Page 2 Vigor2860 Series VDSL2 Security Firewall User’s Guide Version: 2.5 Firmware Version: V3.7.4.1 (For future update, please visit DrayTek web site) Date: April 02, 2014 Vigor2860 Series User’s Guide...
Page 3 Web registration is preferred. You can register your Vigor router via Owner http://www.DrayTek.com. Firmware & Tools Due to the continuous evolution of DrayTek technology, all routers will be regularly Updates upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.
Page 4 Product: Vigor2860 Series Router DrayTek Corp. declares that Vigor2860 Series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE 1999/5/EC, ErP 2009/125/EC and RoHS 2011/65/EU The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
Page 5: Table Of Contents
2.1.3 For WAN3/WAN4 (USB)....................46 2.2 Service Activation Wizard...................... 48 2.3 VPN Client Wizard ........................ 52 2.4 VPN Server Wizard ....................... 58 2.5 Wireless Wizard ........................63 2.6 VoIP Wizard........................... 67 2.7 Registering Vigor Router....................... 69 Vigor2860 Series User’s Guide...
Page 6 3.7.11 Notification Object....................... 216 3.8 CSM Profile ......................... 218 3.8.1 APP Enforcement Profile ....................219 3.8.2 URL Content Filter Profile..................... 222 3.8.3 Web Content Filter Profile..................... 227 3.8.4 DNS Filter ........................231 3.8.5 APPE Support List ......................232 Vigor2860 Series User’s Guide...
Page 7 3.15.2 SIP Accounts ......................340 3.15.3 Phone Settings ......................345 3.15.4 Status.......................... 350 3.16 Wireless LAN(2.4GHz/5GHz) ................... 352 3.16.1 Basic Concepts......................352 3.16.2 General Setup......................354 3.16.3 Security ........................357 3.16.4 Access Control......................359 3.16.5 WPS..........................360 Vigor2860 Series User’s Guide...
Page 8 3.20.7 Ping Diagnosis......................425 3.20.8 Data Flow Monitor....................... 426 3.20.9 Traffic Graph....................... 428 3.20.10 Trace Route ......................429 3.20.11 Syslog Explorer......................430 3.20.12 TSPC Status ......................431 3.21 External Devices ....................... 432 3.21.1 All Devices ........................432 Vigor2860 Series User’s Guide viii...
Page 9 4.13 How to use AP Management function (in Vigor2860) to check AP status and deploy WLAN profile............................495 4.14 CVM Application - How to manage the CPE (router) through Vigor2860 series? .... 498 4.15 CVM Application - How to build the VPN between remote devices and Vigor2860 series? ..............................
Page 10 Vigor2860 Series User’s Guide...
Page 11: Introduction
Vigor2860 series is a VDSL2 router. It integrates IP layer QoS, NAT session/bandwidth management to help users control works well with large bandwidth. By adopting hardware-based VPN platform and hardware encryption of AES/DES/3DES, the router increases the performance of VPN greatly, and offers several protocols (such as IPsec/PPTP/L2TP) with up to 32 VPN tunnels.
Page 12: Web Configuration Buttons Explanation
Add new settings for specified item. Edit the settings for the selected item. Delete the selected item with the corresponding settings. Note: For the other buttons shown on the web pages, please refer to Chapter 3, 4 for detailed explanation. Vigor2860 Series User’s Guide...
Page 13: Led Indicators And Connectors
The port is connected with 1000Mbps. The port is connected with 10/100Mbps Left The port is connected. GigaLAN The port is disconnected. Blinking The data is transmitting. Right The port is connected with 1000Mbps. The port is connected with 10/100Mbps Vigor2860 Series User’s Guide...
Page 14 Connecter for a USB device (for 3G USB Modem or printer). VDSL/ADSL Connecter for accessing the Internet. WAN2 Connecter for local network devices or modem for accessing Internet. GigaLAN (1-6) Connecters for local network devices. Connecter for a power adapter. Power Switch. ON/OFF Vigor2860 Series User’s Guide...
Page 15: For Vigor2860N
The port is connected with 1000Mbps. The port is connected with 10/100Mbps Left The port is connected. GigaLAN The port is disconnected. Blinking The data is transmitting. Right The port is connected with 1000Mbps. The port is connected with 10/100Mbps Vigor2860 Series User’s Guide...
Page 16 Connecter for a USB device (for 3G USB Modem or printer). VDSL/ADSL Connecter for accessing the Internet. WAN2 (Giga) Connecter for local network devices or modem for accessing Internet. GigaLAN (1-6) Connecters for local network devices. Connecter for a power adapter. ON/OFF Power Switch. Vigor2860 Series User’s Guide...
Page 17: For Vigor2860N-Plus
The port is connected with 1000Mbps. The port is connected with 10/100Mbps Left The port is connected. GigaLAN The port is disconnected. Blinking The data is transmitting. Right The port is connected with 1000Mbps. The port is connected with 10/100Mbps Vigor2860 Series User’s Guide...
Page 18 Connecter for a USB device (for 3G USB Modem or printer). VDSL/ADSL Connecter for accessing the Internet. WAN2 (Giga) Connecter for local network devices or modem for accessing Internet. GigaLAN (1-6) Connecters for local network devices. Connecter for a power adapter. ON/OFF Power Switch. Vigor2860 Series User’s Guide...
Page 19: For Vigor2860Vn-Plus
The data is transmitting. Right The port is connected with 1000Mbps. The port is connected with 10/100Mbps Left The port is connected. GigaLAN The port is disconnected. Blinking The data is transmitting. Right The port is connected with 1000Mbps. Vigor2860 Series User’s Guide...
Page 20 WAN2 (Giga) Connecter for local network devices or modem for accessing Internet. GigaLAN (1-6) Connecters for local network devices. Phone 1/2 Connecter for analog phone(s). Line Connector for PSTN life line. Connecter for a power adapter. Vigor2860 Series User’s Guide...
Page 21: Hardware Installation
Power on the device by pressing down the power switch on the rear panel. The system starts to initiate. After completing the system test, the ACT LED will light up and start blinking. (For the hardware connection, we take “n” model as an example.) Vigor2860 Series User’s Guide...
Page 22: Printer Installation
You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows XP/2000. For Windows 98/SE/Vista, please visit www.DrayTek.com. Before using it, please follow the steps below to configure settings for connected computers (or wireless clients).
Page 23 Open File->Add Printer. A welcome dialog will appear. Please click Next. Click Local printer attached to this computer and click Next. In this dialog, choose Create a new port Type of port and use the drop down list to select Standard TCP/IP Port. Click Next. Vigor2860 Series User’s Guide...
Page 24 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next. Click Standard and choose Generic Network Card. Then, in the following dialog, click Finish. Vigor2860 Series User’s Guide...
Page 25 11. Select "LPR" on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next please refer to the red rectangle for choosing the correct protocol and LPR name. Vigor2860 Series User’s Guide...
Page 26 Note 1: Some printers with the fax/scanning or other additional functions are not supported. If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support >FAQ/Application Notes; find out the link of USB>>Printer Server and click it.
Page 27: Accessing Web Page
Please type “admin/admin” as the Username/Password and click Login. Notice: If you fail to access to the web configuration, please go to “Trouble Shooting” for detecting and solving your problem. Vigor2860 Series User’s Guide...
Page 28: Changing Password
Open a web browser on your PC and type http://192.168.1.1. A pop-up window will open to ask for username and password. Please type “admin/admin” as Username/Password for accessing into the web user interface with admin mode. Go to System Maintenance page and choose Administrator Password. Vigor2860 Series User’s Guide...
Page 29 Now, the password has been changed. Next time, use the new password to access the Web user interface for this router. Note: Even the password is changed, the Username for logging onto the web user interface is still “admin”. Vigor2860 Series User’s Guide...
Page 30: Introducing Dashboard
It will be refreshed every five seconds. When you move and click the mouse cursor on LEDs (except ACT), USB ports, VDSL/ADSL, WAN2, or LAN1 – LAN6, related web setting page will be open for you to configure if required. Vigor2860 Series User’s Guide...
Page 31: Name With A Link
For detailed information about the LED display, refer to 1.2 LED Indicators and Connectors. A name with a link (e.g., Router Name, Current Time, WAN1 and etc.) below means you can click it to open the configuration page for modification. Vigor2860 Series User’s Guide...
Page 32: Quick Access For Common Used Menu
LAN are located on the bottom of this page. Scroll down the page to find them and use them if required. Note that there is a plus ( ) icon located on the left side of VPN/LAN. Click it to review the VPN connection(s) used presently. Vigor2860 Series User’s Guide...
Page 33: Gui Map
All the functions the router supports are listed with table clearly in this page. Users can click the function link to access into the setting page of the function for detailed configuration. Click the icon on the top of the main screen to display all the functions. Vigor2860 Series User’s Guide...
Page 34: Web Console
The functions/settings modified under Web Console also can be reviewed on the web user interface. Click the Web Console icon on the top of the main screen to open the following screen. Vigor2860 Series User’s Guide...
Page 35: Config Backup
Simply click the icon on the top of the main screen and a pop up dialog will appear. Click Save to store the setting. Click this icon to exit the web user interface. Such page displays the physical connection status such as LAN connection status, WAN connection status, ADSL information, and so on. Vigor2860 Series User’s Guide...
Page 36 Vigor2860 Series User’s Guide...
Page 37 RX Bytes - Displays the speed of received octets at the LAN interface. WAN IPv6 Status Enable – No in red means such interface is available but not enabled. Yes in green means such interface is enabled. No in red means such interface is not available. Vigor2860 Series User’s Guide...
Page 38: Virtual Wan
Each time you click OK on the web page for saving the configuration, you can find messages showing the system interaction with you. Ready indicates the system is ready for you to input settings. Settings Saved means your settings are saved once you click Finish or OK button. Vigor2860 Series User’s Guide...
Page 39: Quick Setup
VoIP Wizard – used for establishing VoIP profile. Quick Start Wizard can help you to deploy and use the router easily and quickly. The first screen of Quick Start Wizard is entering login password. After typing the password, please click Next. Vigor2860 Series User’s Guide...
Page 40 WAN1; if Ethernet interface is used, please choose WAN2; if 3G USB modem is used, please choose WAN3 or WAN4. Then click Next for next step. WAN1, WAN2, WAN3 and WAN4 will bring up different configuration page. Refer to the following sections for detailed information. Vigor2860 Series User’s Guide...
Page 41: For Wan1 (Adsl/Vdsl2)
ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. In addition, the field of For ADSL Only will be available only when ADSL is detected. Then click Next for next step. Vigor2860 Series User’s Guide...
Page 42 Type the IP address if Fixed IP is enabled. Subnet Mask Type the subnet mask. Default Gateway Type the IP address as the default gateway. Primary DNS Type in the primary IP address for the router. Vigor2860 Series User’s Guide...
Page 43 Note: The maximum length of the password you can set is 62 characters. Confirm Password Retype the password. Back Click it to return to previous setting page. Click it to get into the next setting page. Next Cancel Click it to give up the quick start wizard. Vigor2860 Series User’s Guide...
Page 44 After finished the above settings, click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 45 VPI and VCI. Or, click Auto detect to find out the best values. Fixed IP Click Yes to enable Fixed IP feature. Type the IP address if Fixed IP is enabled. IP Address Subnet Mask Type the subnet mask. Vigor2860 Series User’s Guide...
Page 46 Then click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 47: For Wan2 (Ethernet)
On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. Then click Next for next step. Vigor2860 Series User’s Guide...
Page 48 Assign a specific valid user name provided by the ISP. Note: The maximum length of the user name you can set is 63 characters. Password Assign a valid password provided by the ISP. Note: The maximum length of the password you can set is 62 Vigor2860 Series User’s Guide...
Page 49 Please manually enter the Username/Password provided by your ISP. Click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 50 Description User Name Assign a specific valid user name provided by the ISP. Note: The maximum length of the user name you can set is 63 characters. Password Assign a valid password provided by the ISP. Vigor2860 Series User’s Guide...
Page 51 Then click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 52 Type the IP address of gateway. Primary DNS Type in the primary IP address for the router. Secondary DNS Type in secondary IP address for necessity in the future. Back Click it to return to previous setting page. Vigor2860 Series User’s Guide...
Page 53 Now, you can enjoy surfing on the Internet. Choose WAN2 as WAN Interface and click the Next button. The following page will be open for you to specify Internet Access Type. Vigor2860 Series User’s Guide...
Page 54 Click it to return to previous setting page. Next Click it to get into the next setting page. Cancel Click it to give up the quick start wizard. After finished the settings above, click Next for viewing summary of such connection. Vigor2860 Series User’s Guide...
Page 55 Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 56: For Wan3/Wan4 (Usb)
Internet. The maximum length of the pin code (PPP mode) you can set is 15 characters. Modem Initial String – Such value is used to initialize USB modem. Please use the default value. If you have any Vigor2860 Series User’s Guide...
Page 57 Then, click Next for viewing summary of such connection. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system status of this protocol will be shown. Now, you can enjoy surfing on the Internet. Vigor2860 Series User’s Guide...
Page 58: Service Activation Wizard
Service Activation Wizard is a tool which allows you to use trial version or update the license of WCF directly without accessing into the server (MyVigor) located on http://myvigor.draytek.com. For using Web Content Filter Profile, please refer to later section Web Content Filter Profile for detailed information.
Page 59 When you finish the selection, please click Next. Commtouch is the web content filter based on Commtouch operated in the worldwide. There is a 30-day trial period. After trial, you can purchase DrayTek's prepared Commtouch GlobalView WCF package from retailing outlets.
Page 60 Later, if you need to extend the license valid time for the same service, you can also use the Service Activation Wizard again to reach your goal by clicking the radio button of Formal edition with license key and clicking Next. Vigor2860 Series User’s Guide...
Page 61 Vigor2860 Series User’s Guide...
Page 62: Vpn Client Wizard
Route Mode/NAT Mode – If the remote network only allows you to dial in with single IP, please choose this mode, otherwise please choose Route Mode. Please choose a There are 32 VPN profiles for users to set. LAN-to-LAN Profile Vigor2860 Series User’s Guide...
Page 63 In this page, you have to select suitable VPN type for the VPN client profile. There are six types provided here. Different type will lead to different configuration page. After making the choices for the client profile, please click Next. You will see different configurations based on the selection(s) you made. Vigor2860 Series User’s Guide...
Page 64 When you choose PPTP (None Encryption) or PPTP (Encryption), you will see the following graphic:  When you choose IPsec, you will see the following graphic:  When you choose L2TP, you will see the following graphic: Vigor2860 Series User’s Guide...
Page 65 When you choose L2TP over IPsec (Nice to Have) or L2TP over IPsec (Must), you will see the following graphic: Available settings are explained as follows: Item Description Profile Name Type a name for such profile. The length of the file is limited to 10 characters. Vigor2860 Series User’s Guide...
Page 66 Certificate Management >> Local Certificate. Otherwise, the setting you choose here will not be effective. IPsec Security Medium - Authentication Header (AH) means data will be Method authenticated, but not be encrypted. By default, this option Vigor2860 Series User’s Guide...
Page 67 Click this radio button to set another profile of VPN Server Do another VPN through VPN Server Wizard. Server Wizard Setup View more detailed Click this radio button to access VPN and Remote configuration Access>>LAN to LAN for viewing detailed configuration. Vigor2860 Series User’s Guide...
Page 68: Vpn Server Wizard
VPN connection. Please choose a This item is available when you choose Site to Site VPN LAN-to-LAN Profile (LAN-to-LAN) as VPN server mode. There are 32 VPN profiles for users to set. Vigor2860 Series User’s Guide...
Page 69 2. After making the choices for the server profile, please click Next. You will see different configurations based on the selection you made. Here we take the examples of choosing Site-to-Site VPN as the VPN Server Mode. Vigor2860 Series User’s Guide...
Page 70 When you check PPTP, you will see the following graphic:  When you check PPTP & IPsec & L2TP (three types) or PPTP & IPsec (two types) or L2TP with Policy (Nice to Have/Must), you will see the following graphic: Vigor2860 Series User’s Guide...
Page 71 Peer IP/VPN Client Type the WAN IP address or VPN client IP address for the remote client. Peer ID Type the ID name for the remote client. The length of the name is limited to 47 characters. Vigor2860 Series User’s Guide...
Page 72 Click this radio button to set another profile of VPN Server Server Wizard Setup through VPN Server Wizard. View more detailed Click this radio button to access VPN and Remote configuration Access>>LAN to LAN for viewing detailed configuration. Vigor2860 Series User’s Guide...
Page 73: Wireless Wizard
Description Wireless 2.4GHz Settings Name Type the SSID name of this router for wireless 2.4GHz. The default name is defined with DrayTek. Change the name if required. Mode At present, the router can connect to 11n Only, 11g Only, Mixed (11b+11g), Mixed (11a+11n), Mixed (11g+11n), and Mixed (11b+11g+11n) stations simultaneously.
Page 74 802.1x authentication. Either 8~63 ASCII characters, such as 012345678(or 64 Hexadecimal digits leading by 0x, such as "0x321253abcde..."). Next Click it to get into the next setting page. Vigor2860 Series User’s Guide...
Page 75 Upload – Check Enable and type the transmitting rate for data upload. Default value is 30,000 kbps. Download – Type the transmitting rate for data download. Default value is 30,000 kbps. Wireless 5GHz Settings Click it to enable or disable settings in this page. Enable/Disable Vigor2860 Series User’s Guide...
Page 76 Exit the wireless wizard without saving any changes. 4. After typing the required information, click Next. 5. The following page will display the configuration summary for wireless setting. 6. Click Finish to complete the wireless settings configuration. Vigor2860 Series User’s Guide...
Page 77: Voip Wizard
Password – Type the password for the account registered to your ISP. Use the same Account as phone 1 – If you don’t need to configure Phone 2 settings, simply check this box. Click it to get into the next setting page. Next Vigor2860 Series User’s Guide...
Page 78 Cancel Click it to give up the quick start wizard. 3. After finished the settings above, click Next for viewing summary of such connection. 4. Click Finish. A page of VoIP Wizard Setup OK!!! will appear. Vigor2860 Series User’s Guide...
Page 79: Registering Vigor Router
Please login the web configuration interface of Vigor router by typing “admin/admin” as User Name / Password. Click Support Area>>Production Registration from the home page. A Login page will be shown on the screen. Please type the account and password that you created previously. And click Login. Vigor2860 Series User’s Guide...
Page 80 When the following page appears, please type in Nickname (for the router) and choose the right registration date from the popup calendar (it appears when you click on the box of Registration Date). After adding the basic information for the router, please click Submit. Vigor2860 Series User’s Guide...
Page 81 If you have not activated web content filter service by using Service Activation Wizard, you can activate the service from this step. Please click the serial number link. From the Device’s Service section, click the Trial. Vigor2860 Series User’s Guide...
Page 82 In the following page, check the box of “I have read and accept the above Agreement”. The system will find out the date for you to activate this version of service. Then, click Next. When this page appears, click Register. Wait for a moment until the following page appears. Click Close. Vigor2860 Series User’s Guide...
Page 83: Advanced Configuration
These are known as private IP addresses, and are listed in the following ranges: From 10.0.0.0 to 10.255.255.255 From 172.16.0.0 to 172.31.255.255 From 192.168.0.0 to 192.168.255.255 Vigor2860 Series User’s Guide...
Page 84 Besides, 3G/4G USB Modem in WAN3 also can be used as backup device. Therefore, when WAN1 and WAN2 are not available, the router will use 3.5G for supporting automatically. The supported 3G/4G USB Modem will be listed on DrayTek web site. Please visit www.draytek.com for more detailed information.
Page 85: General Setup
Auto Weigh to let the router reach the best load balance. Index Click the WAN interface link under Index to access into the WAN configuration page. V means such WAN interface is enabled and ready to be Enable used. Vigor2860 Series User’s Guide...
Page 86 Available settings are explained as follows: Item Description Enable Choose Yes to invoke the settings for this WAN interface. Choose No to disable the settings for this WAN interface. Display Name Type the description for such interface. Vigor2860 Series User’s Guide...
Page 87 Disable – Disable the function of VLAN with tag. Tag value – Type the value as the VLAN ID number. The range is form 0 to 4095. Priority – Type the packet priority number for such VLAN. The range is from 0 to 7. Vigor2860 Series User’s Guide...
Page 88 When all of selected WAN disconnect – Such backup WAN will be activated only when all master WAN interfaces disconnect. After finished the above settings, click OK to save the settings. WAN2 is fixed with physical mode of Ethernet. Vigor2860 Series User’s Guide...
Page 89 Load Balance: Check this box to enable auto load balance function for such WAN interface. When the data traffic is large, the WAN interface with the function enabled will balance the data transmission automatically among all of the WAN interfaces in connection status. Vigor2860 Series User’s Guide...
Page 90 Display the physical mode of such WAN interface. Line Speed If your choose According to Line Speed as the Load Balance Mode, please type the line speed for downloading and uploading for such WAN interface. The unit is kbps. Vigor2860 Series User’s Guide...
Page 91 WAN will be activated when any master WAN interface disconnects. When all of selected WAN disconnect – Such backup WAN will be activated only when all master WAN interfaces disconnect. After finished the above settings, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 92: Internet Access
Access Mode for these connections also varies. Refer to the following figures. Available settings are explained as follows: Item Description Index Display the WAN interface. Display Name It shows the name of the WAN1/WAN2/WAN3/WAN4 that entered in general setup. Physical Mode It shows the physical connection for Vigor2860 Series User’s Guide...
Page 93 Interface – Specify the WAN interface(s) that will be overwritten by such function. WAN5 ~ WAN7 can be located under WAN>>Multi-PVCs. Option Number – Type a number for such function. Note If you choose to configure option 61 here, the Vigor2860 Series User’s Guide...
Page 94 ISP via the Vigor router. When PPPoA protocol is selected, the PPPoE package transmitted by PC will be transformed into PPPoA package and sent to WAN server. Thus, the PC can access Internet through such direction. Vigor2860 Series User’s Guide...
Page 95 WAN IP Alias - If you have multiple public IP addresses and would like to utilize them on the WAN interface, please use WAN IP Alias. You can set up to 8 public IP addresses Vigor2860 Series User’s Guide...
Page 96 Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Applications >> Schedule web page and you can use the number that you have set in that web page. Vigor2860 Series User’s Guide...
Page 97 Mode – Choose ARP Detect or Ping Detect for the system to execute for WAN detection. Ping IP – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging. Vigor2860 Series User’s Guide...
Page 98 Specify an IP address – Click this radio button to specify some data.  IP Address – Type in the private IP address.  Subnet Mask – Type in the subnet mask.  Gateway IP Address – Type in gateway IP Vigor2860 Series User’s Guide...
Page 99 ADSL only. (for ADSL only) Multi-PVC channel - The selections displayed here are determined by the page of Internet Access >> Multi PVCs. Select M-PVCs Channel means no selection will be chosen. Vigor2860 Series User’s Guide...
Page 100 IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. It means Max Transmit Unit for packet. The default setting is 1442. Vigor2860 Series User’s Guide...
Page 101 WAN IP Alias - If you have multiple public IP addresses and would like to utilize them on the WAN interface, please use WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Vigor2860 Series User’s Guide...
Page 102 LANs to send packets to each other via an ATM backbone. To use MPoA/Static or Dynamic IP as the accessing protocol of the Internet, select MPoA /Static or Dynamic IP from the WAN>>Internet Access >>WAN1 page. The following web page will appear. Vigor2860 Series User’s Guide...
Page 103 ISP. VPI - Type in the value provided by ISP. VCI - Type in the value provided by ISP. Modulation –Default setting is Multimode. Choose the one that fits the requirement of your router. Vigor2860 Series User’s Guide...
Page 104 WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Notice that this setting is available for WAN1 only. Type the additional WAN IP address and check the Enable box. Then click OK to exit the dialog. Vigor2860 Series User’s Guide...
Page 105 Specify a MAC Address – Type in the MAC address for the router manually. DNS Server IP Address Type in the primary IP address for the router. If necessary, type in secondary IP address for necessity in the future. Vigor2860 Series User’s Guide...
Page 106 Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Application >> Schedule web page and you can use the number that you have set in that web page. Vigor2860 Series User’s Guide...
Page 107 OK to exit the dialog. Fixed IP – Click Yes to use this function and type in a fixed IP address in the box of Fixed IP Address. Default MAC Address – You can use Default MAC Vigor2860 Series User’s Guide...
Page 108 Available settings are explained as follows: Item Description Enable / Disable Click Enable for activating this function. If you click Disable, this function will be closed and all the settings that you adjusted in this page will be invalid. Vigor2860 Series User’s Guide...
Page 109 WAN IP Alias - If you have multiple public IP addresses and would like to utilize them on the WAN interface, please use WAN IP Alias. You can set up to 8 public IP addresses other than the current one you are using. Vigor2860 Series User’s Guide...
Page 110 Specify a MAC Address: Some Cable service providers specify a specific MAC address for access authentication. In such cases you need to click the Specify a MAC Address and enter the MAC address in the MAC Address field. Vigor2860 Series User’s Guide...
Page 111 63 characters. Password -Type in the password provided by ISP in this field. The maximum length of the password you can set is 62 characters. Index (1-15) in Schedule Setup - You can type in four sets Vigor2860 Series User’s Guide...
Page 112 Specify an IP address – Click this radio button to specify some data.  IP Address – Type the IP address.  Subnet Mask – Type the subnet mask. After finishing all the settings here, please click OK to activate them. Vigor2860 Series User’s Guide...
Page 113 SIM PIN code Type PIN code of the SIM card that will be used to access Internet. The maximum length of the PIN code you can set is 15 characters. Vigor2860 Series User’s Guide...
Page 114 IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. After finishing all the settings here, please click OK to activate them. Vigor2860 Series User’s Guide...
Page 115 The maximum length of the name you can set is 47 characters. It means Max Transmit Unit for packet. The default setting is 1380. After finishing all the settings here, please click OK to activate them. Vigor2860 Series User’s Guide...
Page 116 PCs under LAN also can have the public IPv6 address for Internet access by means of the generated prefix. No need to type any other information for PPP mode. Below shows an example for successful IPv6 connection based on PPP mode. Vigor2860 Series User’s Guide...
Page 117 After getting the IPv6 prefix and starting router advertisement daemon (RADVD), the PC behind this router can directly connect to IPv6 the Internet. Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 118 The maximum length of the name you can set is 19 characters. Password Type the password assigned with the user name. The maximum length of the password you can set is 19 characters. Confirm Password Type the password again to make the confirmation. Vigor2860 Series User’s Guide...
Page 119 Available settings are explained as follows: Item Description Identify Association Choose Prefix Delegation or Non-temporary Address as the identify association. IAID Type a number as IAID. After finished the above settings, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 120 Delete – Click it to remove an existed entry. Current IPv6 Address Display current interface IPv6 address. Table Static IPv6 Gateway IPv6 Gateway Address - Type your IPv6 gateway address Configuration here. After finished the above settings, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 121 Type the static IPv6 address for LAN routing with the value for prefix length. Type the number for the data lifetime in tunnel. Tunnel TTL After finished the above settings, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 122 Type the IPv4 addresses of the 6rd Border Relay for a given 6rd domain. IPv4 Mask Length Type a number of high-order bits that are identical across all CE IPv4 addresses within a given 6rd domain. It may be any value between 0 and 32. Vigor2860 Series User’s Guide...
Page 123 Type the IPv6 prefix length for the 6rd IPv6 prefix in number of bits. After finished the above settings, click OK to save the settings. Below shows an example for successful IPv6 connection based on 6rd mode. Vigor2860 Series User’s Guide...
Page 124: Multi-Pvc
WAN type may not configure the same VLAN tag value. Enable - Check this box to enable the port-based bridge function on this channel. P1 ~ P6 – Check the box(es) to build bridge connection on LAN. Vigor2860 Series User’s Guide...
Page 125 VCI - Type in the value provided by your ISP. Protocol - Select a proper protocol for this channel. Encapsulation - Choose a proper type for this channel. The types will be different according to the protocol setting that you choose. Vigor2860 Series User’s Guide...
Page 126 WAN links for Channel 5, 6 and 7 are provided for router-borne application such as TR-069. The settings must be applied and obtained from your ISP. For your special request, please contact with your ISP and then click WAN link of Channel 5, 6 or 7 to configure your router. Vigor2860 Series User’s Guide...
Page 127 WAN type to be built upon. In the Multi-PVCs application, only the Ethernet WAN type is available. The user will be able to select the physical WAN interface the channel shall use here. Vigor2860 Series User’s Guide...
Page 128 WAN Application – Management – It can be specified for general management (Web configuration/telnet/TR069). If you choose Management, the configuration for this VLAN will be effective for Web configuration/telnet/TR069. IPTV - The IPTV configuration will allow the WAN Vigor2860 Series User’s Guide...
Page 129 Static IP mode. If necessary, type in secondary IP address for necessity in the future. After finished the above settings, click OK to save the settings and return to previous page. Vigor2860 Series User’s Guide...
Page 130 It allows the PVC channel to use the same ADSL connection settings of another PVC channel. Please choose the PVC channel via the drop down list. After finished the above settings, click OK to save the settings Vigor2860 Series User’s Guide...
Page 131: Lan
IP address. As a part of the public subnet, the Vigor router will serve for IP routing to help hosts in the public subnet to communicate with other public hosts or servers outside. Therefore, the router should be set as the gateway for public hosts. Vigor2860 Series User’s Guide...
Page 132 You can group local hosts by physical ports and create up to 8 virtual LANs. To manage the communication between different groups, please set up rules in Virtual LAN (VLAN) function and the rate of each. Vigor2860 Series User’s Guide...
Page 133: General Setup
DHCP box for each LAN. IP Address - Display the IP address for each LAN item. Such information is set in default and you can not modify it. Details Page - Click it to access into the setting page. Each Vigor2860 Series User’s Guide...
Page 134 Internet Access server (PPPoE, PPTP, L2TP or DHCP server). Inter-LAN Routing Check the box to link two or more different subnets (LAN and LAN). When you finish the configuration, please click OK to save and exit this page. Vigor2860 Series User’s Guide...
Page 135 LAN. Disable Server – Let you manually assign IP address to every host in the LAN. Enable Relay Agent –Specify which subnet that DHCP server is located the relay agent should redirect the DHCP Vigor2860 Series User’s Guide...
Page 136 DNS Server. If your ISP does not provide it, the router will automatically apply default secondary DNS Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: Vigor2860 Series User’s Guide...
Page 137 IPv4) and IPv6 Setup. Click the tab for each type and refer to the following explanations for detailed information. Below shows the settings page for IPv6. It provides 2 daemons for LAN side IPv6 address configuration. One is RADVD(stateless) and the other is DHCPv6 Server (Stateful). Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 138 Add – Click it to add a new entry. Delete – Click it to remove an existed entry. Current IPv6 Address Display current used IPv6 addresses. Table When you finish the configuration, please click OK to save and exit this page. Vigor2860 Series User’s Guide...
Page 139 DHCP Server IP Address – It is available when Enable Relay Agent is checked. Set the IP address of the DHCP server you are going to use so the Relay Agent can help to Vigor2860 Series User’s Guide...
Page 140 Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: If both the Primary IP and Secondary IP Address fields are left empty, the router will assign its own IP address to local Vigor2860 Series User’s Guide...
Page 141 DHCP stands for Dynamic Host Configuration Protocol. Configuration The router by factory default acts a DHCP server for your network so it automatically dispatch related IP settings to any local user configured as a DHCP client. It is highly Vigor2860 Series User’s Guide...
Page 142 Edit – Click it to edit the selected MAC address. Cancel – Click it to cancel the job of adding, deleting and editing. When you finish the configuration, please click OK to save and exit this page. Vigor2860 Series User’s Guide...
Page 143: Static Route
Displays the destination address of the static route. Status Displays the status of the static route. Set to Factory Default Clear all of the settings and return to factory default settings. Displays the routing table for your reference. Viewing Routing Table Vigor2860 Series User’s Guide...
Page 144 1st subnet (192.168.1.0/24). The second is that those hosts on the internal private subnets (ex. 192.168.10.0/24) can access the Internet via the router, and continuously exchange of IP routing information with different subnets. Vigor2860 Series User’s Guide...
Page 145 Use the drop down list to specify an interface for such static route. Return to Static Route Setup page. Click on another Index Number to add another static route as show below, which regulates all packets destined to 211.100.88.0 will be forwarded to 192.168.1.3. Click OK. Vigor2860 Series User’s Guide...
Page 146 Set to Factory Default Clear all of the settings and return to factory default settings. Viewing IPv6 Routing Displays the routing table for your reference. Table Click any underline of index number to get the following page. Vigor2860 Series User’s Guide...
Page 147 Type the gateway address for this entry. Network Interface Use the drop down list to specify an interface for this static route. When you finish the configuration, please click OK to save and exit this page. Vigor2860 Series User’s Guide...
Page 148: Vlan
The multi-subnet can let a small businesses have much better isolation for multi-occupancy applications. Go to LAN page and select VLAN. The following page will appear. Click Enable to invoke VLAN function. Below is an example page in Vigor2860n: Vigor2860 Series User’s Guide...
Page 149 Choose one of them to make the selected VLAN mapping to the specified subnet only. For example, LAN1 is specified for VLAN0. It means that PCs grouped under VLAN0 can get the IP address(es) that specified by the subnet. Vigor2860 Series User’s Guide...
Page 150 Note: Leave one VLAN untagged at least to prevent from not connecting to Vigor router due to unexpected error. Vigor2860 series features a hugely flexible VLAN system. In its simplest form, each of the Gigabit LAN ports can be isolated from each other, for example to feed different companies or departments but keeping their local traffic completely separated.
Page 151 (isolated) or common (able to communicate with each other). This is ideal for departmental or multi-occupancy applications. Note: As for the VLAN applications, refer to “Appendix I: VLAN Application on Vigor Router” for more detailed information. Vigor2860 Series User’s Guide...
Page 152: Bind Ip To Mac
Each pair of IP and MAC address listed in ARP table can be selected and added to IP Bind List by clicking Add below Click this link to select all the items in the ARP table. Select All Sort Reorder the table based on the IP address. Vigor2860 Series User’s Guide...
Page 153 Note: Before you select Strict Bind, you have to bind one set of IP/MAC address for one PC. If not, no one of the PCs can access into Internet. And the web user interface of the router might not be accessed. When you finish the configuration, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 154: Lan Port Mirror
Select which ports are necessary to be mirrored for transmitting the packets. Mirrored Rx Port Select which ports are necessary to be mirrored for receiving the packets. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 155: Wired 802.1X
Check the box to enable LAN 802.1x function. Enable 802.1x ports After enabling the function, simply specify the LAN port(s) to apply such function. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 156: Web Portal Setup
Display the content (Disable, URL Redirect or Message) of the profile. Interface Display the applied interfaced of the profile. Preview Open a preview window according to the configured settings. To configure the profile, click any index number link to open the following page. Vigor2860 Series User’s Guide...
Page 157 Check the box(es) representing different interfaces to be applied by such profile. The advantage is that each SSID (1/2/3/4) for wireless network can be applied with different web portal separately. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 158: Load-Balance /Route Policy
Use Up or Down link to move the order of the policy. Wizard Mode Allows to configure frequently used settings of route policy via three setting pages Advance Mode Allows to configure detailed settings of route policy. Vigor2860 Series User’s Guide...
Page 159 Available settings are explained as follows: Item Description Interface Use the drop down list to choose a WAN or LAN interface or VPN profile. Packets match with the above criteria will be transferred to the interface chosen here. Vigor2860 Series User’s Guide...
Page 160 6. If there is no error, click Finish to complete wizard setting. To use Advance Mode, do the following steps: 1. Click the Advance Mode radio button. 2. Click Index 1 to access into the following page. Vigor2860 Series User’s Guide...
Page 161 Src IP End - Type the source IP end for the specified WAN interface. If this field is blank, it means that all the source IPs inside the LAN will be passed through the WAN interface. Vigor2860 Series User’s Guide...
Page 162 WAN automatically when the selected WAN interface is down. Packet Forwarding to WAN via – Choose Force NAT or Force Routing. When you finish the configuration, please click OK to save and exit this page. Vigor2860 Series User’s Guide...
Page 163: Nat
192.168.1.0/24 subnet for the router. As stated before, the NAT facility can map one or more IP addresses and/or service ports into different specified services. In other words, the NAT function can be achieved by using port mapping methods. Below shows the menu items for NAT. Vigor2860 Series User’s Guide...
Page 164: Port Redirection
The port redirection can only apply to incoming traffic. To use this function, please go to NAT page and choose Port Redirection web page. The Port Redirection Table provides 40 port-mapping entries for the internal hosts. Vigor2860 Series User’s Guide...
Page 165 IP of private IP had been entered, the system will calculate and display the ending IP of private IP automatically. Service Name Enter the description of the specific network service. Select the transport layer protocol (TCP or UDP). Protocol Vigor2860 Series User’s Guide...
Page 166 80 to avoid conflict, such as 8080. This can be set in the System Maintenance >>Management Setup. You then will access the admin screen of by suffixing the IP address with 8080, e.g., http://192.168.1.1:8080 instead of port 80. Vigor2860 Series User’s Guide...
Page 167 Vigor2860 Series User’s Guide...
Page 168: Dmz Host
Click DMZ Host to open the following page. You can set different DMZ host for each WAN interface. Click the WAN tab to switch into the configuration page for that WAN. Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 169 IP address will be shown on the following screen. Click OK to save the setting. DMZ Host for WAN2, WAN3 or WAN4 is slightly different with WAN1. Active True IP selection is available for WAN1 only. See the following figure. Vigor2860 Series User’s Guide...
Page 170 When you have selected one private IP from the above dialog, the IP address will be shown on the screen. Click OK to save the setting. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 171: Open Ports
Inactive or Active state. To add or edit port settings, click one index number on the page. The index entry setup page will pop up. In each index entry, you can specify 10 port ranges for diverse services. Vigor2860 Series User’s Guide...
Page 172 Specify the transport layer protocol. It could be TCP, UDP, or ----- (none) for selection. Start Port Specify the starting port number of the service offered by the local host. End Port Specify the ending port number of the service offered by the local host. Vigor2860 Series User’s Guide...
Page 173: Port Triggering
TCP: 86400 sec. UDP: 180 sec. IGMP: 10 sec. TCP WWW: 60 sec. TCP SYN: 60 sec. Available settings are explained as follows: Item Description Comment Display the text which memorizes the application of this rule. Vigor2860 Series User’s Guide...
Page 174 Check to enable this entry. Service Choose the predefined service to apply for such trigger profile. Comment Type the text to memorize the application of this rule. Triggering Protocol Select the protocol (TCP, UDP or TCP/UDP) for such triggering profile. Vigor2860 Series User’s Guide...
Page 175 (TCP, UDP or TCP/UDP) for the incoming data of such triggering profile. Incoming Port Type the port or port range for the incoming packets. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 176: Firewall
It will check packets according to the filter rules. If legal, the packet will pass the router. The following illustrations are flow charts explaining how router will treat incoming traffic and outgoing traffic respectively. Vigor2860 Series User’s Guide...
Page 177 4. Port Scan attack 12. Tear drop attack 5. IP options 13. Ping of Death attack 6. Land attack 14. ICMP fragment 7. Smurf attack 15. Unassigned Numbers 8. Trace route Below shows the menu items for Firewall. Vigor2860 Series User’s Guide...
Page 178: General Setup
“Accept large incoming fragmented UDP or ICMP Packets”. By checking this box, you can play these kinds of on-line games. If security concern is in higher priority, you cannot enable “Accept large incoming fragmented UDP or ICMP Packets”. Vigor2860 Series User’s Guide...
Page 179 IPv4 being accepted by such router. It is effective only for the packets routed but not for packets translated by NAT. Such page allows you to choose filtering profiles including QoS, Load-Balance policy, WCF, APP Enforcement, URL Content Filter, for data transmission via Vigor router. Vigor2860 Series User’s Guide...
Page 180 All the hosts in LAN must follow the standard configured in the APP Enforcement profile selected here. For detailed information, refer to the section of APP Enforcement profile setup. For Vigor2860 Series User’s Guide...
Page 181 URL will be processed. Please use the drop-down list to choose a codepage. If you do not have any idea of choosing suitable codepage, please open Syslog. From Codepage Information of Setup dialog, you will see the recommended codepage listed on the dialog box. Vigor2860 Series User’s Guide...
Page 182 However, if the network is not stable, small value will be proper. Session timeout – Setting timeout for sessions can make the best utilization of network resources. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 183: Filter Setup
Set the link to the next filter set to be executed after the current filter run. Do not make a loop with many filter sets. To edit Filter Rule, click the Filter Rule index button to enter the Filter Rule setup page. Vigor2860 Series User’s Guide...
Page 184 ON schedule profiles are applied. Set the direction of packet flow. It is for Data Filter only. Direction For the Call Filter, this setting is not available since Call Filter is only applied to outgoing traffic. Vigor2860 Series User’s Guide...
Page 185 From the IP Group drop down list, choose the one that you want to apply. Or use the IP Object drop down list to choose the object that you want. Service Type Click Edit to access into the following dialog to choose a suitable service type. Vigor2860 Series User’s Guide...
Page 186 Filter Specifies the action to be taken when packets match the rule. Block Immediately - Packets matching the rule will be dropped immediately. Pass Immediately - Packets matching the rule will be Vigor2860 Series User’s Guide...
Page 187 [Create New] from the drop down list in this page to create a new profile. All the hosts in LAN must follow the standard configured in the APP Enforcement profile selected here. For detailed information, refer to the Vigor2860 Series User’s Guide...
Page 188 Choose correct codepage can help the system obtaining correct ASCII after decoding data from URL and enhance the correctness of URL Content Filter. The default value for this setting is ANSI 1252 Latin Vigor2860 Series User’s Guide...
Page 189 TCP protocol only; session timeout is configured for the data flow which matched with the firewall rule. DrayTek Banner – Please uncheck this box and the following screen will not be shown for the unreachable web page. The default setting is Enabled.
Page 190 Each filter set is composed by 7 filter rules, which can be further defined. After that, in General Setup you may specify one set for call filter and one set for data filter to execute first. Vigor2860 Series User’s Guide...
Page 191: Dos Defense
Check the box to activate the UDP flood defense function. Once detecting the Threshold of the UDP packets from the Internet has exceeded the defined value, the Vigor router will start to randomly discard the subsequent UDP packets for a period defined in Timeout. Vigor2860 Series User’s Guide...
Page 192 The Vigor router will drop any packets having SYN flag and more fragment bit set. Block Fraggle Attack Check the box to activate the Block fraggle Attack function. Any broadcast UDP packets received from the Internet is blocked. Vigor2860 Series User’s Guide...
Page 193 All the warning messages related to DoS Defense will be sent to user and user can review it through Syslog daemon. Look for the keyword DoS in the message, followed by a name to indicate what kind of attacks is detected. Vigor2860 Series User’s Guide...
Page 194 Vigor2860 Series User’s Guide...
Page 195: User Management
Note: If Transparency Mode is selected in Firewall>>General Setup, User Management cannot be used any more. Please uncheck Transparency Mode first if you want to utilize user management to handle users in LAN, WAN or WLAN. Vigor2860 Series User’s Guide...
Page 196: General Setup
Landing Page Type the information to be displayed on the first web page when the LAN user accessing into Internet via such router. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 197: User Profile
To set the user profile, please click any index number link to open the following page. Notice that profile 1 (admin) and profile 2 (Dial-In User) are factory default settings. Profile 2 is reserved for future use. Vigor2860 Series User’s Guide...
Page 198 Firewall can be adopted for such user profile. Create New Policy – If you choose such item, the following page will be popped up for you to define another filter rule as a new policy. Vigor2860 Series User’s Guide...
Page 199 URL (if requested by the user) will be guided automatically by the router. Alert Tool – If it is selected, the user can open Alert Tool and type the user name and password for authentication. A Vigor2860 Series User’s Guide...
Page 200 Next, the user can access Internet through any browser on Windows. Note that Alert Tool can be downloaded from DrayTek web site. Telnet – If it is selected, the user can use Telnet command to perform the authentication job.
Page 201 Default Time Quota – Type the value for the time manually. Default Data Quota – Type the value for the data manually. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 202: User Group
All the available user objects that you have created will be shown in this box. Notice that user object, Admin and Dial-In User are factory settings. User defined profiles will be numbered with 3, 4, 5 and so Vigor2860 Series User’s Guide...
Page 203: User Online Status
Last Login Time Display the login time that such user connects to the router last time. Expired Time Display the expired time of the network connection for the user. Data Quota Display the quota for data transmission. Vigor2860 Series User’s Guide...
Page 204: Objects Settings
IPs in the same department can be defined with an IP object (a range of IP address). You can set up to 192 sets of IP Objects with different conditions. Available settings are explained as follows: Item Description Clear all profiles. Set to Factory Default Vigor2860 Series User’s Guide...
Page 205 Select Range Address if this object contains several IPs within a range. Select Subnet Address if this object contains one subnet for IP address. Select Any Address if this object contains any IP address. Select Mac Address if this object contains Mac address. Vigor2860 Series User’s Guide...
Page 206 If it is checked, all the IP addresses except the ones listed above will be applied later while it is chosen. After finishing all the settings here, please click OK to save the configuration. Below is an example of IP objects settings. Vigor2860 Series User’s Guide...
Page 207: Ip Group
Display the name of the group profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2860 Series User’s Guide...
Page 208 Selected IP Objects Click >> button to add the selected IP objects in this box. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 209: Ipv6 Object
Display the name of the object profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2860 Series User’s Guide...
Page 210 Invert Selection If it is checked, all the IPv6 addresses except the ones listed above will be applied later while it is chosen. After finishing all the settings, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 211: Ipv6 Group
To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 212: Service Type Object
You can set up to 96 sets of Service Type Objects with different conditions. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Name Display the name of the object profile. Vigor2860 Series User’s Guide...
Page 213 (>) – the port number greater than this value is available. (<) – the port number less than this value is available for this profile. Vigor2860 Series User’s Guide...
Page 214: Service Type Group
This page allows you to bind several service types into one group. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Display the name of the group profile. Name Vigor2860 Series User’s Guide...
Page 215 Objects Setting>>Service Type Object will be shown in this box. Selected Service Type Click >> button to add the selected IP objects in this box. Objects After finishing all the settings, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 216: Keyword Object
Web Content Filter Profile. Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Display the profile number that you can configure. Index Name Display the name of the object profile. Vigor2860 Series User’s Guide...
Page 217 Contents. When you browse the webpage, the page with gambling information will be watched out and be passed/blocked based on the configuration on Firewall settings. After finishing all the settings, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 218: Keyword Group
Display the name of the group profile. To set a new profile, please do the steps listed below: 1. Click the number (e.g., #1) under Index column for configuration in details. 2. The configuration page will be shown as follows: Vigor2860 Series User’s Guide...
Page 219: File Extension Object
Available settings are explained as follows: Item Description Set to Factory Default Clear all profiles. Index Display the profile number that you can configure. Name Display the name of the object profile. Vigor2860 Series User’s Guide...
Page 220 Type a name for this profile. The maximum length of the name you can set is 7 characters. Type a name for such profile and check all the items of file extension that will be processed in the router. Finally, click OK to save this profile. Vigor2860 Series User’s Guide...
Page 221: Sms/Mail Service Object
Display the service provider which offers SMS service. To set a new profile, please do the steps listed below: 1. Click the SMS Provider tab, and click the number (e.g., #1) under Index column for configuration in details. Vigor2860 Series User’s Guide...
Page 222 Note that one credit equals to one SMS text message on the standard route. Sending Interval To avoid quota being exhausted soon, type time interval for sending the SMS. 3. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 223 Display the name of this profile. It cannot be modified. Service Provider Type the website of the service provider. Type the URL string in the box under the filed of Service Provider. You have to contact your SMS provider to obtain the exact URL string. Vigor2860 Series User’s Guide...
Page 224 Each item is explained as follows: Item Description Set to Factory Default Clear all of the settings and return to factory default settings. Index Display the profile number that you can configure. Profile Display the name for such mail server profile. Vigor2860 Series User’s Guide...
Page 225 Username – Type a name for authentication. The maximum length of the name you can set is 31 characters. Password – Type a password for authentication. The maximum length of the password you can set is 31 Vigor2860 Series User’s Guide...
Page 226: Notification Object
You can set an object with different monitoring situation. To set a new profile, please do the steps listed below: 1. Open Object Setting>>Notification Object, and click the number (e.g., #1) under Index column for configuration in details. Vigor2860 Series User’s Guide...
Page 227 Display the types that will be monitored. Display the status for the category. You can check the box Status you want to be monitored. 3. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 228: Csm Profile
Please note that this action will not introduce any delay in your Web surfing because each of multiple load balanced database servers can handle millions of requests for categorization. Note: The priority of URL Content Filter is higher than Web Content Filter. Vigor2860 Series User’s Guide...
Page 229: App Enforcement Profile
Click the number under Index column for settings in detail. There are four tabs IM, P2P, Protocol and Misc displayed on this page. Each tab will bring out different items that you can choose to disallow people using. Vigor2860 Series User’s Guide...
Page 230 Pass – Pass all the packets with the settings configured in this page. The profiles configured here can be applied in the Firewall>>General Setup and Firewall>>Filter Setup pages as the standard for the host(s) to follow. Vigor2860 Series User’s Guide...
Page 231 Below shows the items which are categorized under IM. The items categorized under P2P ----- Vigor2860 Series User’s Guide...
Page 232: Url Content Filter Profile
URL such as “www.sex.com” or “sex.com”. Also the Vigor router will discard any request that tries to retrieve the malicious code. Click CSM and click URL Content Filter Profile to open the profile setting page. Vigor2860 Series User’s Guide...
Page 233 Administration Message. You can set eight profiles as URL content filter. Simply click the index number under Profile to open the following web page. Vigor2860 Series User’s Guide...
Page 234 Control and Web Feature below, such function can determine the priority for the actions executed. For this one, the router will process the packages with the conditions set below for web feature first, then URL second. Vigor2860 Series User’s Guide...
Page 235 In addition, the maximal length of each frame is 32-character long. After specifying keywords, the Vigor router will decline the connection request to the website whose URL string matched to any user-defined keyword. It Vigor2860 Series User’s Guide...
Page 236 Upload – Check the box to block the file upload by way of web page. File Extension Profile – Choose one of the profiles that you configured in Object Setting>> File Extension Objects previously for passing or blocking the file downloading. Vigor2860 Series User’s Guide...
Page 237: Web Content Filter Profile
Note: If you have used Service Activation Wizard to activate WCF service, you can skip this section. WCF adopts the mechanism developed and offered by certain service provider (e.g., DrayTek). No matter activating WCF feature or getting a new license for web content filter, you have to click Activate to satisfy your request.
Page 238 Setup Test Server It is recommended for you to use the default setting, auto-selected. Click it to open http://myvigor.draytek.com for searching Find more another qualified and suitable server. Test a site to verify Click this link to do the verification.
Page 239 If you have and activate another web content filter license, the items will be changed simultaneously. All of the configuration made for web content filter will be deleted automatically. Therefore, please backup your data before you change the web content filter license. Vigor2860 Series User’s Guide...
Page 240 Block – Only the log about Block will be recorded in Syslog. All – All the actions (Pass and Block) will be recorded in Syslog. After finishing all the settings, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 241: Dns Filter
Pass – Only the log about Pass will be recorded in Syslog. Block – Only the log about Block will be recorded in Syslog. All – All the actions (Pass and Block) will be recorded in Syslog. Vigor2860 Series User’s Guide...
Page 242: Appe Support List
After finishing all the settings, please click OK to save the configuration. Such page lists all the information (name, version and note) about IM, P2P, Protocol and others applications that Vigor router supports for APPE function. Vigor2860 Series User’s Guide...
Page 243: Bandwidth Management
To activate the function of limit session, simply click Enable and set the default session limit. Available settings are explained as follows: Item Description Session Limit Enable - Click this button to activate the function of limit session. Disable - Click this button to close the function of limit session. Vigor2860 Series User’s Guide...
Page 244 All the schedules can be set previously in Application >> Schedule web page and you can use the number that you have set in that web page. After finishing all the settings, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 245: Bandwidth Limit
Disable - Click this button to close the function of limit bandwidth. Default TX limit - Define the default speed of the upstream for each computer in LAN. Default RX limit - Define the default speed of the Vigor2860 Series User’s Guide...
Page 246 Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Application >> Schedule web page and you can use the number that you have set in that web page. Vigor2860 Series User’s Guide...
Page 247: Quality Of Service
The core routers in the backbone will do the same checking before executing treatments in order to ensure service-level consistency throughout the whole QoS-enabled network. Vigor2860 Series User’s Guide...
Page 248 Index – Display the class number that you can edit. Class Rule Name – Display the name of the class. Rule – Allow to configure detailed settings for the selected Class. Service Type – Allow to configure detailed settings for the Vigor2860 Series User’s Guide...
Page 249 There are four queues allowed for QoS control. The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. Yet, the last one is reserved for the packets which are not suitable for the user-defined class rules. Vigor2860 Series User’s Guide...
Page 250 UDP application traffic such as streaming video will exhaust lots of bandwidth. Outbound TCP ACK The difference in bandwidth between download and upload Prioritize are great in ADSL2+ environment. For the download speed might be impacted by the uploading TCP ACK, you can Vigor2860 Series User’s Guide...
Page 251 Edit link of that one. After you click the Edit link, you will see the following page. Now you can define the name for that Class. In this case, “Test” is used as the name of Class Index #1. Vigor2860 Series User’s Guide...
Page 252 QoS control. It can also be edited. You can choose the predefined service type from the Service Type drop down list. Those types are predefined in factory. Simply choose the one that you want for using by current QoS. Vigor2860 Series User’s Guide...
Page 253 Edit to open the rule edit page for modification. To add a new service type, edit or delete an existed service type, please click the Edit link under Service Type field. After you click the Edit link, you will see the following page. Vigor2860 Series User’s Guide...
Page 254 After finishing all the settings here, please click OK to save the configuration. By the way, you can set up to 10 service types. If you want to edit/delete an existed service type, please select the radio button of that one and click Edit/Edit for modification. Vigor2860 Series User’s Guide...
Page 255 For example, in the following illustration, the VoIP packets in LAN go into Vigor router without any header. However, when they go forward to the Server on ISP through Vigor router, all of the packets are tagged with AF (configured in Bandwidth >>QoS>>Class) automatically. Vigor2860 Series User’s Guide...
Page 256: Applications
Enable the Function and Add a Dynamic DNS Account Assume you have a registered domain name from the DDNS provider, say hostname.dyndns.org, and an account with username: test and password: test. In the DDNS setup menu, check Enable Dynamic DNS Setup. Vigor2860 Series User’s Guide...
Page 257 Enable Dynamic Check this box to enable the current account. If you did DNS Account check the box, you will see a check mark appeared on the Active column of the previous web page in step 2). Vigor2860 Series User’s Guide...
Page 258 IP before DDNS update takes place. Click OK button to activate the settings. You will see your setting has been saved. Disable the Function and Clear all Dynamic DNS Accounts Vigor2860 Series User’s Guide...
Page 259: Lan Dns
DNS server in LAN. With such feature, the user can configure some services (such as ftp, www or database) with domain name which is easy to be accessed. Simply click Application>>LAN DNS to open the following page. Vigor2860 Series User’s Guide...
Page 260 The detailed settings with index 1 are shown below. Available settings are explained as follows: Item Description Enable Check this box to enable such profile. Profile Type a name for such profile. Domain Name Type the domain name for such profile. Vigor2860 Series User’s Guide...
Page 261 IP address for the DNS query coming from different LAN PC. Delete – Click it to remove an existed IP address on the list. Click OK button to save the settings. A new LAN DNS profile has been created. Vigor2860 Series User’s Guide...
Page 262: Schedule
You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN and Remote Access >> LAN-to-LAN settings. To add a schedule: Click any index, say Index No. 1. The detailed settings of the call schedule with index 1 are shown below. Vigor2860 Series User’s Guide...
Page 263 Click OK button to save the settings. Example Suppose you want to control the PPPoE Internet access connection to be always on (Force On) from 9:00 to 18:00 for whole week. Other time the Internet access connection should be disconnected (Force Down). Vigor2860 Series User’s Guide...
Page 264: Radius
The RADIUS server and client share a secret that is used to authenticate the messages sent between them. Both sides must be configured to use the same shared secret. The maximum length of the shared secret you can set is 36 characters. Vigor2860 Series User’s Guide...
Page 265: Ldap /Active Directory Setup
LDAP to search or list the directory object, inquire or manage the active directory. This page allows you to enable the function and specify general settings for LDAP server. Vigor2860 Series User’s Guide...
Page 266 Type this setting if Regular Mode is selected as Bind Type. Regular Password Specify a password if Regular Mode is selected as Bind Type. After finished the above settings, click OK button to save the settings. Vigor2860 Series User’s Guide...
Page 267 Type a name for such profile. The length of the use name is limited to 19 characters. Common Name Type or edit the common name identifier for the LDAP server. Identifier The common name identifier for most LDAP server is “cn”. Vigor2860 Series User’s Guide...
Page 268 After finished the above settings, click OK to save and exit this page. A new profile has been created. For detailed information about LDAP application, refer to section 4.7 How to Implement the AD/LDAP Authentication for User Management? Vigor2860 Series User’s Guide...
Page 269: Universal Plug And Play
The NAT Traversal of UPnP enables the multimedia features of your applications to operate. This has to manually set up port mappings or use other similar methods. The screenshots below show examples of this facility. Vigor2860 Series User’s Guide...
Page 270 Some Microsoft operating systems have found out the UPnP weaknesses and hence you need to ensure that you have applied the latest service packs and patches.  Non-privileged users can control some router functions, including removing and adding port mappings. Vigor2860 Series User’s Guide...
Page 271: Igmp
This field displays the ID port for the multicast group. The available range for IGMP starts from 224.0.0.0 to 239.255.255.254. P1 to P6 It indicates the LAN port used for the multicast group. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 272: Wake On Lan
MAC Address Type any one of the MAC address of the bound PCs. Wake Up Click this button to wake up the selected IP. See the following figure. The result will be shown on the box. Vigor2860 Series User’s Guide...
Page 273: Sms / Mail Alert Service
Available settings are explained as follows: Item Description Index Check the box to enable such profile. SMS Provider Use the drop down list to choose SMS service provider. You can click SMS Provider link to define the SMS server. Vigor2860 Series User’s Guide...
Page 274 Use the drop down list to choose a message profile. The recipient will get the content stated in the message profile. You can click the Notify Profile link to define the content of the mail message. Vigor2860 Series User’s Guide...
Page 275: Bonjour
Below shows an example for applying the bonjour feature that Vigor router can be used as the FTP server. 1. Here, we use Firefox and DNSSD to discover the service in such case. Therefore, just ensure the Bonjour client program and DNSSD for Firefox have been installed on the computer. Vigor2860 Series User’s Guide...
Page 276 (DNSSD) and see the following results. 3. Open System Maintenance>>Management. Type a name (e.g., Dray_2925) as the Router Name and click OK. 4. Next, open Applications>>Bonjour. Check the service that you want to use via Bonjour. Vigor2860 Series User’s Guide...
Page 277 Vigor router (based on Bonjour protocol) is ready to be used as a printer server, FTP server, SSH Server, Telnet Server, and HTTP Server. 6. Now, any page or document can be printed out through Vigor router (installed with a printer). Vigor2860 Series User’s Guide...
Page 278: Vpn And Remote Access
LAN, you should disable the VPN service of Vigor Router to allow VPN tunnel pass through, as well as the appropriate NAT settings, such as DMZ or open port. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 279: Ppp General Setup
In addition, the remote dial-in user will use 40-bit to perform encryption prior to using 128-bit for encryption. In other words, if 128-bit MPPE encryption method is not available, then 40-bit encryption scheme will Vigor2860 Series User’s Guide...
Page 280: Ipsec General Setup
It can just apply to local packet, e.g., L2TP over IPsec. The Tunnel mode will not only add the AH/ESP payload but also use a new IP header (Tunneled IP header) to encapsulate the whole original IP packet. Vigor2860 Series User’s Guide...
Page 281 High (ESP) - Encapsulating Security Payload (ESP) means payload (data) will be encrypted and authenticated. You may select encryption algorithm from Data Encryption Standard (DES), Triple DES (3DES), and AES. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 282: Ipsec Peer Identity
Click each index to edit one peer digital certificate. There are three security levels of digital signature authentication: Fill each necessary field to authenticate the remote peer. The following explanation will guide you to fill all the necessary fields. Vigor2860 Series User’s Guide...
Page 283 The field includes Country (C), State (ST), Location (L), Organization (O), Organization Unit (OU), Common Name (CN), and Email (E). After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 284: Remote Dial-In User
Check the box to activate such profile. Active Status Display the access state of the specific dial-in user. The symbol V and X represent the specific dial-in user to be active and inactive, respectively. Vigor2860 Series User’s Guide...
Page 285 L2TP alone or with IPsec. Select from below:  None - Do not apply the IPsec policy. Accordingly, the VPN connection employed the L2TP without IPsec policy can be viewed as one pure L2TP Vigor2860 Series User’s Guide...
Page 286 L2TP with IPsec Policy when you specify the IP address of the remote node. The only exception is Digital Signature (X.509) can be set when you select IPsec tunnel either with or without specify the IP address of the remote node. Vigor2860 Series User’s Guide...
Page 287: Lan To Lan
L2TP by itself or over IPsec) and corresponding security methods, etc. The router supports up to 32 VPN tunnels simultaneously. The following figure shows the summary table. The following figure shows the summary table according to the item (All/Trunk) selected for View. Vigor2860 Series User’s Guide...
Page 288 The following shows profiles joined into VPN Load Balance and VPN Backup mechanism. If there is no profile joined yet, this page will be shown as follows: Vigor2860 Series User’s Guide...
Page 289 LAN-to-LAN profile includes 4 subgroups. If the fields gray out, it means you may leave it untouched. The following explanations will guide you to fill all the necessary fields. For the web page is too long, we divide the page into several sections for explanation. Vigor2860 Series User’s Guide...
Page 290 Pass – Click this button to let multicast packets pass through the router.  Block – This is default setting. Click this button to let multicast packets be blocked by the router. Call Direction - Specify the allowed call direction of this LAN-to-LAN profile. Vigor2860 Series User’s Guide...
Page 291 PPTP or L2TP with or without IPsec policy above. The length of the name is limited to 49 characters. Password - This field is applicable when you select PPTP or L2TP with or without IPsec policy above. The length of Vigor2860 Series User’s Guide...
Page 292 MD5 or SHA-1 authentication algorithm.  AES without Authentication-Use AES encryption algorithm and not apply any authentication scheme.  AES with Authentication-Use AES encryption algorithm and apply MD5 or SHA-1 authentication algorithm. Vigor2860 Series User’s Guide...
Page 293 Index(1-15) - Set the wireless LAN to work at certain time interval only. You may choose up to 4 schedules out of the 15 schedules pre-defined in Applications >> Schedule setup. The default setting of this field is blank and the function will always work. Vigor2860 Series User’s Guide...
Page 294 L2TP without IPsec policy can be viewed as one pure L2TP connection.  Nice to Have - Apply the IPsec policy first, if it is applicable during negotiation. Otherwise, the dial-in VPN connection becomes one pure L2TP Vigor2860 Series User’s Guide...
Page 295 IPsec Tunnels and L2TP with IPsec Policy when you specify the remote node.  Medium- Authentication Header (AH) means data will be authenticated, but not be encrypted. By default, this option is active.  High- Encapsulating Security Payload (ESP) means Vigor2860 Series User’s Guide...
Page 296 More - Add a static route to direct all traffic destined to more Remote Network IP Addresses/ Remote Network Mask through the VPN connection. This is usually used when you find there are several subnets behind the remote VPN router. Vigor2860 Series User’s Guide...
Page 297 IP, please choose NAT, otherwise choose Route. Change default route to this VPN tunnel - Check this box to change the default route with this VPN tunnel. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 298: Vpn Trunk Management
VPN Tunnels disconnected. Users do not need to reconnect with setting TCP/UDP Service Port again. The VPN Load Balance function can keep the transmission for internal data on tunnel stably Vigor2860 Series User’s Guide...
Page 299 Type - Display the connection type for that profile, such as IPsec, PPTP, L2TP, L2TP over IPsec (NICE), L2TP over IPsec(MUST) and so on. Member2 - Display the dial-out profile selected from the Member2 drop down list below. Vigor2860 Series User’s Guide...
Page 300 IPsec(MUST) and so on. Member2 - Display the dial-out profile selected from the Member2 drop down list below. Advanced – This button is only available when there is one or more profiles created in this page. Vigor2860 Series User’s Guide...
Page 301 The corresponding members (LAN-to-LAN profiles) grouped in such new VPN TRUNK – VPN Backup mechanism profile will be locked. The profiles in LAN-to-LAN will be displayed in red. VPN TRUNK – VPN Load Balance mechanism profile will be locked. The Vigor2860 Series User’s Guide...
Page 302 Enable radio button; type a name for such profile (e.g., 071023); choose one of the LAN-to-LAN profiles from Member1 drop down list; choose one of the LAN-to-LAN profiles from Member2 drop down list; and click Add at last. Vigor2860 Series User’s Guide...
Page 303 Peer GRE IP. See the following graphic for an example. Later, on peer side (as VPN Client): please type 192.168.50.100 in the field of My GRE IP and type IP address of the server (192.168.50.200) in the field of Peer GRE IP. Vigor2860 Series User’s Guide...
Page 304 (10Mbps/100Mbps) and switch with fixed value ratio (3:7) for packet transmission. If the transmission rate for packets on both sides of the tunnels is the same, the value of Auto Weighted should be 5.5. According to Speed Ratio allows Vigor2860 Series User’s Guide...
Page 305 Port also fits the number here, such binding tunnel table can be established. Other means when the source IP, destination IP, destination port and fragment conditions match with the settings specified here with different TCP Service Port/UDP Service Port/ICMP/IGMP, such binding tunnel table can be established. Vigor2860 Series User’s Guide...
Page 306 Type Binding Src IP range (Start and End) and Binding Des IP range (Start and End). Choose TCP/UDP, IGMP/ICMP or Other as Binding Protocol. Detailed Settings for Advanced Backup Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 307: Connection Management
General Mode - This filed displays the profile configured in LAN-to-LAN (with Index number and VPN Server IP address). The VPN connection built by General Mode does not support VPN backup function. Backup Mode - This filed displays the profile name saved Vigor2860 Series User’s Guide...
Page 308: Certificate Management
Remember to adjust the time of Vigor router before using the certificate so that you can get the correct valid period of certificate. Below shows the menu items for Certificate Management. Available settings are explained as follows: Item Description Generate Click this button to open Generate Certificate Request Vigor2860 Series User’s Guide...
Page 309 (used for identifying different certificate), subject alternative name type and relational settings for subject name. Then click GENERATE again. Note: Please be noted that “Common Name” must be configured with rotuer’s WAN IP or domain name. Vigor2860 Series User’s Guide...
Page 310 Upload Local Certificate It allows users to import the certificate which is generated by vigor router and signed by CA server. If you have done well in certificate generation, the Status of the certificate will be shown as “OK”. Vigor2860 Series User’s Guide...
Page 311 Click this button to view the detailed settings for certificate request. Note: You have to copy the certificate request information from above window. Next, access your CA server and enter the page of certificate request, copy the information into Vigor2860 Series User’s Guide...
Page 312: Trusted Ca Certificate
For viewing each trusted CA certificate, click View to open the certificate detail information window. If you want to delete a CA certificate, choose the one and click Delete to remove all the certificate information. Vigor2860 Series User’s Guide...
Page 313: Certificate Backup
Backup on the following screen to save them. If you want to set encryption password for these certificates, please type characters in both fields of Encrypt password and Retype password. Also, you can use Restore to retrieve these two settings to the router whenever you want. Vigor2860 Series User’s Guide...
Page 314: Central Vpn Management
Note: Such menu can manage the CPE connected through WAN only. This page is used to configure settings which will be used by the clients to register to such Vigor router. Click General Settings and IPsec VPN Settings to configure the basic settings for CVM mechanism. Vigor2860 Series User’s Guide...
Page 315 Type the password for the user. Password Polling Interval Type the time value (unit is second). The range is from 60 ~ 86400. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 316 Encryption Type Choose one of the selections as the encryption type. Local Subnet Type the IP address and subnet mask of local host. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 317: Cpe Management
All the CPEs managed by Vigor2860 series can be seen with icons from this page Before using such feature, make sure the CVM port has been enabled and configured properly. This page allows you to manage the CPEs connected to Vigor2860 series.
Page 318 Unmanaged Devices List Any device (CPE) which follows the standard of TR-069 can be configured and can be detected by Vigor2860 series automatically. Only eight remote devices can be managed by Vigor2860 at one time. Therefore, other remote devices detected by Vigor2860 series might be displayed in such field.
Page 319 - When a USB disk connects to Vigor2860, the disk usage and the disk capacity will be displayed in such field. - When there is no USB disk connecting to Vigor2860, such message will be displayed in this field. Vigor2860 Series User’s Guide...
Page 320 Follow the steps below to create a new maintenance profile. Click any index number link, e.g., Index 1. The Maintenance dialog appears. Available parameters are listed as follows: Item Description Profile Name Type the name of the maintenance profile. Vigor2860 Series User’s Guide...
Page 321 Check it to enable such profile. Device Name The drop down list will display all the CPE devices detected by Vigor2860 series. Choose the one which will be applied with such new created profile. Action Type There are three actions for you to choose for such profile.
Page 322 To display the location of the managed CPE with a bird’s eye view, open Central VPN Management>>CPE Management and click the tab of Google Map. Vigor2860 Series User’s Guide...
Page 323: Vpn Management
An easy and quick method is offered to configure VPN settings for building VPN connection automatically between Vigor2860 series (treated as VPN server) and other Vigor router (treated as CPE device, i.e., VPN client).  Page without CPE connected ...
Page 324: Log & Alert
Display the number of the received rate. UP Time Display the connection time of such VPN. & & This page offers brief information to identify the CPE connected to Vigor2860 series. Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 325 Vigor2860 series. Action Type Display the action that Vigor2860 series will perform for the managed CPE. Message Display the information for each event. The Alert page offers brief information to identify the CPE connected to Vigor2860 series. Vigor2860 Series User’s Guide...
Page 326: Central Ap Management
In which, 0/64 means that up to 64 clients are allowed to connect to the access point. But, now no one connects to the access point. The number displayed on the left side means 2.4GHz; and the Vigor2860 Series User’s Guide...
Page 327: Wlan Profile
Display the security mode selected by such wireless profile. Multi-SSID Enable means multiple SSIDs (more than one) are active. Disable means only SSID1 is active. WLAN ACL Display the name of the access control list. Rate Control Display the upload and/or download transmission rate. Vigor2860 Series User’s Guide...
Page 328 Simply choose the device you want from Existing Device field. Click >> to move the device to Selected Device field. Then, click OK. The selected WLAN profile will be applied to the selected access point immediately. Later the access point will reboot. Vigor2860 Series User’s Guide...
Page 329 1. Check the box on the left side of the selected profile. 2. Click the Edit button to display the following page. Vigor2860 Series User’s Guide...
Page 330 3. After finished the general settings configuration, click Next to open the following page for 2.4G wireless security settings. Vigor2860 Series User’s Guide...
Page 331 4. After finished the above web page configuration, click Next to open the following page for 5G wireless security settings. 5. When you finished the above web page configuration, click Finish to exit and return to the first page. The modified WLAN profile will be shown on the web page. Vigor2860 Series User’s Guide...
Page 332: Ap Maintenance
Simply click << or >> to move the device(s) between Select Device and Selected Device areas. Display the access points that will be applied by such function Selected Device after clicking OK. After finishing all the settings here, please click OK to perform the action. Vigor2860 Series User’s Guide...
Page 333: Traffic Graph
The horizontal axis represents time; the vertical axis represents the transmission rate (in kbps). It displays the access point scanned by Vigor router. In which, the APs will be classified with friendly APs, rogue APs and unknown APs in different colors. Below shows the detected APs by clicking OK. Vigor2860 Series User’s Guide...
Page 334 Use the drop down list to specify the time to refresh the web page. Refresh Click such link to refresh the web page immediately. Display the channel used by the detected access point. Display the SSID specified for the detected access point. SSID Vigor2860 Series User’s Guide...
Page 335 AP is friendly and which one is Rogue respectively. Follow the steps below to perform the classification of access points. 1. Click the radio button on one of the access points. In this case, DrayTek-LAN-A is selected. 2. Later, some options will appear on the bottom of the page.
Page 336 AP, simply choose the one and click Delete. Later, the page will refresh and the one will be classified as Unknown. 3. Click OK to save the settings. The following figure shows the APs classified and displayed in different colors. Vigor2860 Series User’s Guide...
Page 337: Load Balance
The purpose is to prevent lots of stations connecting to access point at the same time and causing traffic unbalanced. By Traffic – The operation of load balance will executed according to the traffic configuration in this page. Vigor2860 Series User’s Guide...
Page 338: Function Support List
Click the Client tab to list the AP management functions that the Access Points support under different firmware versions. Click the Server tab to list the AP management functions that Vigor router supports under different firmware versions. Vigor2860 Series User’s Guide...
Page 339: Voip
Then, both parties’ SIP proxies will forward the sequence of messages to caller to establish the session. If you both register to the same SIP Registrar, then it will be illustrated as below: Vigor2860 Series User’s Guide...
Page 340 QoS Assurance assists to assign high priority to voice traffic via Internet. You will always have the required inbound and outbound bandwidth that is prioritized exclusively for Voice traffic over Internet but you just get your data a little slower and it is tolerable for data traffic. Vigor2860 Series User’s Guide...
Page 341: Dialplan
Note: If the incoming or outgoing calls do not match any entry on the phonebook, the router will try to make the call "being protected". But, if the call ends up "unprotected"(e.g. peer side does not support ZRTP+SRTP), the router will not play out a warning message. Vigor2860 Series User’s Guide...
Page 342 Click any index number to display the dial plan setup page. Available settings are explained as follows: Item Description Enable Click this to enable this entry. Phone Number The speed-dial number of this index. This can be any Vigor2860 Series User’s Guide...
Page 343 Note: If the incoming or outgoing calls do not match any entry on the phonebook, the router will try to make the call "being protected". But, if the call ends up "unprotected"(e.g. peer side does not support ZRTP+SRTP), the router will not play out a warning message. Vigor2860 Series User’s Guide...
Page 344 886 will be deleted completely for the prefix number is set with 886. Replace - When you choose this mode, the OP number will be replaced by the prefix number for calling out through the specific VoIP interface. Take the above picture (Prefix Vigor2860 Series User’s Guide...
Page 345 Click the link to move the selected entry up or down. After finishing all the settings here, please click OK to save the configuration. Call barring is used to block phone calls coming from the one that is not welcomed. Vigor2860 Series User’s Guide...
Page 346 Unknown Domain or Block IP Address. Simply click the relational links to open the web page. For Block Anonymous – this function can block the incoming calls without caller ID on the interface (Phone port) specified in the following window. Such control also can be done based on preconfigured schedules. Vigor2860 Series User’s Guide...
Page 347 SIP accounts. Such control also can be done based on preconfigured schedules. For Block IP Address – this function can block incoming calls (through Phone port) coming from IP address. Such control also can be done based on preconfigured schedules. Vigor2860 Series User’s Guide...
Page 348 Dial the number typed in this field to forward all the incoming calls to the specified place while the phone is busy. Call Forward [No Dial the number typed in this field to forward all the incoming calls to the specified place while there is no Vigor2860 Series User’s Guide...
Page 349 PSTN number for dialing without passing through Internet. Check the Enable box to make the PSTN number available for dial whenever you need and type the number in the field of phone number for PSTN relay. Vigor2860 Series User’s Guide...
Page 350: Sip Accounts
As Vigor VoIP Router is turned on, it will first register with Registrar using AuthorizationUser@Domain/Realm. After that, your call will be bypassed by SIP Proxy to the destination using AccountName@Domain/Realm as identity. Note: Selection items for Ring Port will differ according to the router you have. Vigor2860 Series User’s Guide...
Page 351 SIP server successfully. – means the account is failed to register on SIP server. STUN Server Type in the IP address or domain of the STUN server. Type in the gateway IP address. External IP Vigor2860 Series User’s Guide...
Page 352 Some SIP server allows user to use VoIP function without registering. For such server, please check the box of Call without Registration. Choosing Auto is recommended. The system will select a proper way for your VoIP call. Vigor2860 Series User’s Guide...
Page 353 Manual – Choose this option if you want to specify an external IP address as the NAT transversal support. Nortel – If the soft-switch that you use supports Nortel solution, you can choose this option. Vigor2860 Series User’s Guide...
Page 354 Single Codec – If the box is checked, only the selected Codec will be applied. Packet Size The amount of data contained in a single packet. The default value is 20 ms, which means the data packet will contain 20 ms voice information. Vigor2860 Series User’s Guide...
Page 355: Phone Settings
Gain - Display the volume gain settings for Mic/Speaker that configured in the advanced settings page of Phone Index. Default SIP Account – “draytel_1” is the default SIP account. You can click the number below the Index field to Vigor2860 Series User’s Guide...
Page 356 The default value is 15000. RTP TOS – It decides the level of VoIP package. Use the drop down list to choose any one of them. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 357 Check this box to hide the caller ID on the display panel of the phone set. Call Waiting Check this box to invoke this function. A notice sound will appear to tell the user new phone call is waiting for your Vigor2860 Series User’s Guide...
Page 358 Available settings are explained as follows: Item Description Region Select the proper region which you are located. The common settings of Caller ID Type, Dial tone, Ringing tone, Busy tone and Congestion tone will be shown Vigor2860 Series User’s Guide...
Page 359 DTMF DTMF Mode – There are four DTMF modes for you to choose.  InBand - Choose this one then the Vigor will send the DTMF tone as audio directly when you press the Vigor2860 Series User’s Guide...
Page 360: Status
Description Refresh Seconds Specify the interval of refresh time to obtain the latest VoIP calling information. The information will update immediately when the Refresh button is clicked. Port It shows current connection status for Phone(s) ports. Vigor2860 Series User’s Guide...
Page 361 Accumulation for the times of in call. Out Calls Accumulation for the times of out call. Miss Calls Accumulation for the times of missing call. The volume of present call. Speaker Gain Display logs of VoIP calls. Vigor2860 Series User’s Guide...
Page 362: Wireless Lan(2.4Ghz/5Ghz)
SSID as identification, located channel etc. Vigor router supports four SSID settings for wireless connections. Each SSID can be defined with different name and download/upload rate for selecting by stations connected to the router wirelessly. Vigor2860 Series User’s Guide...
Page 363 The following sections explain setting for wireless LAN. Here we take menu items under Wireless LAN (2.4 GHz) as the examples. The differences for the settings between 2.4 GHz and 5 GHz will be pointed out. Vigor2860 Series User’s Guide...
Page 364: General Setup
Check the box to enable wireless function. Mode For 2.4GHz: At present, the router can connect to 11g Only, 11n Only(2.4 GHz), Mixed (11b+11g), Mixed (11g+11n), and Mixed (11b+11g+11n) stations simultaneously. Simply choose Mixed (11b+11g+11n) mode. Vigor2860 Series User’s Guide...
Page 365 (stations) with the same SSID not accessing for each other. VPN – Check this box to make the wireless clients (stations) with different VPN not accessing for each other. Rate Control It controls the data transmission rate through wireless Vigor2860 Series User’s Guide...
Page 366 You may choose up to 4 schedules out of the 15 schedules pre-defined in Applications >> Schedule setup. The default setting of this field is blank and the function will always work. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 367: Security
By clicking the Security Settings, a new web page will appear so that you could configure the settings of WPA and WEP. Available settings are explained as follows: Item Description Mode There are several modes provided for you to choose. Vigor2860 Series User’s Guide...
Page 368 0x, such as "0x321253abcde..."). 64-Bit - For 64 bits WEP key, either 5 ASCII characters, such as 12345 (or 10 hexadecimal digitals leading by 0x, such as 0x4142434445.) 128-Bit - For 128 bits WEP key, either 13 ASCII Vigor2860 Series User’s Guide...
Page 369: Access Control
Select to enable the MAC Address filter for wireless LAN Filter identified with SSID 1 to 4 respectively. All the clients (expressed by MAC addresses) listed in the box can be grouped under different wireless LAN. For example, they Vigor2860 Series User’s Guide...
Page 370: Wps
He/she only needs to press a button on wireless client, and WPS will connect for client and router automatically. There are two methods to do network connection through WPS between AP and Stations: pressing the Start PBC button or using PIN Code. Vigor2860 Series User’s Guide...
Page 371 For WPS is supported in WPA-PSK or WPA2-PSK mode, if you do not choose such mode in Wireless LAN>>Security, you will see the following message box. Please click OK and go back Wireless LAN>>Security to choose WPA-PSK or WPA2-PSK mode and access WPS again. Vigor2860 Series User’s Guide...
Page 372 Start PIN button. The WPS LED on the router will blink fast when WPS is in progress. It will return to normal condition after two minutes. (You need to setup WPS within two minutes) Vigor2860 Series User’s Guide...
Page 373: Wds
To meet the above requirement, two WDS modes are implemented in Vigor router. One is Bridge, the other is Repeater. Below shows the function of WDS-bridge interface: The application for the WDS-Repeater mode is depicted as below: Vigor2860 Series User’s Guide...
Page 374 Bridge 2 through WDS links. However, hosts connected to Bridge 1 CANNOT communicate with hosts connected to Bridge 3 through Bridge 2. Click WDS from Wireless LAN menu. The following page will be shown. Vigor2860 Series User’s Guide...
Page 375 Disable to cancel this function. It allows user to send “hello” message to peers. Yet, it is Status valid only when the peer also supports this function. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 376: Advanced Setting
If you choose auto as guard interval, the AP router will choose short guard interval (increasing the wireless performance) or long guard interval for data transmit based on the station capability. Vigor2860 Series User’s Guide...
Page 377 Vigor N61 wireless utility window, choose Enable for TxBURST on the tab of Option). Note: * means the real transmission rate depends on the environment of the network. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 378: Wmm Configuration
1 to 15. Be aware that CWMax value must be greater than CWMin or equals to CWMin value. Both values will influence the time delay for WMM accessing categories. The difference between AC_VI and AC_VO categories must be smaller; however, the difference Vigor2860 Series User’s Guide...
Page 379 “Check” the box means the AP router will not answer any response request for the transmitting packets. It will have better performance with lower reliability. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 380: Ap Discovery
AP’s MAC address on the bottom of the page and click Bridge or Repeater. Next, click Add to. Later, the MAC address of the AP will be added to Bridge or Repeater field of WDS settings page. Vigor2860 Series User’s Guide...
Page 381: Station List
WLAN station and click Add to Access Control below. Available settings are explained as follows: Item Description Refresh Click this button to refresh the status of station list. Click this button to add current typed MAC address into Access Control. Vigor2860 Series User’s Guide...
Page 382: Station Control
/reconnecting to Vigor router. Or, type the Reconnection Time duration manually when you choose User defined. All the wireless stations connecting to Vigor router by using Display All Station such SSID will be listed on Station Control List. Control List Vigor2860 Series User’s Guide...
Page 383: Ssl Vpn
Available settings are explained as follows: Item Description Port Such port is set for SSL VPN server. It will not affect the HTTPS Port configuration set in System Maintenance>>Management. In general, the default setting is 443. Vigor2860 Series User’s Guide...
Page 384: Ssl Web Proxy
Each item is explained as follows: Item Description Name Display the name of the profile that you create. Display the URL. Display current status (active or inactive) of such profile. Active Click number link under Index filed to set detailed configuration. Vigor2860 Series User’s Guide...
Page 385 In addition, users must execute “Connect” manually in SSL Client Portal page. SSL – if you choose such selection, web proxy over SSL will be applied for VPN. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 386: Ssl Application
VNC/RDP/SAMBA. Active Display current status (active or inactive) of the selected profile. To create a new SSL application profile: 1. Click number link under Index filed to set detailed configuration. 2. The following page will appear. Vigor2860 Series User’s Guide...
Page 387 (100%, 80%, 60%) for such application. Screen Size If you choose RDP, you have to choose the screen size for such application. Samba Path If you choose Samba, you have to specify the path of the Samba service. Vigor2860 Series User’s Guide...
Page 388 3. Enter the required information. 4. After finished the above settings, click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 389: User Account
With SSL VPN, Vigor2860 series let teleworkers have convenient and simple remote access to central site VPN. The teleworkers do not need to install any VPN software manually. From regular web browser, you can establish VPN connection back to your main office even in a guest network or web cafe.
Page 390 PPTP - Allow the remote dial-in user to make a PPTP VPN connection through the Internet. You should set the User Name and Password of remote dial-in user below. IPSec Tunnel - Allow the remote dial-in user to make an Vigor2860 Series User’s Guide...
Page 391 IPSec tunnel either with or without specify the IP address of the remote node. Pre-Shared Key - Check the box of Pre-Shared Key to invoke this function and type in the required characters (1-63) as the Vigor2860 Series User’s Guide...
Page 392 Local ID - Specify a local ID to be used for Dial-in setting in the LAN-to-LAN Profile setup. This item is optional and can be used only in IKE aggressive mode. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 393: User Group
Display the number of the client which connecting to FTP server. Name Display the name of the group profile. Click any index number link to open the following page for detailed configuration. Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 394 If the above three options are enabled, the system will do the authentication based on them in sequence. After finishing all the settings here, please click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 395: Online User Status
If you have finished the configuration of SSL Web Proxy (server), users can find out corresponding settings when they access into Draytek SSL VPN portal interface. Next, users can open SSL VPN>> Online Status to view logging status of SSL VPN.
Page 396: Usb Application
Vigor router, please make sure the memory format for the USB storage disk is FAT16 or FAT32. It is recommended for you to use FAT32 for viewing the filename completely (FAT16 cannot support long filename). Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 397: Usb User Management
USB storage disk must type the same username and password configured in this page. Before adding or modifying settings in this page, please insert a USB storage disk first. Otherwise, an error message will appear to warn you. Vigor2860 Series User’s Guide...
Page 398 USB storage disk. Note: When write protect status for the USB storage disk is ON, you cannot type any new folder name in this field. Only “/” can be used in such case. Vigor2860 Series User’s Guide...
Page 399: File Explorer
File Explorer offers an easy way for users to view and manage the content of USB storage disk connected on Vigor router. Available settings are explained as follows: Item Description Click this icon to refresh files list. Refresh Click this icon to return to the upper directory. Back Vigor2860 Series User’s Guide...
Page 400: Usb Device Status
Username It displays the username that user uses to login to the FTP server. When you insert USB storage disk into the Vigor router, the system will start to find out such device within several seconds. Vigor2860 Series User’s Guide...
Page 401: Temperature Sensor
A USB Thermometer is now available that complements your installed DrayTek router installations that will help you monitor the server or data communications room environment and notify you if the server room or data communications room is overheating. During summer in particular, it is important to ensure that your server or data communications equipment are not overheating due to cooling system failures.
Page 402 Enable Syslog Alarm - The temperature log will be recorded on Syslog if it is enabled. Upper temperature limit/Lower temperature limit - Type the upper limit and lower limit for the system to send out temperature alert. Below shows an example of temperature graph: Vigor2860 Series User’s Guide...
Page 403: Modem Support List
Such page provides the information about the brand name and model name of the USB modems which are supported by Vigor router. Vigor2860 Series User’s Guide...
Page 404: System Maintenance
Below shows the menu items for System Maintenance. The System Status provides basic network settings of Vigor router. It includes LAN and WAN interface information. Also, you could get the current running firmware version or firmware related information from this presentation. Vigor2860 Series User’s Guide...
Page 405 - Display the current status of DHCP server of the LAN interface - Display the assigned IP address of the primary DNS. Link Status - Display current connection status. MAC Address - Display the MAC address of the WAN Interface. Vigor2860 Series User’s Guide...
Page 406 Scope - Display the scope of IPv6 address. For example, IPv6 Link Local could only be used for direct IPv6 link. It can't be used for IPv6 internet. Internet Access Mode – Display the connection mode chosen for accessing into Internet. Vigor2860 Series User’s Guide...
Page 407: 397
Port – Sometimes, port conflict might be occurred. To solve such problem, you might change port number for CPE. Periodic Inform Settings The default setting is Enable. Please set interval time or schedule time for the router to send notification to CPE. Or Vigor2860 Series User’s Guide...
Page 408 CPE must send binding request to the server for the purpose of maintaining the binding in the Gateway. Please type a number as the maximum period. A value of “-1” indicates that no maximum period is specified. Vigor2860 Series User’s Guide...
Page 409: Administrator Password
This feature allows other user in LAN who can access into the web user interface with the same privilege of the administrator. Local User – Check the box to enable the local user configuration. Local User List – It displays the username of the local user. Vigor2860 Series User’s Guide...
Page 410 LDAP Profile Setup. LDAP Profile Setup – It allows you to create a new LDAP profile. When you click OK, the login window will appear. Please use the new password to access into the web user interface again. Vigor2860 Series User’s Guide...
Page 411: User Password
Below shows an example for accessing into User Operation with User Password. 1. Open System Maintenance>>User Password. 2. Check the box of Enable User Mode for simple web configuration to enable user mode operation. Type a new password in the field of New Password and click OK. Vigor2860 Series User’s Guide...
Page 412 4. Log out Vigor router web user interface by clicking the Logout button. 5. The following window will be open to ask for username and password. Type the new user password in the filed of Password and click Login. Vigor2860 Series User’s Guide...
Page 413: Login
At that moment, the background of the web page is blank and no heading will be displayed on the Login window. This page allows you to specify login URL and the heading on the Login window if you have such requirement. Vigor2860 Series User’s Guide...
Page 414 Enable Check this box to enable the login customization function. Login Page Title Type a brief description (e.g., Welcome to DrayTek) which will be shown on the heading of the login dialog. Welcome Message and Type words or sentences here. It will be displayed for bulletin message.
Page 415: Configuration Backup
Click Backup button to get into the following dialog. Click Save button to open another dialog for saving configuration as a file. In Save As dialog, the default filename is config.cfg. You could give it another name by yourself. Vigor2860 Series User’s Guide...
Page 416 Click Browse button to choose the correct configuration file for uploading to the router. Click Restore button and wait for few seconds, the following picture will tell you that the restoration procedure is successful. Vigor2860 Series User’s Guide...
Page 417: Syslog/Mail Alert
Mail Syslog – Check the box to recode the mail event on Syslog. Enable syslog message - Check the box listed on this web page to send the corresponding message of firewall, VPN, User Access, Call, WAN, Router/DSL information to Vigor2860 Series User’s Guide...
Page 418 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. Vigor2860 Series User’s Guide...
Page 419 Vigor2860 Series User’s Guide...
Page 420: Time And Date
Enable Daylight Saving Check the box to enable the daylight saving. Such feature is available for certain area. Automatically Update Select a time interval for updating from the NTP server. Interval Click OK to save these settings. Vigor2860 Series User’s Guide...
Page 421: Snmp
Set trap community by typing a proper name. The default setting is public. The maximum length of the text is limited to 23 characters. Notification Host IP Set the IPv4 address of the host that will receive the trap (IPv4) community. Vigor2860 Series User’s Guide...
Page 422 Privacy Algorithm Choose one of the methods listed below as the privacy algorithm. Privacy Password Type a password for privacy. The maximum length of the text is limited to 23 characters. Click OK to save these settings. Vigor2860 Series User’s Guide...
Page 423: Management
Available settings are explained as follows: Item Description Router Name Type in the router name provided by ISP. Default: Disable If it is enabled, the function of auto-logout for web user Auto-Logout interface will be disabled. Vigor2860 Series User’s Guide...
Page 424 CVM Access Control CVM Port – Check the box to enable such port setting. CVM SSL Port – Check the box to enable such port setting. After finished the above settings, click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 425 A maximum of three IPs/subnet masks is allowed. IPv6 Address /Prefix Length- Indicate the IP address(es) allowed to login to the router. After finished the above settings, click OK to save the configuration. Vigor2860 Series User’s Guide...
Page 426: Reboot System
Note: When the system pops up Reboot System web page after you configure web settings, please click Reboot Now to reboot your router for ensuring normal operation and preventing unexpected errors of the router in the future. Vigor2860 Series User’s Guide...
Page 427: Firmware Upgrade
Note that this example is running over Windows OS (Operating System). Download the newest firmware from DrayTek's web site or FTP site. The DrayTek web site is www.DrayTek.com (or local DrayTek's web site) and FTP site is ftp.DrayTek.com.
Page 428: Modem Code Upgrade
Click System Maintenance>>Activation to open the following page for accessing http://myvigor.draytek.com. Available settings are explained as follows: Item Description Activate via Interface Choose WAN interface used by such device for activating Web Content Filter. Activate The Activate link brings you accessing into Vigor2860 Series User’s Guide...
Page 429: Diagnostics
Below shows the successful activation of Web Content Filter: Diagnostic Tools provide a useful way to view or diagnose the status of your Vigor router. Below shows the menu items for Diagnostics. Vigor2860 Series User’s Guide...
Page 430: Dial-Out Triggering
(e.g., PPPoE) is triggered by a package sending from the source IP address. Available settings are explained as follows: Item Description Decoded Format It shows the source IP address (local), destination IP (remote) address, the protocol and length of the package. Refresh Click it to reload the page. Vigor2860 Series User’s Guide...
Page 431: Routing Table
Click Diagnostics and click Routing Table to open the web page. Available settings are explained as follows: Item Description Refresh Click it to reload the page. Vigor2860 Series User’s Guide...
Page 432: Arp Cache Table
IPv6 address. This information is helpful in diagnosing network problems, such as IP address conflicts, etc. Click Diagnostics and click IPv6 Neighbour Table to open the web page. Available settings are explained as follows: Item Description Vigor2860 Series User’s Guide...
Page 433: Dhcp Table
It displays the connection item number. IP Address It displays the IP address assigned by this router for specified PC. MAC Address It displays the MAC address for the specified PC that DHCP assigned IP address for it. Vigor2860 Series User’s Guide...
Page 434: Nat Sessions Table
It indicates the temporary port of the router used for NAT. Peer IP:Port It indicates the destination IP address and port of remote host. Interface It displays the representing number for different interface. Refresh Click it to reload the page. Vigor2860 Series User’s Guide...
Page 435: Ping Diagnosis
Use the drop down list to choose the destination that you want to ping. IP Address Type the IP address of the Host/IP that you want to ping. Ping IPv6 Address Type the IPv6 address that you want to ping. Vigor2860 Series User’s Guide...
Page 436: Data Flow Monitor
Flow Monitor. If not, a notification dialog box will appear to remind you enabling it. Click Diagnostics and click Data Flow Monitor to open the web page. You can click IP Address, TX rate, RX rate or Session link for arranging the data display. Available settings are explained as follows: Vigor2860 Series User’s Guide...
Page 437 Peak means the highest peak value detected by the router in data transmission. Speed means line speed specified in WAN>>General Setup. If you do not specify any rate at that page, here will display Auto for instead. Vigor2860 Series User’s Guide...
Page 438: Traffic Graph
WAN1/WAN2/WAN3/WAN4 Bandwidth chart, the numbers displayed on vertical axis represent the numbers of the transmitted and received packets in the past. For Sessions chart, the numbers displayed on vertical axis represent the numbers of the NAT sessions during the past. Vigor2860 Series User’s Guide...
Page 439: Trace Route
Run. The result of route trace will be shown on the screen. Available settings are explained as follows: Item Description IPv4 / IPv6 Click one of them to display corresponding information for Trace through Use the drop down list to choose the interface that you want Vigor2860 Series User’s Guide...
Page 440: Syslog Explorer
Click this link to save the data as a file. Refresh Click this link to refresh this page manually. Clear Click this link to clear information on this page. Display Mode There are two modes for you to choose. Vigor2860 Series User’s Guide...
Page 441: Tspc Status
Display the information for each event. IPv6 TSPC status web page could help you to diagnose the connection status of TSPC. If TSPC has configured properly, the router will display the following page when the user connects to tunnel broker successfully. Vigor2860 Series User’s Guide...
Page 442: External Devices
You can change the device name if required or remove the information for off-line device whenever you want. When you finished the configuration, click OK to save it. Note: Only DrayTek products can be detected by this function. Vigor2860 Series User’s Guide...
Page 443: Tutorials And Applications
TSPC, AICCU, DHCPv6 Client and Static IPv6. Access into the web user interface of Viogr2860. Open WAN>> Internet Access. Choose one of the WAN interfaces as the one supporting IPv6 service. Then, click the IPv6 button of the selected WAN. Vigor2860 Series User’s Guide...
Page 444 PPP – Dual Stack application, IPv4 and IPv6 services can be utilized at the same time Choose PPP and type the information for PPPoE of IPv4. Access into the setting page for IPv6 service, it is not necessary for you to configure anything. Vigor2860 Series User’s Guide...
Page 445 Click OK and open Online Status. If the connection is successful, you will get the IP address for IPv4 and IPv6 at the same time. Vigor2860 Series User’s Guide...
Page 446 Vigor2860 Series User’s Guide...
Page 447 (In the following figure, the TSPC information is obtained from http://gogo6.com/ after applied for the service.) Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 448 (In the following figure, the AICCU information is obtained from https://www.sixxs.net/main/ after applied for the service.) Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 449  DHCPv6 Client Choose DHCPv6 Client. Click one of the identity associations and type the IAID number. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 450  Static IPv6 Choose Static IPv6. Type IPv6 address, Prefix Length and Gateway Address. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 451 Choose 6in4 Static Tunnel. Type remote endpoint IPv4 address, 6in4 IPv6 Address, LAN Routed Prefix and Tunnel TTL. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 452  Choose 6rd. Type IPv4 Border Relay, IPv4 Mask Length, 6rd Prefix and 6rd Prefix Length. Click OK and open Online Status. If the connection is successful, the physical connection will be shows as follows: Vigor2860 Series User’s Guide...
Page 453 In the field of DHCPv6 Server Configuration, when DHCPv6 service is enabled, you can assign available IPv6 address for the client manually. Note: When both mechanisms are enabled, the client can determine which mechanism to be used (e.g., the default mechanism for Windows7 is RADVD). Vigor2860 Series User’s Guide...
Page 454 IPv4 IP and IPv6 IP services. Its IPv6 address is seen with a format of 2001:200:dff:fff1:216:3eff:feb1:44d7. After getting the above message, it means the IPv6 service has been activated successfully. Vigor2860 Series User’s Guide...
Page 455 If not, only a steady turtle will be seen. If you can see a turtle dancing on the screen, that means IPv6 service is ready for you to access and utilize. Vigor2860 Series User’s Guide...
Page 456: How Can I Get The Files From Usb Storage Device Connecting To Vigor Router
Plug the USB device to the USB port on the router. Make sure Disk Connected appears on the Connection Status as the figure shown below: Then, please open USB Application >> USB General Settings to enable Samba service. Vigor2860 Series User’s Guide...
Page 457 "user1" and assign authorities “Read”, “Write” and “List” to it. Click OK to save the configuration. Make sure the FTP service is running properly. Please open a browser and type ftp://192.168.1.1. Use the account "user1" to login. Vigor2860 Series User’s Guide...
Page 458 Now, users in LAN of Vigor2710 can access into the USB storage device by typing ftp://192.168.1.1 on any browser. They can add or remove files / directories, depending on the Access Rule for FTP account settings in USB Application >>USB User Management. Vigor2860 Series User’s Guide...
Page 459: How To Build A Lan-To-Lan Vpn Between Remote Office And Headquarter Via Ipsec Tunnel
(in this case, type VPN Server), and check the box of Enable This Profile. For Vigor router will be set as a server, the call direction shall be set as Dial-in and set 0 as Idle Timeout. Vigor2860 Series User’s Guide...
Page 460 (e.g., 218.242.130.19 in this case). Press the IKE Pre-Shared Key button to set the PSK; and select Medium (AH) or High (ESP) as the security method. Continue to navigate to the TCP/IP Network Settings for setting the LAN IP for remote side. Click OK to save the settings. Vigor2860 Series User’s Guide...
Page 461 (in this case, type VPN Client), and check the box of Enable This Profile. For such Vigor router will be set as a client, the call direction shall be set as Dial-out. Check the box of Always on for a permanent VPN connection. Vigor2860 Series User’s Guide...
Page 462 IKE Pre-Shared Key button to set the PSK; and select Medium (AH) or High (ESP) as the security method. Continue to navigate to the TCP/IP Network Settings for setting the LAN IP for the remote side. Click OK to save the settings. Vigor2860 Series User’s Guide...
Page 463: How To Optimize The Bandwidth Through Qos Technology
Internet connection line? The advanced bandwidth management technology-QoS (Quality of Service) helps you to well allocate the bandwidth upon your demand of Voice, Video, or Data transferring. Let's see how to get the optimum bandwidth per your request by using DrayTek Vigor router as below.
Page 464 Check the box of ACT. Click Edit to specify the local address. In the pop-up window, choose Range Address as the Address Type and type the start IP address and end IP address in relational fields. Click OK to save the settings and exit the window. Vigor2860 Series User’s Guide...
Page 465 Click OK again to save the settings. The class rule for VoIP has been set. Click OK to return to previous page. Do the same steps to add class rules for IPTV and Data/Email with IP addresses as shown below. Vigor2860 Series User’s Guide...
Page 466 VoIP, IPTV and Data/Email. 10. In the Setup page, check the box of Enable the QoS Control. Type 30, 50 and 15 in the boxes for VoIP, IPTV and Data/Email respectively. Check the box of Enable UDP Bandwidth Control. Vigor2860 Series User’s Guide...
Page 467 11. Click OK to save the settings. The class rules for WAN1 are defined as shown below. Vigor2860 Series User’s Guide...
Page 468: Qos Setting Example
Skype in the restroom. Go to Bandwidth Management>>Quality of Service. Click Setup link of WAN(1/2/3). Make sure the QoS Control on the left corner is checked. And select BOTH in Direction. Set Inbound/Outbound bandwidth. Vigor2860 Series User’s Guide...
Page 469 “E-mail” for Class 1. Click OK to save the settings. Click the Setup link for WAN2. The user can set reserved bandwidth (e.g., 25%) for E-mail using protocol POP3 and SMTP. Click OK to save the settings. Vigor2860 Series User’s Guide...
Page 470 Return to previous page. Enter the Name of Index Class 2 by clicking Edit link. In this index, the user will set reserved bandwidth for HTTPS. And click OK. Click Setup link for WAN2. Vigor2860 Series User’s Guide...
Page 471 Class Name of Index 3. In this index, he will set reserved bandwidth for 1 VPN tunnel. 10. Click Edit for Class 3 to open a new window. In this index, the user will set reserved bandwidth for VPN. Vigor2860 Series User’s Guide...
Page 472 11. Click Add to open the following window. Check the ACT box, first. 12. Then click Edit of Local Address to set a worker’s subnet address. Click Edit of Remote Address to set headquarter’s IP address. Leave other fields and click OK. Vigor2860 Series User’s Guide...
Page 473: How To Implement The Ldap/Ad Authentication For User Management
Create LDAP server profiles. Click the Active Directory /LDAP tab to open the profile web page and click any one of the index number link. If we have two groups “RD1” and “SHRD” on LDAP server, we can configure two LDAP server profiles with different Group Distinguished Name. Vigor2860 Series User’s Guide...
Page 474 Click OK to save the settings above. Open User Management>>General Setup. Select User-Based as the Mode option. Vigor2860 Series User’s Guide...
Page 475 Then open VPN and Remote Access>>PPP General Setup to check the profile(s) that will be authenticated with LDAP server. After above configurations, users belong to either “rd1” or “shrd” group can access Internet after inputting their credentials on LDAP server. Vigor2860 Series User’s Guide...
Page 476: How To Use Landing
Landing Page is a special feature configured under User Management. It can specify the message, content to be seen or specify which website to be accessed into when users try to access into the Internet by passing the authentication. Here, we take Vigor2860 series router as an example.
Page 477 Open any browser (e.g., FireFox, Internet Explorer). The logging page will appear and asks for username and password. Please type the correct username and password. Click Login. If the logging is successful, you will see the message of Login Success from the browser you use. Vigor2860 Series User’s Guide...
Page 478 Next, enable the Landing Page function. Open User Management -> User Profile and click one of the index number (e.g., index number 3) links. In the following page, check the box of Landing page and click OK to save the settings. Vigor2860 Series User’s Guide...
Page 479 Open any browser (e.g., FireFox, Internet Explorer). The logging page will appear and asks for username and password. Please type the correct username and password. Click Login. If the logging is successful, you will be directed into the website of www.draytek.com. Vigor2860 Series User’s Guide...
Page 480: How To Send A Notification To Specified Phone Number Via Sms Service In Wan Disconnection
Choose any index number (e.g., Index 1 in this case) to configure the SMS Provider setting. In the following page, type the username and password and set the quota that the router can send the message out. Vigor2860 Series User’s Guide...
Page 481 Choose any index number (e.g., Index 1 in this case) to configure conditions for sending the SMS. In the following page, type the name of the profile and check the Disconnected and Reconnected boxes for WAN to work in concert with the topic of this paper. Vigor2860 Series User’s Guide...
Page 482 Click OK to save the settings. Later, if one of the WAN connections fails in your router, the system will send out SMS to the phone number specified. If the router has only one WAN interface, the system will send out SMS to the phone number while reconnecting the WAN interface successfully. Vigor2860 Series User’s Guide...
Page 483 URL string of the SMS provider and type the username and password. After clicking OK, the new added SMS provider will be added and will be available for you to specify for sending SMS out. Vigor2860 Series User’s Guide...
Page 484: How To Create An Account For Myvigor
The website of MyVigor (a server located on http://myvigor.draytek.com) provides several useful services (such as Anti-Spam, Web Content Filter, Anti-Intrusion, and etc.) to filtering the web pages for the sake of protecting your system. To access into MyVigor for getting more information, please create an account for MyVigor.
Page 485 2. Click the Activate link. A login page for MyVigor web site will pop up automatically. 3. Click the link of Create an account now. 4. Check to confirm that you accept the Agreement and click Accept. Vigor2860 Series User’s Guide...
Page 486 5. Type your personal information in this page and then click Continue. 6. Choose proper selection for your computer and click Continue. Vigor2860 Series User’s Guide...
Page 487 8. Check to see the confirmation email with the title of Letter from myvigor.draytek.com. 9. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2860 Series User’s Guide...
Page 488: Create An Account Via Myvigor Web Site
11. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. 1. Access into http://myvigor.draytek.com. Find the line of Not registered yet?. Then, click the link Click here! to access into next page.
Page 489 2. Check to confirm that you accept the Agreement and click Accept. 3. Type your personal information in this page and then click Continue. 4. Choose proper selection for your computer and click Continue. Vigor2860 Series User’s Guide...
Page 490 6. Check to see the confirmation email with the title of Letter from myvigor.draytek.com. 7. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2860 Series User’s Guide...
Page 491 UserName and Password. Then type the code in the box of Auth Code according to the value displayed on the right side of it. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. Vigor2860 Series User’s Guide...
Page 492: How To Setup Address Mapping
We will take an example to introduce how to make use of this feature. Log into the web user interface of Vigor2860. Open WAN>>Internet Access. For WAN1, choose MPoA/Static or Dynamic IP as the Access Mode. Vigor2860 Series User’s Guide...
Page 493 WAN IP address as 202.211.100.10. Click the WAN IP Alias button to configure the other P address which is 202.211.100.11. Make sure Join IP NAT Pool is not checked. Click OK to save the settings. Vigor2860 Series User’s Guide...
Page 494 After finished configuration for WAN1, open Load-Balance/Route Policy. Click Index number 1 and 2 to configure the details. After finished the settings, click OK to save the settings respectively. Vigor2860 Series User’s Guide...
Page 495 Upon completing the above configuration, you have specified the outgoing IP address(es) for some specific computers. Now, you bind some specific computers to some WAN IP alias for outgoing traffic. Vigor2860 Series User’s Guide...
Page 496: How To Configure Certain Computers Accessing To Internet
Firewall>>Filter Setup is used as the default setting, we has to create a new rule starting from Filter Rule 2 of Set 2. Access into the web user interface of Vigor router. Open Firewall>>Filter Setup. Click the Set 2 link and choose the Filter Rule 2 button. Vigor2860 Series User’s Guide...
Page 497 Next, set another rule. Just open Firewall>>Filter Setup. Click the Set 2 link and choose the Filter Rule 3 button. Check the box of Check to enable the Filter Rule. Type the comments (e.g., open_ip). Click the Edit button for Source IP. Vigor2860 Series User’s Guide...
Page 498 End IP. Then, click OK to save the settings. The computers within the range can access into the Internet. Now, check the content of Source IP is correct or not. The action for Filter shall be set with Pass Immediately. Then, click OK to save the settings. Vigor2860 Series User’s Guide...
Page 499 Both filter rules have been created. Click OK. Now, all the settings are configured well. Only the computers with the IP addresses within 192.168.1.10 ~ 192.168.1.20 can access to Internet. Vigor2860 Series User’s Guide...
Page 500: How To Block Facebook Service Accessed By The Users Via Web Content Filter / Url Content Filter
*How to Register AI/AV/AS/WCF Service (Service Activation Wizard) (http://www.draytek.com/user/SupportFAQDetail.php?ID=1955) *How to Activate Anti-Virus/Anti-Intrusion/Anti-Spam Service (http://www.draytek.com/user/SupportFAQDetail.php?ID=286 ) How to use the Web Content Filter (WCF) (http://www.draytek.com/user/SupportFAQDetail.php?ID=1953) * What the Web Content Filter (WCF) license benefits are, (http://www.draytek.com/user/PdInfoDetail.php?Id=110) Vigor2860 Series User’s Guide...
Page 501 Open CSM >> Web Content Filter Profile to create a WCF profile. Check Social Networking with Action, Block. Enable this profile in Firewall>>General Setup>>Default Rule. Next time when someone accesses facebook via this router, the web page would be blocked and the following message would be displayed instead. Vigor2860 Series User’s Guide...
Page 502 In the field of Contents, please type facebook. Configure the settings as the following figure. Open CSM>>URL Content Filter Profile. Click an index number to open the setting page. Configure the settings as the following figure. When you finished the above steps, click OK. Then, open Firewall>>General Setup. Vigor2860 Series User’s Guide...
Page 503 B. Disallow users to play games on Facebook Open Object Settings>>Keyword Object. Click an index number to open the setting page. In the field of Contents, please type apps.facebook. Configure the settings as the following figure. Vigor2860 Series User’s Guide...
Page 504 When you finished the above steps, please open Firewall>>General Setup. Click the Default Rule tab. Choose the profile just configured from the drop down list in the field of URL Content Filter. Now, users cannot open any web page with the word “facebook” inside. Vigor2860 Series User’s Guide...
Page 505: Profile
Edit button being available. Then, click the Edit button. When the following configuration page appears, make the changes you want and check Apply to All APs. Then, click Next to access into the next page. Vigor2860 Series User’s Guide...
Page 506 “plug and play” and “zero-configuration”. The following page allows you to modify related settings for 2.4G SSID of managed AP. Make the changes you want for 2.4G SSID. Click Next for next page. Vigor2860 Series User’s Guide...
Page 507 AP. Continue to make any changes you want. After finished all of the changes, simply click Finish. Now, the AP (represented with AP800_00507F6EE4980) detected by Vigor router will be applied with the settings modified by Vigor router. Vigor2860 Series User’s Guide...
Page 508: Cvm Application - How To Manage The Cpe (Router) Through Vigor2860 Series
To manage CPEs through Vigor2860 series, you have to set URL on CPE first and set username and password for Vigor2860 series. For this section, we use Vigor2850 series as the example. All the CPE configuration will be done through Vigor2850 series.
Page 509 In the field of ACS Server, type the URL (IP address with port number) of Vigor2860 series and type the same Username and Password defined on the page of Central VPN Management>>General Setup in Vigor2860 series. Then, click Enable for CPE Client and then click OK to save the settings.
Page 510 Open WAN>>Internet Access. Use the drop down list of Access Mode on WAN1 to select MPoA (RFC1483/2684). Then, click Details Page. Click Specify an IP address. Type correct WAN IP address, subnet mask and gateway IP address for your CPE. Then click OK. Vigor2860 Series User’s Guide...
Page 511 Note: Reboot the CPE device and re-log into Vigor2860 series. CPE which has registered to Vigor2860 series will be captured and displayed on the page of Central VPN Management>>CPE Management. Return to the web user interface of Vigor2860 series. Open Central VPN Management>>VPN Management. Now there is one CPE displayed on the field of Unmanaged Devices List.
Page 512: Cvm Application - How To Build The Vpn Between Remote Devices And Vigor2860 Series
When a remote device is managed by Vigor2860 series, it is easy to build VPN between these two devices. Access into the web user interface of Vigor2860 series. Open Central VPN Management>>CPE Management. Click the device icon (marked with ) and click the PPTP/IPsec button.
Page 513 VPN and Remote Access>>LAN to LAN of the remote device for viewing the detailed information. Note: The profile name is created automatically by the system. Do not modify any value in such page to avoid VPN error. Vigor2860 Series User’s Guide...
Page 514: Cvm Application - How To Upgrade Cpe Firmware Through Vigor2860 Series
Vigor2850, as an example, is chosen for Vigor2860 to perform the CPE firmware upgrade remotely in this case. Plug in USB storage disk onto Vigor2860 series via USB interface. Make sure the USB disk has been installed correctly, otherwise, the firmware upgrade will not be successful.
Page 515 Select to locate it. Specify the Schedule profile. At last, click Now, a new maintenance profile has been created. Click Now to perform the firmware upgrade immediately for Vigor2850. Wait for several minutes for firmware upgrade. Vigor2860 Series User’s Guide...
Page 516 Click Managed Devices List. Click the icon of Vigor2850 and click Edit and view the software version. Another way to check if the firmware upgrade is completed or not, simply open Central VPN Management>>Log & Alert. Vigor2860 Series User’s Guide...
Page 517: How To Setup Load Balance For Packets
Internet. The PC in LAN1 can send the data to the remote PC through the specified WAN1. Access into web user interface of Vigor2860 series. Open Load-Balance/Route Policy. From the following web page, simply click index number #1.
Page 518 203.65.1.35; choose WAN1 as the Interface; click default gateway; do not check Auto Failover To The Other WAN. After finished the above settings, click OK to save the configuration. Now, the packets sent to the remote PC (IP address: 203.65.1.35) will be forcefully to pass through WAN1. Vigor2860 Series User’s Guide...
Page 519: How To Authenticate Clients Via User Management
With User Management authentication function, before a valid username and password have been correctly supplied, a particular client will not be allowed to access Internet through the router. There are three ways for authentication: Web, Telnet and Alert Tool. Vigor2860 Series User’s Guide...
Page 520 Web authentication interface first. Then, the client is trying to access http://www.draytek.com and but brought to the Vigor router. Since this is an SSL connection, some web browsers will display warning messages.
Page 521 With Crome browser, you may get the following warning. Click Proceed anyway. After that, the web authentication window will appear. Input the user name and the password for your account (defined in User Management) and click Login. Vigor2860 Series User’s Guide...
Page 522 If the authentication is successful, the client will be redirected to the original web site that he tried to access. In this example, it is http://www.draytek.com . Furthermore, you will get a popped up window as the following. Then you can access the Internet.
Page 523 With the default setup <body stats=1><script language='javascript'> window.location='http://www.draytek.com'</script></body>, you will be redirected to http://www.draytek.com . You may change it if you want. For example, you will get the following welcome message if you enter Login Successful in the Welcome Message table.
Page 524 If SSL Tunnel or SSL Web Proxy is disabled in the VPN profile, a User Management account and a remote dial-in VPN profile can use the same Username, even with different passwords. However, we recommend you to use different usernames for different user profiles in User Management and VPN profiles. Vigor2860 Series User’s Guide...
Page 525 Note: Here expired time is “Unlimited” means the Time Quota function is not enabled for this account. After login, this account will not be expired until it is logout. In the Web interface of router, the configuration page of Time Quota is shown as below. Vigor2860 Series User’s Guide...
Page 526 You will get the following message. The expired time is shown after you login. After you run out the available time, you can’t use this account any more until the administrator manually adds additional time for you. Vigor2860 Series User’s Guide...
Page 527 Any modification to the Firewall policy will break down the connections of all current users. They all have to authenticate again for Internet access.  The administrator may check the current users from User Online Status page. Vigor2860 Series User’s Guide...
Page 528 Vigor2860 Series User’s Guide...
Page 529: Trouble Shooting
Turn on the router. Make sure the ACT LED blink once per second and the correspondent LAN LED is bright. If not, it means that there is something wrong with the hardware status. Simply back to “1.3 Hardware Installation” to execute the hardware installation again. And then, try again. Vigor2860 Series User’s Guide...
Page 530 Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties. Select Internet Protocol (TCP/IP) and then click Properties. Vigor2860 Series User’s Guide...
Page 531 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used Mac OS on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4. Vigor2860 Series User’s Guide...
Page 532: Pinging The Router From Your Computer
Open the Application folder and get into Utilities. Double click Terminal. The Terminal window will appear. Type ping 192.168.1.1 and press [Enter]. If the link is OK, the line of “64 bytes from 192.168.1.1: icmp_seq=0 ttl=255 time=xxxx ms” will appear. Vigor2860 Series User’s Guide...
Page 533: Checking If The Isp Settings Are Ok Or Not
PIN code and try again. If it still fails, it might be the compliance problem of system. Please open DrayTek Syslog Tool to capture the connection information (WAN Log) and send the page (similar to the following graphic) to the service center of DrayTek.
Page 534: Backing To Factory Default Setting If Necessary
Go to System Maintenance and choose Reboot System on the web page. The following screen will appear. Choose Using factory default configuration and click Reboot Now. After few seconds, the router will return all the settings to the factory settings. Vigor2860 Series User’s Guide...
Page 535: Contacting Your Dealer
After restore the factory default setting, you can configure the settings for the router again to fit your personal request. If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@DrayTek.com. Vigor2860 Series User’s Guide...
Page 536 This page is left blank. Vigor2860 Series User’s Guide...
Page 537: Appendix I: Vlan Applications On Vigor Router
VLAN helps you to solve these situations, and DrayTek’s products support bellow two popular types: It uses a matrix table of the physical ports to define the traffics how to exchange between each port, and the traffics will be isolated from the ports are not being ticked in the same line.
Page 538 P1 and P2 are doing NAT flow to access to the internet, but P3 and P4 will forward the packets between WAN and LAN ports directly. So far, there are two kinds of open system on Vigor router. One is DrayOS, which is DrayTek owned, and another is Linux-like which customized by DrayTek from OpenWRT. Here...
Page 539 DrayOS system is going to be introduced to you because it is the most stable and superfast booting system in DrayTek products. If the UI style of yours is different from the following. It may not DrayOS system with new web style or maybe the Linux-like model.
Page 540  Multi Subnet (VLAN of LAN) Vigor2860 Series User’s Guide...
Page 541 The benefit of Port-based is able to extend the wired ports by installing a cheaper dumb switch as many as you need, but Tag-based offers you a flexible and well-managed network. The networks are isolated, secured and reduce the broadcasting storm effectively in each of networks with VLAN.  Guest Network Vigor2860 Series User’s Guide...
Page 542 However, a switch support VLAN function is need if VLAN Tag enabled.  Triple Play (Multi-WAN) NAT mode with VLAN Vigor2860 Series User’s Guide...
Page 543 Following settings, the set-top box (STB) is able to attach with any LAN port. Video streaming which your ISP provided will be played on your monitor. Vigor2860 Series User’s Guide...
Page 544 Set-top box (STB) or the other kinds of media devices are able to attach with Port4 or Port5 of LAN. Those devices that attached with Port4 or Port5 are able to access the services network directly which your ISP provided. Vigor2860 Series User’s Guide...
Page 545: Appendix Ii: Release Note
Improved: Add WAN DHCP option configuration in the page of WAN>>Internet Access.  Improved: Increase more port number settings for Port Redirection and Open ports.  IP Alias Number: 32 (original: 8)  Port Redirection Number: 40 (original: 20) Vigor2860 Series User’s Guide...
Page 546 Corrected: Enabling the DNF filter and unplugging the WAN cable will cause router reboot continuously.  Fixed: Fix the problem of stability issue after enabling WCF mechanism.  Fixed: IPv6 PPP WAN cannot connect with VLAN tag on WAN interface. Vigor2860 Series User’s Guide...

Draytek Vigor2860 Series User Manual

Quick Links

Related Manuals for Draytek Vigor2860 Series

Summary of Contents for Draytek Vigor2860 Series
