Performing Feed Correction to Alleviate Horizontal Bands and the Like

Procedure
1.
Print a test pattern.
–
MENU
CALIBRATION
—
CALIBRATION
TEST PRINT
2.
Check the test pattern you printed.
Gap present
Test pattern
Correction-value
adjustment
Reduce the value.
3.
Enter the correction value.
SETTING
0 . 0 0 %
0 . 1 5 %
4.
Go back to the original screen.
W 1346mm
SETUP SHEET
ROLL
6-7 Correcting Misalignment for Printing or Cutting
Press .
Press several times.
Press .
Press to start printing.
Correct results
± 0
Press .
Press .
Use to make the setting for the correction value.
Press to enable the setting.
Press .
Press to go back to the original screen.
Overlap
Increase the value.
Chapter 6 Feature Reference 103
