Figure 21 BCM Bus configuration for R2MFC MBM
6
Select Modules on bus > Module 1 from the navigation tree.
The Bus # - Module # Information frame displays. See
7
Configure the parameters in the Bus# - Module # information frame. See
parameters and settings.
See
Figure 22 on page 56
on Bus 06.
Table 8 Module configuration parameters
Parameter
Module type
Protocol
Clock source
Overlap receiving
Local number length
for an example of the screen layout for an R2MFC MBM configured
Setting
PRI
Euro
Primary (if only one trunk
module in system;
otherwise, it depends on the
synchronization scheme of
the BCM)
Y
According to BCM local
dialing plan (customer -
dependent)
R2MFC Media Bay Module Installation and Configuration Guide
Chapter 5 Configuring the R2MFC MBM
Figure 22 on page
55
56.
Table 8
