8A – 4 SEAT BELTS
DIAGNOSTIC INFORMATION AND PROCEDURES
SEAT BELT WARNING LAMP IS INOPERATIVE
Condition
Seat Belt Warning
Lamp is Inoperative
Probable Cause
D Fuse F1 is blown.
D Seat belt warning lamp wiring harness is
open circuit or a short circuit.
D The continuity between the two terminals at
the switch side of the connector is fail.
D The continuity between the terminal for the
BLK wire and ground is fail.
D The warning lamp bulb in the instrument
cluster is blown.
Correction
D Replace the fuse F1.
D Repair the wiring harness.
D Replace the seat belt switch.
D Repair the open ground.
D Replace the warning lamp bulb.
DAEWOO M-150 BL2
