Dtc P0341 Camshaft Position Sensor Rationality - Daewoo MATIZ Service Manual

Step
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
1
Is the system check complete?
1. Turn the ignition switch to LOCK.
2. Disconnect the CMP sensor connector.
2
3. Check for a faulty connector or terminals.
Is the problem found?
1. Turn the ignition switch to ON.
2. Disconnect the ECM connector.
3. Inspect the ECM pins and connector for bent or
damaged terminals.
4. Check the wire between the CMP sensor terminal
1 and ECM connector 82 for an open or short to
3
ground or short to battery voltage while related
connectors and wiring harness.
5. Check the wires between the CMP sensor
terminal 2 and ECM connector 18 for an open
while moving related connectors and wiring
harness.
Is the problem found?
1. Turn the ignition switch to LOCK.
2. Repair or replace the wire or the connector.
3. Clear any DTCs from the ECM.
4
4. Run the engine.
5. Perform the diagnostic system check.
Is the repair complete?
1. Turn the ignition switch to LOCK.
2. Replace the CMP sensor.
3. Clear any DTCs from the ECM.
5
4. Run the engine.
5. Perform the diagnostic system check.
Does DTC P0341 reset?
1. Replace the ECM.
2. Run the engine.
6
3. Perform the Diagnostic system check.
Is the replacement complete?
1. Using the scan tool, clear the DTCs.
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
7
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic run
and passed?
Check if any additional DTCs are set.
8
Are any DTCs displayed that have not been
diagnosed?
DAEWOO M-150 BL2
DTC P0341 – Camshaft Position Sensor Rationality
Action
ENGINE CONTROLS 1F – 157
Value(s) Yes
–
Go to Step 2
–
Go to Step 4
–
Go to Step 4
–
System OK
–
System OK
–
Go to Step 7
–
Go to Step 8
Go to
Applicable DTC
–
table
No
Go to
"On-Board
Diagnostic
System Check"
Go to Step 3
Go to Step 5
–
Go to Step 6
–
–
System OK
