WIRING DIAGRAM
MT-03 2006
1. Crankshaft position sensor
2. A.C. magneto
3. Neutral switch
4. Main switch
5. Rectifier/regulator
6. Wire plus lead
7. Battery
8. Main fuse
9. Starter relay
10. Starter motor
11. Wire minus lead
12. Relay unit
13. Starting circuit cut-off relay
14. Fuel injection system relay
15. Fuel injection diagnostic tool
16. Ignition coil
17. Spark plug
18. Fuel injector
19. Air induction system solenoid
20. Intake air temperature sensor
21. Coolant temperature sensor
22. ECU
23. Speed sensor
24. Throttle position sensor
25. Intake air pressure sensor
26. Lean angle cut-off switch
27. Multi-function meter unit
28. Neutral indicator light
29. Multi-function meter
30. Fuel level warning light
31. Turn signal indicator light
32. High beam indicator light
33. Coolant temperature warning light
34. Immobilizer system indicator light
35. Multi-function meter light
36. Engine trouble warning light
37. Fuel pump
38. Sidestand switch
39. Front brake light switch
40. Right handlebar switch
41. Engine stop switch
42. Start switch
43. Turn signal/hazard relay
44. Headlight relay
45. Clutch switch
46. Hazard switch
47. Turn signal switch
48. Dimmer switch
49. Pass switch
50. Horn switch
51. Left handlebar switch
52. Rear turn signal light (right)
53. Front turn signal light (right)
54. Front turn signal light (left)
55. Rear turn signal light (left)
56. Headlight
57. Horn
58. Tail/brake light
59. Auxiliary light
60. License light
61. Rear brake light switch
62. Radiator fan motor
63. Radiator fan motor relay
64. Parking lighting fuse
65. Headlight fuse
66. Signaling system fuse
67. Ignition fuse
68. Radiator fan motor fuse
69 Backup fuse (immobilizer unit, multi-function meter
unit)
70. Fuel injection system fuse
71. Anti-theft alarm (optional)
72. Immobilizer unit
