WINDSHIELD/REAR WINDOW WIPER AND WASHER SYSTEM(Cont'd)
Condition
Rear Wiper Does Not Work
Rear Window Washer Does Not
Work, Rear Window Wiper OK
DAEWOO M-150 BL2
Probable Cause
D The open or a short in the power
supply circuit to the fuse F9.
D Fuse F9 is blown.
D The circuit between the fuse F9
and the wiper/washer switch is the
open circuit or a short circuit.
D Faulty wiper/washer switch.
D The circuit between the
wiper/washer switch and the rear
window wiper motor is the open
circuit or a short circuit.
D The circuit between the fuse F9
and the rear window wiper motor
is the open circuit or a short
circuit.
D Faulty rear window wiper motor.
D Poor ground G403.
D The open or a short in the power
supply circuit to the fuse F9.
D Fuse F9 is blown.
D The circuit between the fuse F9
and wiper/washer switch is the
open circuit or a short circuit.
D Faulty wiper/washer switch.
D The circuit between the
wiper/washer switch and the
windshield washer pump is the
open circuit or a short circuit.
D Faulty windshield washer pump.
D Poor ground G102.
WIPERS/WASHER SYSTEMS 9D – 5
Correction
D Repair or Replace the open or a
short in the power supply circuit to
the fuse F8.
D Replace the fuse F9.
D Repair or Replace the wiring
harness.
D Replace the wiper/washer switch.
D Repair or Replace the wiring
harness.
D Repair or Replace the wiring
harness.
D Replace the rear window wiper
motor.
D Repair or Replace the wiring
harness.
D Repair or Replace the open or a
short in the power supply circuit to
the fuse F9.
D Replace the fuse F9.
D Repair or Replace the wiring
harness.
D Replace the wiper/washer switch.
D Repair or replace the wiring
harness.
D Replace the windshield washer
pump.
D Repair or Replace the wiring
harness.
