s: Isolate the station from LAN
>
T e l n e t C o m m
T e l n e t C o m m
This command allows users to configure general settings and security settings for wireless
connection.
S y n t a x
S y n t a x
wl config mode [value]
wl config mode show
wl config channel [number]
wl config preamble [enable]
wl config txburst [enable]
wl config ssid [ssid_num enable ssid_name [hidden_ssid]]
wl config security [SSID_NUMBER] [mode]
wl config ratectl [ssid_num enable upload download ]
wl config isolate [ssid_num lan member]
S y n t a x
S y n t a x
Parameter
mode[value]
mode show
channel [number]
preamble [enable]
txburst [enable]
ssid[ssid_num enable
ssid_name [hidden_ssid]]
896
Attribute
00:50:70:ff:12:70
s 00:50:70:ff:12:70
a n d : w l c o n f i g
a n d : w l c o n f i g
D e s c r i p t i o n
D e s c r i p t i o n
Description
It means to select connection mode for wireless connection.
Available settings are: "11bgn", "11gn", "11n", "11bg", "11g", or "11b".
It means to display what the current wireless mode is.
It means the channel of frequency of the wireless LAN.
The available settings are 0,1,2,3,4,5,6,7,8,9,10,11,12 and 13.
number=0, means Auto
number=1, means Channel 1
....
number=13, means Channel 13.
It means to define the length of the sync field in an 802.11 packet.
Most modern wireless network uses short preamble with 56 bit sync
field instead of long preamble with 128 bit sync field. However,
some original 11b wireless network devices only support long
preamble.
0: disable to use long preamble.
1: enable to use long preamble.
It means to enhance the performance in data transmission about
40%* more (by enabling Tx Burst). It is active only when both sides
of Access Point and Station (in wireless client) invoke this function
at the same time.
0: disable the function.
1: enable the funciton.
It means to set the name of the SSID, hide the SSID if required.
ssid_num: Type 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
ssid_name: Give a name for the specified SSID.
MAC Address Associated SSIDs
ssid1 ssid2 ssid3 ssid4
ssid1 ssid2
