*1
The length of printing or cutting is subject to the limitations of the program or driver.
*2
➢ At Roland PET film, print travel: 1 m
➢ Temperature: 25°C (77°F), humidity: 50%
*3
Not assured when the print heater or dryer is used.
*4
The following conditions must be met:
➢ Media type: Media specified by Roland DG Corp.
➢ Roll media must be loaded on the shaft
➢ [PREFEED] menu item must be set to [ENABLE]
➢ Side margins: 25 mm or more for both the left and right margins
➢ Front margin: 35 mm or more
➢ Excluding stretching/contraction of the media
Range for assured repetition accuracy
➢ For media with a width exceeding 610 mm: Length 4,000 mm
➢ For media with a width of 610 mm or less: Length 8,000 mm
*5
➢ Provided that media length is under 3000 mm
➢ Temperature: 25°C (77°F)
➢ Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media
*6
➢ Media type : Roland PET film
➢ Data size: 1,000 mm in the media-feed direction, 1,346 mm in the carriage-movement direction
➢ No lamination
➢ Automatic detection of crop marks at 4 points when media is reloaded
➢ During cutting, [PREFEED] menu item must be set to [ENABLE]
➢ Temperature: 25°C (77°F)
➢ Excludes the effects of slanted movement and of expansion and contraction of the media
*7
➢ Warm-up is required after powerup. This may require 5 to 20 minutes, depending on the operating environment.
➢ Depending on the ambient temperature and media width, the preset temperature fail to be reached.
*8
Operating environment
(%)
Humidity
(no condensation) 80
55
35
°C (°F)
0 15 20 27 32
(59) (68) (80.6) (89.6)
Temperature
Use in an operating environment with
this range.
