Table of Contents

Advertisement

Quick Links




Use this manual if you are just starting to use the machine.

If you have already mastered the basic operation, use this

manual for an introduction to more advanced operations.


R1-170216

FA01088
Select the manual that you want to read.

http://www.rolanddg.com/
Copyright (C) 2017 Roland DG Corporation
Basic Edition
Application Edition
 Windows version
 Macintosh version







Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-540 and is the answer not in the manual?

Questions and answers

Related Manuals for Roland GR-540

Summary of Contents for Roland GR-540

  • Page 1   Select the manual that you want to read.         Use this manual if you are just starting to use the machine. Basic Edition       If you have already mastered the basic operation, use this Application Edition   manual for an introduction to more advanced operations.  Windows version    Macintosh version http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation   R1-170216     FA01088...
  • Page 2     Sending Data from   Printing and Cutting Cutting Perforated Lines  Illustrator     Other Things That You   Troubleshooting   Can Do     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation...
  • Page 3 Application Edition Macintosh Version Cover Sending Data from Illustrator Printing and Cutting Cutting Perforated Lines Other Things That You Can Do Troubleshooting...
  • Page 4 Other Things That You Can Do Troubleshooting Sending Data from   Printing and Cutting Cutting Perforated Lines  Illustrator     Other Things That You   Troubleshooting   Can Do     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation...
  • Page 5     Sending Data from Illustrator/CorelDRAW Printing and Cutting Cutting Perforated Lines        Other Things That You   Tiled Output Troubleshooting   Can Do     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation  ...
  • Page 6 Application Edition Windows Version Cover Sending Data from Illustrator/CorelDRAW Printing and Cutting Cutting Perforated Lines Tiled Output Other Things That You Can Do Troubleshooting...
  • Page 7 Other Things That You Can Do Troubleshooting Sending Data from   Illustrator/CorelDRAW Printing and Cutting Cutting Perforated Lines      Other Things That You Tiled Output Troubleshooting     Can Do     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation  ...
  • Page 8     Simple!   Maintenance/Replacement Troubleshooting   Basic Cutting     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation...
  • Page 9 Basic Edition Cover About the User's Manuals Getting Started What Is the GR- 640/540/420? Simple! Basic Cutting Improving the Finish Maintenance/Replacement Troubleshooting Error Message List Menu Flow Chart Specifications...
  • Page 10 What Is the GR- 640/540/420?     Simple! Basic Cutting Improving the Finish Maintenance/Replacement Troubleshooting Error Message List Menu Flow Chart Specifications Simple!   Maintenance/Replacement Troubleshooting   Basic Cutting     http://www.rolanddg.com/     Copyright (C) 2017 Roland DG Corporation...
  • Page 11 This manual provides instructions for basic machine operation and maintenance. User's Manual, Application Edition—Windows Version (Electronic-format Manual) This manual provides instructions and tips for using the GR-640/GR-540/GR-420 and its included software to create various products. The Windows version of the application edition provides procedures that use a computer on which Windows is installed.

  • Page 12: Getting Started

    There are additional precautions related to this product's handling and installation site. For details, see the setup guide of this machine. Storing Important Data Roland DG Corp. assumes no liability for any loss or damage of data resulting from computer malfunction or damage. Always back up important data.
  • Page 13 What Is the GR-640/GR-540/GR-420? What the GR-640/GR-540/GR-420 Can Be Used For Loadable Materials/Cuttable Area Part Names Carriage LED Lamp...
  • Page 14 What the GR-640/GR-540/GR-420 Can Be Used For Cutting Characters and Shapes Cleanly Making Stickers by Connecting to a Printer Printing and Cutting Preparations for Printing and Cutting (When Using CutStudio) Simple! Basic Cutting Preparations for Printing and Cutting (When Using...
  • Page 16 Length 156 to 1,802 mm GR-640 (6 to 70 inches) Roll material: no restriction 156 to 1,548 mm GR-540 (6 to 60 inches) Flat material: 200 mm or more 156 to 1,224 mm GR-420 (6 to 48 inches) Never load media that weighs over 40 kg (88.19 lb.).
  • Page 17 Maximum cutting area Width: 1,651 mm (65 inches)(*) GR-640 Length: 24,998 mm Width: 1,397 mm (55 inches)(*) GR-540 Length: 24,998 mm Width: 1,075 mm (42.3 inches)(*) GR-420 Length: 24,998 mm * The maximum width can be extended by up to 20 mm depending on settings. However, this may cause the pinch roller to leave marks on the products.
  • Page 18 minus approximately 1 mm on each side. Type of specified material Cutting area <Width>: Distance between the two pinch rollers minus approximately 1 mm [ROLL] or [EDGE] on each side <Length>: 24,998 mm <Width>: Distance between the two pinch rollers minus approximately 1 mm [PIECE] on each side <Length>: Detected length(*)

  • Page 19: Part Names

    Part Names Main Unit Front Number Name Description To raise or lower this part, press ［PINCH］. This part lowers to pinch Left pinch roller the material. Set this at the left edge of the material. Middle pinch rollers To raise or lower these parts, press ［PINCH］. These parts lower to (the number of which varies depending pinch the material.
  • Page 20 Power switch Turns the machine's power on and off. Set the material in place so that its right edge is aligned with the front Ruler and back rulers. These indicate the locations of the grit rollers. When loading the Grit pattern material, be sure to place the pinch rollers within the area indicated by each of these patterns.
  • Page 21 Notation used in this Number Name Description document Use this to raise and lower the pinch rollers. Use this when PINCH key inserting or removing the material. [PINCH] When the pinch rollers are lowered, this key lights. Display This displays various setting menus and other information. - - - You use these to select settings for menu items, to move the ［...
  • Page 22 Carriage LED Lamp Normal The blue lamp is steadily lit or flashes. Error The red lamp flashes and an error message is displayed. Refer to "Error Message List" and clear the error.
  • Page 23 Simple! Basic Cutting Performing Cutting Let's learn basic cutting operations. When you follow the procedure, you can create a sticker like the one shown in the figure below. Items Required Other Than the Machine A computer with CutStudio installed Roll material CutStudio Be sure to install this program.
  • Page 24 Procedure Loading Roll Material Installing the Cutting Tool Performing a Cutting Test Setting the Origin Creating Cutting Data (1) Creating Cutting Data (2) Entering Characters and Shapes Saving Cutting Data Performing Cutting Removing the Material...

  • Page 25: Loading Roll Material

    Loading Roll Material Load roll media correctly. CAUTION Otherwise the media may fall and cause injury. Roll media weighs about 40 kg (88.19 lb.). To avoid injury, handle it with care. CAUTION Never load media that weighs over 40 kg (88.19 lb.). CAUTION The machine may fail to withstand the weight, causing the machine to tip over or the material to fall.
  • Page 26 Place the roll material on the shaft at the back of the machine. Pull the roll material out to the front of the machine. Release the brake, and then pass the leading edge of the roll material between the pinch rollers and the grit rollers.
  • Page 27 1: Machine front 2: Machine back 3: Brake 4: Roll material 5: Pinch rollers 6: Grit rollers 7: Pinch roller shaft Pull out a length of material that is slightly long, leaving some slack. If you load the material without creating some slack, the material cannot be fed correctly.
  • Page 28 Place the right edge of the roll material over the grit roller (on the right edge). 1: Grit roller 2: Right edge of the roll material Slide the roll material to place its left edge over the grit roller. At this point, check that the right edge of the roll material remains over the grit roller on the right edge.
  • Page 29 *: Ruler gradation Place the left and right pinch rollers over the grit rollers on both edges of the roll material and the middle pinch rollers over their corresponding grit rollers. Position the pinch rollers on the edges so that each one is 25 mm or more inside of the respective left or right edge of the roll material.
  • Page 30 Handling Error Messages If the following error message appears on the display, one of the pinch rollers is not in the correct position. Follow the procedure shown below to place the pinch rollers in the correct positions. Procedure Press [ENTER]. The cutting carriage moves to the right edge, and the following screen is shown on the display.
  • Page 31 Press [PINCH]. The pinch rollers rise up. Place the pinch rollers in the correct positions. Place them so that each is positioned over a grit roller. Position the pinch rollers on the edges so that each one is 25 mm or more inside of the respective left or right edge of the roll material.
  • Page 32 Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] to display the screen shown in the figure. Press the [ ] key, and then the [ ] key. The screen shown in the figure below is displayed. Press [ ].
  • Page 33 Press [ENTER]. The set length of the material moves out to the front, then is immediately pulled back and taken up again. Press the [MENU] key to return to the screen shown in the figure. If the Material Comes Loose If the material comes loose from the pinch rollers, press the [PAUSE] key to stop operation.

  • Page 34: Installing The Cutting Tool

    Installing the Cutting Tool Never touch the tip of the blade. CAUTION Doing so may result in injury. Notice：Use the blade which suit material There is a risk of damage to blade when you cut unspecified sheet because of compatibility between blade and sheet. Use the optimal blade for cutting to sheet material.
  • Page 35 Installing the Cutting Tool Procedure Loosen the cutting carriage screw. Install the cutting tool in the cutting carriage. Normally, install it in the position shown in the figure (in the rear). Install it in the front position when cutting perforated lines.
  • Page 36 Tighten the cutting carriage screw. Material Types and Blade Adjustment It may be necessary to adjust the amount of blade extension for some types of material, such as material with thin carrier paper. If you are not able to obtain stable cutting results, changing the amount of blade extension can yield better results.
  • Page 37 General Guide Regarding Cutting Conditions Changing the Blade Force Changing the Cutting Speed Adjusting the Cutting-in Amount Performing a Cutting Test...

  • Page 38: Performing A Cutting Test

    Performing a Cutting Test To obtain high-quality cutting results, carry out a cutting test to check the cutting quality for the material before you perform the actual cutting. Procedure Setting the Number of Cutting Tests to Perform Check that the PEN FORCE slider is at the center position (at "0" on the scale).
  • Page 39 Press [ ] or [ ] to set the number of cutting tests to perform. Cutting tests in three locations: Status of the finished product Cutting test in one location: Status of the finished product Press [ENTER] to select the setting. You are returned to the following screen (in this example, three cutting tests will be performed).
  • Page 40 When the cutting test finishes, the material is automatically fed to the front. Peel off circle 1. Use the tweezers or a similar tool to peel off the cut shape, and then check the cutting quality. Circle 1 Tweezers If Circle 1 Peels Off Alone → Step 8...
  • Page 41 *: Circle 1 If Other Shapes Also Peel Off/The Machine Cuts the Carrier Paper → "Changing the Blade Force" Peel off rectangle 2. Use the tweezers or a similar tool to peel off the cut shape, and then check the cutting quality. Rectangle 2 If the Blade Leaves Faint Traces on the Material's Carrier Paper →...
  • Page 42 If the Traces Left by the Blade Are Indistinct/Too Deep → "Changing the Blade Force" Setting the Origin...

  • Page 43: Setting The Origin

    Setting the Origin The origin is set in order to determine the cutting position. Move the cutting carriage to a place where it does not overlap the location where you made the cutting test. Procedure Press ［MENU］ to display the following screen. Moving the Cutting Carriage at High Speed Press [ ], [ ], [ ], and [ ] to move the cutting carriage to the location you want to set as the origin.
  • Page 44 Hold down [ORIGIN] for one second or longer. The screen flashes. This completes all preparations for cutting. Creating Cutting Data (1)
  • Page 45 Procedure Start CutStudio. Windows 10 and Windows 7 On the Start menu, click All Programs (or Programs), click Roland CutStudio, and then click CutStudio. Windows 8.1 At the lower left of the Start screen, click to display the Apps screen. Click...
  • Page 46 (2) Set the Model Procedure From the File menu, click Cutting Setup. The Cut Setting window appears.
  • Page 47 Use Name under Printer to select the model name of the cutting machine to use. Creating Cutting Data (2)
  • Page 48 Creating Cutting Data (2) Set Material Size Procedure Click Change under Media Size. Click Get from Machine. The cuttable area is displayed.
  • Page 49 If a Message Saying "The machine is not responding." Is Displayed Refer to "The Machine Doesn't Run," and check the machine and computer settings. Click OK.
  • Page 50 Click OK in the Cut Setting window.
  • Page 51 The cutting area is set. The white area is the cutting area. Characters and shapes outside this area will not be cut.
  • Page 52 *1: Cutting area *2: The origin set in "Setting the Origin" (the cutting start position) corresponds to the lower-left corner of the screen in CutStudio. Entering Characters and Shapes...
  • Page 53 Entering Characters and Shapes Enter Characters and Shapes This example explains the procedure for entering the word "SALE" and creating a frame to make it easy to peel off afterward. Procedure Click Click anywhere in the white area, and then type "SALE."...
  • Page 54 Click , and then change the size of the characters. ■ and ▼ appear around the characters. Drag the ■ and ▼ symbols around the text box to change the size of the characters.
  • Page 55 Select the object, and then click in the menu bar. You can configure advanced settings in the Properties palette. From the Object menu, click Weed. The Weed dialog box appears. Select the Weed Border check box, and then click OK.
  • Page 56 A waste removal line is added around the characters. The character or shape to which the waste removal line has been added is grouped together with the waste removal line. For details on waste removal lines, see the CutStudio help. Click , and then move the characters with the waste removal frame added.
  • Page 57 Select the object that you want to move to the origin, and then click in the menu bar to move this object to the origin. Position Characters and Shapes at the Bottom of the Screen When positioning characters and shapes in CutStudio, it is better to position them starting from the bottom of the screen.
  • Page 58 Actual cutting position Saving Cutting Data...

  • Page 59: Saving Cutting Data

    Saving Cutting Data Save Data Procedure Click The screen shown in the following figure is displayed. Select a folder where you want to save the data. Enter a file name, and then click Save. The data you have created is saved.
  • Page 60 Important: The cutting area is not saved. The cutting area you set in this procedure is not saved. The next time data is loaded, the cutting area must be set again from the Cut Setting menu. Performing Cutting...

  • Page 61: Performing Cutting

    Performing Cutting Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Once the data has been prepared you are ready to start cutting. If you are using a Macintosh, click here.
  • Page 62 If you want to change the cutting conditions, click Change, clear the Use cutting conditions of machine check box, and then enter the values. This completes the cutting procedure for the characters "SALE" and the rectangle.
  • Page 63 Removing the Material To Cancel Cutting Procedure Press [PAUSE] Hold down [ENTER] for one second or longer. The data is canceled. Removing the Material...

  • Page 64: Removing The Material

    Removing the Material When cutting has finished, remove the material. Procedure Press [MENU] several times to display the screen shown below. Press [ENTER]. The cutting carriage returns to the home position. Press [PINCH]. The pinch rollers rise up to release the material.
  • Page 65 Remove the material by moving it through the rear of the machine. To Remove Only the Cut Area Procedure Press [ ] and [ ] to feed the material to the location that you want to cut. The material is cut off at the position shown in the figure. *: Groove along which the separating knife passes...
  • Page 66 Hold down [SHEET CUT] for one second or longer. The cutting carriage moves to the left edge and then to the right edge in order to cut the material. After the material is cut, the cutting carriage returns to the new origin.
  • Page 67 Sending Data from Illustrator/CorelDRAW You can output cutting line data drawn with Adobe Illustrator or CorelDRAW to CutStudio. To output data it is necessary to install a plug-in. When Using Illustrator Required Items CutStudio Plug-in for Illustrator Installing Plug-in for Illustrator Install CutStudio and Plug-in for Illustrator on the computer on which Illustrator is installed.
  • Page 68 When Using CorelDRAW Required Items CutStudio Plug-in for CorelDRAW Installing Plug-in for CorelDRAW Install CutStudio and Plug-in for CorelDRAW on the computer on which CorelDRAW is installed. Sending Data from CorelDRAW Outputting Data Created in CorelDRAW Viewing Help Viewing Help (CorelDRAW)
  • Page 69 Installing Plug-in for Illustrator Installation Procedure Install from the following link. http://startup.rolanddg.com/ Supported Versions For information regarding the latest supported versions, visit the Roland DG Corp. website (http://www.rolanddg.com/).
  • Page 70 * The screenshots show an example of Illustrator CC 2015, but the operation procedure is the same for other versions. You must install Plug-in for Illustrator before proceeding. Installing Plug-in for Illustrator Procedure Start Illustrator. In Illustrator, click Extensions > Roland CutStudio from the Window menu. The "Roland CutStudio" palette appears.
  • Page 71 Create a new file and create a new design or open an existing file. In this example, you will create the design shown in the figure below. Change the characters to outline data.
  • Page 72 When you select characters and click on the palette, the characters change to outline data. Select Output All Lines.
  • Page 73 On the Roland CutStudio palette, select the Auto Update check box. Check that the cutting line that you wish to output is shown on the preview screen.
  • Page 74 Click CutStudio starts, and the cutting line data is sent to CutStudio. The output data is always aligned at the origin of CutStudio regardless of the position in Illustrator. (This does not apply to data with crop marks.) Perform cutting. Performing Cutting When perform cutting from CutStudio, refer to the procedure of "Simple! Basic Cutting."...
  • Page 75 Viewing Help (Illustrator) Procedure On the Roland CutStudio palette, click , and then click Help.
  • Page 76 Installing Plug-in for CorelDRAW Installation Procedure Install from the following link. http://startup.rolanddg.com/ Supported Versions For information regarding the latest supported versions, visit the Roland DG Corp. website (http://www.rolanddg.com/).
  • Page 77 Outputting Data Created in CorelDRAW You must install Plug-in for CorelDRAW before proceeding. Procedure Start CorelDRAW. On the toolbar, click The "Roland CutStudio" palette appears.
  • Page 78 Create a new document and create a new design or open an existing file. In this example, you will create the design shown in the figure below. Convert the characters to curved lines.
  • Page 79 When you select characters and click on the palette, the characters change to outline data. Select Output All Lines.
  • Page 80 Select the Auto Update check box. Check that the cutting line that you wish to output is shown on the preview screen. Click CutStudio starts, and the cutting line data is sent to CutStudio. The output data is always aligned at the origin of CutStudio regardless of the position in CorelDRAW.
  • Page 81 The data created in CorelDRAW is output to CutStudio according to the following conditions. All graphics that are drawn are output to CutStudio. Character strings are not output to CutStudio. Convert character strings to curved lines prior to outputting the data. Line width, fill, and arrows are ignored.
  • Page 82 Viewing Help (CorelDRAW) Procedure On the Roland CutStudio palette, click , and then click Help.

  • Page 83: Printing And Cutting

    Printing and Cutting Printing and Cutting Overview Your favorite picture can be printed and cut. This makes it easy to create your own original stickers. Flow Diagram Create the data in CutStudio. (You can also use Illustrator/CorelDRAW.) Print the data with the printer. (Use the printer that you have on hand.)
  • Page 84 Preparations for Printing and Cutting (When Using Illustrator) Printing and Cutting Procedure (Illustrator) Printing and Cutting with CorelDRAW Preparations for Printing and Cutting (When Using CorelDRAW) Printing and Cutting Procedure (CorelDRAW) Printing and Cutting with a Roland DG Corp. Printer...
  • Page 85 Use Roland VersaWorks Dual to perform printing and cutting. For the method to use, see the Roland VersaWorks Dual help. Printing and Cutting without Using the Included Software Preparations for Printing and Cutting (Manual Mode) Printing and Cutting Procedure (Manual Mode)
  • Page 86 Preparations for Printing and Cutting (When Using CutStudio) Printing and Cutting Sample Data We recommend that you get comfortable with the printing and cutting procedure by using the sample data first. In this procedure, you will create the sticker shown below. Printing and Cutting Procedure (CutStudio) Items Required Other than the Machine A computer with CutStudio...
  • Page 87 Printer Requirements You must use a laser or inkjet printer with a resolution of 720 dpi or greater. If the printed filled sections are blurred, crop marks will not be read correctly. CutStudio Be sure to install this program. Only CutStudio can be used to perform printing and cutting operations. http://startup.rolanddg.com/ Materials That Can Be Used for Printing and Cutting This example uses A4-size material.
  • Page 88 Printing and Cutting Procedure (CutStudio) Procedure Step 1: Set the Printing and Cutting Areas Step 2: Import the Sample Data Step 3: Draw the Cutting Lines Step 4: Perform Printing Step 5: Load the Printed Material Step 6: Set the Alignment Method (Sensor Mode) Step 7: Perform Cutting (Sensor Mode)
  • Page 89 Procedure Start CutStudio. Windows 10 and Windows 7 On the Start menu, click All Programs (or Programs), click Roland CutStudio, and then click CutStudio. Windows 8.1 At the lower left of the Start screen, click to display the Apps screen. Click The screen shown below appears.
  • Page 90 Use Name under Printer to select the model name of the machine on hand. Click OK.
  • Page 91 From the File menu, click Print & Cut. The printing area and crop marks are displayed on the screen. The printing area is displayed with dotted lines. This area corresponds to the paper size specified in Set up the printer excluding the margins specified in Printing Setup.
  • Page 92 From the File menu, click Printing Setup. Click Printer Setup.
  • Page 93 Set the document size, and then click OK. Click Fit into shared area for cutting and printing. The crop mark location is set automatically.
  • Page 94 For guidelines when setting the margins and crop marks, see "Setting the Margins and the Distance between Crop Marks." Click OK. After setting the values, check that the crop marks are within the printing area.
  • Page 95 * Ensure that the crop marks do not project outside of the dotted lines. Step 2: Import the Sample Data...
  • Page 96 Step 2: Import the Sample Data File Formats That Can Be Imported into CutStudio JPEG format * JPEG files saved in CMYK format cannot be imported. BMP format AI, EPS format (Illustrator 8.0 version) * Illustrator 8.0 and EPS 8.0 are the importable file formats. If using a higher version, save files as a lower version before importing.
  • Page 97 Illustrator Data Cannot Be Imported Select the image data, and then click Open. Position the image data in the area within the crop marks. Position the data within this area.
  • Page 98 You can change the darkness of the imported image. For more details, refer to "Changing the Darkness of an Aligned Image." Step 3: Draw the Cutting Lines...
  • Page 99 Step 3: Draw the Cutting Lines Procedure Click , and then draw the cutting lines. If using the sample data, draw the line as shown below. Cutting line Click Save the data. Step 4: Perform Printing...

  • Page 100: Step 4: Perform Printing

    Step 4: Perform Printing Procedure Load the material in the printer. For details on how to load the material, see the instruction manual for your printer. * When expanded/reduced printing is enabled, disable it. Print at 100% scale. Click Select the printer you want to use, and then click OK.
  • Page 101 The image is printed as shown in the figure below. * Cutting lines are not printed. Step 5: Load the Printed Material...
  • Page 102 Step 5: Load the Printed Material Procedure Check the origin for cutting of the printed material. Turn on the cutting machine. Wait for the initial operation to finish. Set the origin for cutting to the lower-left corner of the material, and then load the material in the machine.
  • Page 103 Position the left and right pinch rollers as shown in the figure. For A4-size material, do not use the middle pinch rollers. Using Narrow Material/Preventing Marking Made by the Middle Pinch Rollers (1) Position the pinch rollers outside the tool marks.
  • Page 104 Align the right edge of the material with the front and back gradations of the platen. Select the type of material. Press [ENTER].
  • Page 105 The pinch rollers lower and the carriage and material move. When the movement is finished, the cuttable width and length are displayed. Press [ ] and [ ] to move the material and position the crop marks above the blade protector. (1) Blade protector (2) Crop marks Press [ ] and [ ] to position the tip of the blade over the center of the...
  • Page 106 Crop marks cannot be read in the situations indicated below. If any of the following situations occur, remove the material, and then reload it. The left and right crop marks are slanted by 5 degrees or more with respect to the moving direction of the cutting carriage.
  • Page 107 *: Blade protector The material sometimes curls when it is printed on the printer. Do not use material that is curled as shown in the figure. The crop marks may not be read. If this happens, straighten out the material before loading it on the cutting machine. Step 6: Set the Alignment Method (Sensor Mode)
  • Page 108 Step 6: Set the Alignment Method (Sensor Mode) Position the crop marks automatically using the machine's integrated sensor. Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ] and select SENSOR MODE.
  • Page 109 Step 7: Perform Cutting (Sensor Mode)
  • Page 110 Step 7: Perform Cutting (Sensor Mode) Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Procedure Set the material size. Creating Cutting Data (2) Click If you want to change the cutting conditions, click Change, clear the Use cutting conditions of machine check box, and then enter the values.
  • Page 111 Click OK. The cutting data is sent to the machine. When the machine receives the data, it automatically reads the crop marks using a sensor, and then starts cutting. If the sensor fails to read the crop marks If the sensor fails to read the crop marks, the screen in the figure appears. If this screen appears, see "Crop Marks Cannot be Read."...
  • Page 113 Crop Marks/Tool Marks Crop Marks Crop marks are used for alignment when cutting printed material on the cutting machine. Having the machine remember the positions of the crop marks printed together with the image makes it possible to correct cutting positions. Crop Marks When to Use 4 Crop Marks vs 3 Crop Marks In most cases you should use 4 crop marks.
  • Page 114 * The machine may not be able to read the printed crop marks correctly depending on the printer ink. Setting the Margins and the Distance between Crop Marks Take into account the margin necessary for cutting the material and set the crop mark position. When Using CutStudio When Using Illustrator/CorelDRAW Tool Marks...
  • Page 115 Setting the Margins and the Distance between Crop Marks Set the margins and the distance between crop marks. Take into account the margin necessary for cutting the material and set the crop mark position. When Using CutStudio <crop marks: 3 points>, <crop marks: 4 points> Size Margin and crop mark settings Top: 30 mm, bottom: 45 mm, left: 10 mm, right: 10 mm...
  • Page 116 A3 portrait W: 257 mm, L: 325 mm Top: 30 mm, bottom: 45 mm, left: 10 mm, right: 10 mm A3 landscape W: 380 mm, L: 202 mm Top: 30 mm, bottom: 45 mm, left: 10 mm, right: 10 mm B4 portrait W: 217 mm, L: 269 mm Top: 30 mm, bottom: 45 mm, left: 10 mm, right: 10 mm...
  • Page 117 * When using material with a large amount of feed (long material), we recommend that you set the left and right margins to approximately 25 mm. <crop marks: 3 points>, <crop marks: 4 points> Size Crop mark positions X: 10 mm, Y: 45 mm A4 portrait W: 170 mm, L: 202 mm X: 10 mm, Y: 45 mm...
  • Page 118 : Cuttable area : Ensure that only crop marks are present within this area and that it is free of any other illustrations and dirt.
  • Page 119 Switching between 3 and 4 Crop Marks In most cases you should use 4 crop marks. (1) Printing area (2) Crop mark Switching to 3 Crop Marks CutStudio Procedure From the File menu, click Printing Setup.
  • Page 120 From the Layout Points list, select 3.
  • Page 121 Click OK. After setting the values, check that the crop marks are within the printing area.
  • Page 122 Setting the Margins and the Distance between Crop Marks Illustrator Procedure Click , and then click Crop marks. From the Point list, select 3.
  • Page 123 Click OK. CorelDRAW Procedure Click , and then click Crop marks.
  • Page 124 From the Point list, select 3. Click OK. Setting the Margins and the Distance between Crop Marks...
  • Page 126 Cutting in Tool Mode (1) When to Use Tool Mode ■ When it is not possible to perform alignment in Sensor Mode ■ When printing and cutting without selecting the type of material It is not possible to use Tool Mode when using only 3 crop marks. Required Items Material on which tool marks have been Alignment tool...
  • Page 127 (2) Set Tool Mode Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ]. Press [ ] to select TOOL MODE. Press [ENTER].
  • Page 128 Cutting in Tool Mode (2)
  • Page 129 Cutting in Tool Mode (2) Send Cutting Data and Perform Alignment Send the cutting data. The screen shown in the figure appears. Install the alignment tool. The installation method is the same as that of the cutting tool. Installing the Cutting Tool When installation is complete, press [ENTER].
  • Page 130 Use the [ ], [ ], [ ], and [ ] buttons to align the tip of the alignment tool with tool mark 1. Hold down the alignment tool gently from above with your finger and check that the tip of the alignment tool overlaps the tool mark.
  • Page 131 Press [ENTER]. The tool moves to a position near the upper-left crop mark, and the screen shown in the figure appears. Align the upper-left and upper-right tool marks in the same way. After aligning mark 4, press [ENTER]. The screen shown in the figure appears.
  • Page 132 Remove the alignment tool and install the cutting tool. Press [ENTER]. Press [ENTER]. Cutting starts. To Redo Alignment You can press [MENU] during alignment to return to the previous screen and redo the alignment procedure.
  • Page 133 Materials That Can Be Used for Printing and Cutting Use material with carrier paper that can be printed on a laser or inkjet printer. Material portion type Fine paper, coated paper, art paper, and PET (Polyethylene Laser printer Terephthalate) Inkjet printerVinyl chloride material, fine paper, and coated paper Color White * Automatic detection may not be possible for some materials, such as laminated or...
  • Page 134 Preparations for Printing and Cutting (When Using Illustrator) Printing and Cutting Sample Data We recommend that you get comfortable with the printing and cutting procedure by using the sample data first. In this procedure, you will create the sticker shown below. Printing and Cutting Procedure (Illustrator) Items Required Other than the Machine Printer...
  • Page 135 Printer Requirements You must use a laser or inkjet printer with a resolution of 720 dpi or greater. If the printed filled sections are blurred, crop marks will not be read correctly. Cut Studio/Plug-In for Illustrator Be sure to install these programs. http://startup.rolanddg.com/ Material This example uses A4-size material.
  • Page 136 Printing and Cutting Procedure (Illustrator) Procedure Step 1: Set the Printing and Cutting Areas Step 2: Position the Sample Data Step 3: Draw the Cutting Lines Step 4: Perform Printing Step 5: Load the Printed Material Step 6: Set the Alignment Method (Sensor Mode) Step 7: Perform Cutting (Sensor Mode)
  • Page 137 Step 1: Set the Printing and Cutting Areas Procedure Start Illustrator and open a new document. Set the artboard. From the Window menu, click Extensions, and then click Roland CutStudio. The Roland CutStudio palette appears.
  • Page 138 On the palette, click Crop marks are inserted in the artboard.
  • Page 139 Click , and then click Crop marks. Select the model name from the Type list, and then select 4 from the Point list.
  • Page 140 Point: Set the number of crop marks. Set the margins, and then click OK. Setting the Margins and the Distance between Crop Marks Step 2: Position the Sample Data...
  • Page 141 Step 2: Position the Sample Data Procedure Position the image data in the area within the crop marks. Position the data within this area. Step 3: Draw the Cutting Lines...
  • Page 142 Step 3: Draw the Cutting Lines Procedure Draw the cutting lines. Create a new layer for the cutting lines and draw the cutting lines there. Newly created layer Cutting line Save the data. Step 4: Perform Printing...

  • Page 144: Step 4: Perform Printing

    Step 4: Perform Printing Procedure Load the material in the printer. For details on how to load the material, see the instruction manual for your printer. * When expanded/reduced printing is enabled, disable it. Print at 100% scale. Hide the layer containing the cutting lines.
  • Page 145 From the File menu, click Print. The image is printed as shown in the figure below. Step 5: Load the Printed Material...
  • Page 146 Step 5: Load the Printed Material Procedure Check the origin for cutting of the printed material. Turn on the cutting machine. Wait for the initial operation to finish. Set the origin for cutting to the lower-left corner of the material, and then load the material in the machine.
  • Page 147 Position the left and right pinch rollers as shown in the figure. For A4-size material, do not use the middle pinch rollers. Using Narrow Material/Preventing Marking Made by the Middle Pinch Rollers (1) Position the pinch rollers outside the tool marks.
  • Page 148 Align the right edge of the material with the front and back gradations of the platen. Select the type of material. Using Various Types of Materials...
  • Page 149 Press [ENTER]. The pinch rolls lower and the carriage and material move. When the movement is finished, the cuttable width and length are displayed. Use [ ] and [ ] to move the material and position the crop marks above the blade protector. (1) Blade protector (2) Crop marks Press [ ] and [ ] to position the tip of the blade over the center of the...
  • Page 150 Do not set the origin. Crop marks cannot be read in the situations indicated below. If any of the following situations occur, remove the material, and then reload it. The left and right crop marks are slanted by 5 degrees or more with respect to the moving direction of the cutting carriage.
  • Page 151 *: Blade protector The material sometimes curls when it is printed on the printer. Do not use material that is curled as shown in the figure. The crop marks may not be read. If this happens, straighten out the material before loading it on the cutting machine. Step 6: Set the Alignment Method...
  • Page 152 Step 6: Set the Alignment Method (Sensor Mode) Position the crop marks automatically using the machine's integrated sensor. Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ], [ ], and then press [ ] to select SENSOR MODE.
  • Page 153 Step 7: Perform Cutting (Sensor Mode)
  • Page 154 Show the layer containing the cutting lines and select it. Check that all the cutting lines that you wish to cut are shown on the palette's preview screen. On the Roland CutStudio palette, select Output Current Layer, and then click Update.
  • Page 155 Click CutStudio starts, and the cutting data is sent to CutStudio.
  • Page 156 In CutStudio, click The screen shown in the following figure is displayed. Click OK. The cutting data is sent to the machine. When the machine receives the data, it automatically reads...
  • Page 157 the crop marks using a sensor, and then starts cutting. Crop Marks Cannot Be Read If the Sensor Fails to Read the Crop Marks If the sensor fails to read the crop marks, the screen in the figure appears. If this screen appears, proceed to "Crop Marks Cannot Be Read."...
  • Page 158 Preparations for Printing and Cutting (When Using CorelDRAW) Printing and Cutting Sample Data We recommend that you get comfortable with the printing and cutting procedure by using the sample data first. In this procedure, you will create the sticker shown below. Printing and Cutting Procedure (CorelDRAW) Items Required Other than the Machine Printer...
  • Page 159 Printer Requirements You must use a laser or inkjet printer with a resolution of 720 dpi or greater. If the printed filled sections are blurred, crop marks will not be read correctly. CutStudio/Plug-In for CorelDRAW Be sure to install these programs. http://startup.rolanddg.com/ Material This example uses A4-size material.
  • Page 160 Printing and Cutting Procedure (CorelDRAW) Procedure Step 1: Set the Printing and Cutting Areas Step 2: Position the Sample Data Step 3: Draw the Cutting Lines Step 4: Perform Printing Step 5: Load the Printed Material Step 6: Set the Alignment Method (Sensor Mode) Step 7: Perform Cutting (Sensor Mode)
  • Page 161 Step 1: Set the Printing and Cutting Areas Procedure Start CorelDRAW, and then open a new document. Set the document size. Click the plug-in's start button on the toolbar. The Roland CutStudio palette appears.
  • Page 162 On the palette, click Crop marks are inserted in the document.
  • Page 163 Click , and then click Crop marks. In the Type list, select GR-640/540/420. In the Point list, select 4.
  • Page 164 Point: Set the number of crop marks. Set the margins, and then click OK. Setting the Margins and the Distance between Crop Marks Step 2: Position the Sample Data...
  • Page 165 Step 2: Position the Sample Data Procedure Position the image data in the area within the crop marks. Position the data within this area. Step 3: Draw the Cutting Lines...
  • Page 166 Step 3: Draw the Cutting Lines Procedure Draw the cutting lines. Create a new layer for the cutting lines and draw the cutting lines there. Newly created layer Cutting line Save the data. Step 4: Perform Printing...

  • Page 168: Step 4: Perform Printing

    Step 4: Perform Printing Procedure Load the material in the printer. For details on how to load the material, see the instruction manual for your printer. * When expanded/reduced printing is enabled, disable it. Print at 100% scale. Hide the layer containing the cutting lines.
  • Page 169 From the File menu, click Print. The image is printed as shown in the figure below. Step 5: Load the Printed Material...
  • Page 170 Step 5: Load the Printed Material Procedure Check the origin for cutting of the printed material. Turn on the cutting machine. Wait for the initial operation to finish. Set the origin for cutting to the lower-left corner of the material, and then load the material in the machine.
  • Page 171 Position the left and right pinch rollers as shown in the figure. For A4-size material, do not use the middle pinch rollers. Using Narrow Material/Preventing Marking Made by the Middle Pinch Rollers (1) Position the pinch rollers outside the tool marks.
  • Page 172 Align the right edge of the material with the front and back gradations of the platen. Select the type of material. Using Various Types of Materials...
  • Page 173 Press [ENTER]. The pinch rolls lower and the carriage and material move. When the movement is finished, the cuttable width and length are displayed. Use [ ] and [ ] to move the material and position the crop marks above the blade protector. (1) Blade protector (2) Crop marks Press [ ] and [ ] to position the tip of the blade over the center of the...
  • Page 174 Do not set the origin. Crop marks cannot be read in the situations indicated below. If any of the following situations occur, remove the material, and then reload it. The left and right crop marks are slanted by 5 degrees or more with respect to the moving direction of the cutting carriage.
  • Page 175 *: Blade protector The material sometimes curls when it is printed on the printer. Do not use material that is curled as shown in the figure. The crop marks may not be read. If this happens, straighten out the material before loading it on the cutting machine. Step 6: Set the Alignment Method...
  • Page 176 Step 6: Set the Alignment Method (Sensor Mode) Position the crop marks automatically using the machine's integrated sensor. Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ], [ ], and then press [ ] to select SENSOR MODE.
  • Page 177 Step 7: Perform Cutting (Sensor Mode)
  • Page 178 Show the layer containing the cutting lines and select it. Check that all the cutting lines that you wish to cut are shown on the palette's preview screen. On the Roland CutStudio palette, select Output Current Layer, and then click Update.
  • Page 179 Click CutStudio starts, and the cutting data is sent to CutStudio.
  • Page 180 In CutStudio, click The screen shown in the following figure is displayed. Click OK. The cutting data is sent to the machine. When the machine receives the data, it automatically reads...
  • Page 181 the crop marks using a sensor, and then starts cutting. Crop Marks Cannot Be Read If the Sensor Fails to Read the Crop Marks If the sensor fails to read the crop marks, the screen in the figure appears. If this screen appears, proceed to "Crop Marks Cannot Be Read."...
  • Page 182 Preparations for Printing and Cutting (Manual Mode) Printing and Cutting Sample Data If you use the manual mode, you can perform printing and cutting without using CutStudio and Illustrator. We recommend that you get comfortable with the printing and cutting procedure by using the sample data first.
  • Page 183 Sample Data Open the Sample.bmp file found in the CutStudio installation folder (usually located in the CutStudio folder under Program Files on the C drive). Sample Data Cannot Be Found Printing and Cutting Procedure (Manual Mode)
  • Page 184 Printing and Cutting Procedure (Manual Mode) Procedure Step 1: Create Crop Mark Data Manually Step 2: Perform Printing Step 3: Load the Printed Material Step 4: Set the Alignment Method (Manual Mode) Step 5: Perform Cutting (Manual Mode)
  • Page 185 Step 1: Create Crop Mark Data Manually Create Crop Mark Data in Software Other than CutStudio, Illustrator, or CorelDRAW When drawing crop marks to add to an illustration in application software, take into account the margin necessary for cutting the material when setting the crop mark position. Crop Marks/Tool Marks Procedure Draw crop marks.
  • Page 186 Make a note of the distance between the crop marks (WIDTH and LENGTH). You will enter these values into the machine later. WIDTH LENGTH Make a note of the offset values. Check the origin (the point where both X and Y are 0) of the software that you are using. Make a note of the distance between this origin and the lower-left crop mark.
  • Page 187 Here, the lower-left corner of the paper surface is the origin in the software. Later explanations assume that the distance from the origin to the lower-left crop mark has the positional relationship shown in the following figure. Offset L: 45 mm Offset W: 25 mm Draw the illustration in the cutting area within the crop marks.
  • Page 188 Step 2: Perform Printing Procedure Load the material in the printer. For details on how to load the material, see the instruction manual for your printer. * When expanded/reduced printing is enabled, disable it. Print at 100% scale. Step 3: Load the Printed Material...
  • Page 189 Step 3: Load the Printed Material Procedure Load the material. Refer to "Step 5: Load the Printed Material" and ready the machine. Step 4: Set the Alignment Method (Manual Mode)
  • Page 190 Step 4: Set the Alignment Method (Manual Mode) Referring to the Menu Flow Chart as you proceed will help the setting procedure go smoothly. (1) Select Manual Mode Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure.
  • Page 191 Press [ENTER]. Press [ ] twice. (2) Enter the Distance between the Crop Marks Enter the values that you made a note of in Step 1, No. 3. WIDTH LENGTH Procedure...
  • Page 192 Press the [ ] key, and then press the [ ] key to display the screen shown in the figure. Use [ ] and [ ] to enter the horizontal distance (WIDTH) between the crop marks. Use [ENTER] to select the setting. Press the [ ] key, and then press the [ ] key.
  • Page 193 Use [ENTER] to select the setting. (3) Enter the Offset Values Enter the values that you made a note of in Step 1, No. 4. If you want to further reduce the misalignment after seeing the result of printing and cutting, measure the amount of cutting line misalignment, and then add this measured value to or subtract this measured value from the offset values.
  • Page 194 Use [ ] and [ ] to enter the amount of cutting line misalignment (in the width direction). Use [ENTER] to select the setting. Press the [ ] key, and then press the [ ] key. Use [ ] and [ ] to enter the amount of cutting line misalignment (in the length direction).
  • Page 195 Step 5: Perform Cutting (Manual Mode)
  • Page 196 Step 5: Perform Cutting (Manual Mode) Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Referring to the Menu Flow Chart as you proceed will help the setting procedure go smoothly.
  • Page 197 Perform steps 3 to 13 in "Cutting in Tool Mode (2)." Even if you perform all the steps up to step 13 in Cutting in Tool Mode (2), cutting will not start. To start cutting, perform step 4 shown below. When the screen shown in the figure below is displayed, send data from the computer.
  • Page 198 Cutting Perforated Lines Overview of Cutting Perforated Lines The machine can also cut material without carrier paper, such as coated paper. This function makes it easy to create point-of-purchase advertisements, cards, and other materials. Cutting Perforated Lines with CutStudio Step 1: Perform Preparations for Cutting Step 2: Create Perforated Line Data Step 3: Set Perforated Cutting Conditions Step 4: Cut Perforated Lines...
  • Page 199 Step 1: Perform Preparations for Cutting Procedure Perform preparations for cutting. Click the link below and perform the procedures from "Loading Roll Material" to "Creating Cutting Data (2)." Exercise caution regarding the position in which the cutting tool is installed. Loading Roll Material When cutting perforated lines, install the cutting tool in the position shown in the figure.
  • Page 200 Step 2: Create Perforated Line Data Procedure Create a shape or similar object. In this example, you will create a circle like that shown in the figure below. Click Objects set with perforated lines are displayed in red.
  • Page 201 From the File menu, click Preferences to display the Preferences dialog box. This lets you set the color and display of perforated lines. Step 3: Set Perforated Cutting Conditions Canceling Perforated Line Settings Procedure Use the tool to select the shape for which you want to cancel perforated line settings.
  • Page 202 The cutting lines turn black. Step 3: Set Perforated Cutting Conditions...
  • Page 203 Step 3: Set Perforated Cutting Conditions Procedure From the File menu, click Cutting Setup. Clear the Use perforated cutting conditions of machine check box.
  • Page 204 You can now enter the values. Enter the Perforated Cutting Conditions. Set the length of each perforation to make in the material (the perforation length) and the length of the part that is not perforated because the blade force is reduced (the half-cut length). Adjust the half-cut force to suit the type of material or paper used.
  • Page 205 Perforation length = Half-cut length Perforation length < Half-cut length Click OK. Step 4: Cut Perforated Lines...
  • Page 206 Step 4: Cut Perforated Lines Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Procedure Click The screen shown in the following figure is displayed. Select the type of cutting lines you want to use from the list.
  • Page 207 Frequently Using Perforated Cutting Click OK. Cutting starts. Adjusting Perforated Cutting Conditions Select optimum cutting conditions on the basis of the cutting results. Optimizing the Cutting Quality for the Material...
  • Page 208 Outputting Perforated Line Data from Illustrator * The screenshots show an example of Illustrator CC 2015, but the operation procedure is the same for other versions. * You must install Plug-in for Illustrator before proceeding. Installing Plug-in for Illustrator Procedure Create a new file and create a new design or open an existing file.
  • Page 209 From the Window menu, click Extensions, and then click Roland CutStudio. The Roland CutStudio palette appears. Select the object that you want to apply perforated lines to.
  • Page 210 Click Select Output Perforated Cut Lines.
  • Page 211 On the Roland CutStudio palette, click Update. Check that the cutting line that you wish to output is shown on the preview screen. Click CutStudio starts, and the cutting line data is sent to CutStudio. The output data is always aligned at the origin of CutStudio regardless of the position in Illustrator.
  • Page 212 Perform cutting. Performing Cutting...
  • Page 213 Outputting Perforated Line Data from CorelDraw * The screenshots show an example of CorelDRAW X8, but the operation procedure is the same for other versions. * You must install Plug-in for CorelDRAW before proceeding. Installing Plug-in for CorelDRAW Procedure Create a new document and create a new design or open an existing file. In this example, you will create the design shown in the figure below.
  • Page 214 The Roland CutStudio palette appears. Select the object that you want to apply perforated lines to.
  • Page 215 Click Select Output Perforated Cut Lines.
  • Page 216 On the Roland CutStudio palette, click Update. Check that the cutting line that you wish to output is shown on the preview screen. Click CutStudio starts, and the cutting line data is sent to CutStudio. The output data is always aligned at the origin of CutStudio regardless of the position in CorelDRAW.
  • Page 217 Perform cutting. Performing Cutting...
  • Page 218 Tiled Output Overview of Tiled Output Tiled output lets you split up data that is larger than the cutting area over multiple sheets. * Tiled output does not support the printing and cutting operation. Inner Margin Function ■ Without inner margin: Gap between edges ■...
  • Page 219 Procedure Step 1: Determine Output Size Step 2: Load the Material Step 3: Set Tiled Output Conditions Step 4: Enter Text and Shapes Step 5: Check Preview Step 6: Perform Cutting...
  • Page 220 Step 1: Determine Output Size Remember the basic procedure for tiled output while creating a large sticker like the one shown below. Follow the procedure below. Overview In this example, you will create an image with the dimensions indicated below. Keeping the completed size in mind when working will help the setting procedure go smoothly.
  • Page 221 Check the size of the material to be used. Step 2: Load the Material...
  • Page 222 Step 2: Load the Material Procedure Perform steps 1 to 8 in the procedure under "Loading Roll Material." Loading Roll Material Step 3: Set Tiled Output Conditions...
  • Page 223 Step 3: Set Tiled Output Conditions Procedure Start CutStudio. From the File menu, click Tiling.
  • Page 224 The Tiling dialog box is displayed.
  • Page 225 Click Change Size.
  • Page 226 Click Get from Machine. The cutting area is entered automatically. Once the cutting area has been entered, click OK. The segment size is updated.
  • Page 227 Select the Tiled Output check box, and then enter the number of tiles.
  • Page 228 Enter a value for the inner margin, then click OK. To enter a value for the inner margin, the overall size is updated automatically. Make sure Overall Size is larger than the size of the data determined in Step 1. Inner Margin Function...
  • Page 229 The document is displayed. The edges of the segments are displayed even if an inner margin has not been set. W: Overall Size width L: Overall Size length *1 Inner margin...
  • Page 230 Step 4: Enter Text and Shapes...
  • Page 231 Step 4: Enter Text and Shapes Procedure Enter text and/or shapes as desired. In this example, you will enter the data shown in the figure below. Step 5: Check Preview...
  • Page 232 Step 5: Check Preview Procedure From the File menu, click Cutting Preview. Click Next Page to display the segments in the cutting order. Cutting Order...
  • Page 233 Step 6: Perform Cutting...

  • Page 234: Step 6: Perform Cutting

    Step 6: Perform Cutting Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Procedure Make sure the material is loaded in the machine. Click Click OK.
  • Page 235 Click OK. Cutting starts. When cutting finishes, the message shown below will be displayed. Click OK.
  • Page 236 If you are using flat material, load new material before you click OK. Removing the Material Loading Flat Material Cutting starts. Repeat steps 3 and 4 in this procedure. Output the set number of tiles. Combine the output material. Align the margins to complete the procedure.
  • Page 238 Changing the Language Used for the Display The language for messages on the display can be selected. Procedure While holding down [MENU], switch on the power switch. Use [ ] to select the desired language. Press [ENTER] to select the setting. Other Things That You Can Do...
  • Page 239 Setting the Displayed Unit The unit used in messages on the display can be selected. Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press the [ ] key, the [ ] key, and then press the [ ] key.
  • Page 240 Press [ENTER] to select the setting. Use [MENU] to return to the screen in the figure. Other Things That You Can Do...
  • Page 241 Initializing All Settings to Their Default Values This procedure returns all settings to their factory default values. However, the language setting remains unchanged. Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure.
  • Page 242 You are returned to the screen in the figure. Other Things That You Can Do...

  • Page 243: Checking The Machine Status

    Execute a self test to check the status of the machine. Use this to check the machine when it appears to be not operating correctly. A computer is not required in order to carry out the self test. If the self test cannot be executed, the machine may have malfunctioned. Contact your authorized Roland DG Corp. dealer.
  • Page 244 Press [ENTER]. Operation is normal if the figure shown below is cut. Other Things That You Can Do...
  • Page 245 Changing the Contrast of the Display Screen Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ].
  • Page 246 Use [ ] and [ ] to select the screen brightness. Setting range: 1 to 5 Press [ENTER]. Other Things That You Can Do...
  • Page 247 Frequently Using Perforated Cutting There are two locations in which you can install the cutting carriage tool. Normally install it in the rear position. Install it in the front position when cutting perforated lines. Installing the Cutting Tool If you enable [BLADE DETECT] and send the cutting data, the tool's installation position will be checked before cutting starts.
  • Page 248 Press [ ] several times to display the screen shown in the figure. Press [ ]. Press [ ] several times to display the screen shown in the figure. Press [ ]. Use [ ] and [ ] to display the screen shown in the figure. Press [ENTER].
  • Page 250 Moving the Cutting Carriage at High Speed Press [ ] and [ ] to move the cutting carriage. Press [ ] and [ ] to move the material. Procedure This function can be used when the screen shown below is displayed. Press [ENTER] and one of the cursor keys ([ ], [ ], [ ], and [ ]) at the same time.
  • Page 251 Optimizing the Cutting Quality for the Material/Preventing Misaligned Cutting Optimizing the Cutting Quality for the Material Saving the Cutting Conditions Loading Cutting Conditions Cutting Detailed Characters and Complex Shapes Cutting in the Same Position Repetitively (OVERLAP) Cutting Corners Cleanly (Over Cut) Setting the Amount of Offset for the Tip of the Blade (OFFSET) Setting the Direction of the Coordinate Axis for Cutting (ROTATE) Extending the Cutting Area (WIDTH EXTEND)
  • Page 252 General Guide Regarding Cutting Conditions A general guide for cutting conditions and the service life of the blade for different combinations of materials and blades is given below. Note that optimal cutting is not necessarily obtained simply by conforming to the conditions below. Perform a cutting test in advance to adjust the conditions.
  • Page 253 Replace it with a new blade. Consumable Items If the desired cutting results are not obtained (for example, if uncut areas remain) even after the blade is replaced, refer to "Uncut Areas Remain or Cut Edges Are Not Clean." Improving the Finish...
  • Page 254 Saving the Cutting Conditions The current cutting conditions can be saved to memory. Eight sets of settings can be saved to USER 1 to USER 8 memories. Overwriting a memory deletes any old conditions it contains. Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure.
  • Page 255 Press [ENTER]. The screen shown in the following figure is displayed. Press [MENU] to return to the top screen. Though not shown on the display, the UPSPEED (the speed at which the blade moves when not cutting) and cut quality are also saved. Loading Cutting Conditions Other Things That You Can Do...
  • Page 256 Loading Cutting Conditions Cutting conditions saved to memory can be loaded. You can select the memory from USER 1 to USER 8. Note that loading cutting conditions from memory erases any cutting conditions that have not been saved. Saving the Cutting Conditions Procedure Make sure the material is loaded in the machine.
  • Page 257 Use [ ] and [ ] to select the memory number you wish to load. Press [ENTER] to execute the operation. Use [MENU] to return to the screen in the figure. Other Things That You Can Do...
  • Page 258 Cutting Detailed Characters and Complex Shapes (SMOOTHING) The smoothing function can be used to cut smooth curves such as arcs. Factory default setting ON Options ON, OFF ■ ON When curves in cutting results are not smooth ■ OFF When cutting small characters or complex shapes Procedure Make sure the material is loaded in the machine.
  • Page 259 Use [ ] and [ ] to select [ON] or [OFF]. Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 260 Cutting in the Same Position Repetitively <OVERLAP> The overlap function is used when it is not possible to cut through the material in a single pass, for example, when cutting thick material. Factory default setting OFF Setting range OFF, 1 to 10 Procedure Make sure the material is loaded in the machine.
  • Page 261 Press [ ]. Use [ ] to set the number of cuts. Setting range: 1 to 10 OVERLAP 2 → Normal cut + 2 → 3 cuts are made. Press [ENTER]. This setting remains enabled until you disable it. If you do not require it, disable it after use.
  • Page 262 Cutting Corners Cleanly <Over Cut> This function cuts an extra 1 mm at the start and end of each line. It is effective when you want to produce particularly sharp corners, for example when cutting thicker materials. In most cases the over cut function should be set to [OFF]. Set it to [ON] when you want to ensure that corners are cut cleanly.
  • Page 263 Press [ ]. Press [ ] several times to display the screen shown in the figure. Press [ ]. Press [ ] to select [ON]. Press [ENTER]. This setting remains enabled until you disable it. If you do not require it, disable it after use.
  • Page 264 Other Things That You Can Do...
  • Page 265 Setting Cutting Quality <QUALITY> This setting lets you set cutting quality. Factory default setting NORMAL NORMAL, HIGH SPEED, HEAVY NORMAL: This setting should be used for normal operation. Options HIGH SPEED: This setting should be used when you want to increase the cutting speed. HEAVY: This setting should be used when using thick or heavy material.
  • Page 266 Press [ ]. Use [ ] and [ ] to display the item that you want to set. Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 267 Setting the Amount of Offset for the Tip of the Blade <OFFSET> This setting lets you set the amount of offset for the tip of the blade. Set a value that matches the conditions for the blade installed. When using the included blade or equivalent parts, cutting can be performed using the factory default setting. (1) Offset amount (2) Blade tip (3) Blade centerline...
  • Page 268 Press [ ]. Press [ ] several times to display the screen shown in the figure. Press [ ]. Use [ ] and [ ] to set the value. Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 269 Setting the Direction of the Coordinate Axis for Cutting <ROTATE> This setting lets you set the direction of the coordinate axis for cutting. When set to [0deg] (default value), the origin is set to the lower-left corner of the material. When set to [90deg], the origin is set to the lower-right corner of the material, and the data is rotated counterclockwise by 90 degrees.
  • Page 270 Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] to display the screen shown in the figure. Press [ ]. Press [ ] several times to display the screen shown in the figure. Press [ ].
  • Page 271 Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 272 Extending the Cutting Area <EXTEND> It is possible to extend the cutting area by up to 20 mm. Factory default setting 0.00 mm (OFF) Setting range 0.1 to 10.0 mm Depending on the design to be cut, the pinch rollers may pass over the top of the cutting line. Example: Setting 0 mm →...
  • Page 273 The value of W displayed on the panel and the actual cut width are different. When you set the value according to the above example, the panel is displayed as shown in the figure below. * The panel indication is 210 mm, but the actual cut width is 220 mm When "EXTEND"...
  • Page 274 Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] to display the screen shown in the figure. Press [ ]. Press [ ] several times to display the screen shown in the figure. Press [ ].
  • Page 275 Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 276 Setting the Speed of the Blade During Cutting <UPSPEED> This setting lets you set the speed for moving the blade to the next cutting position with the blade lifted off the material during cutting operation. When this is set to [AUTO], the blade moves at the speed specified by [SPEED]. Increasing [UPSPEED] shortens the cutting time.
  • Page 277 Press [ ] or [ ] several times to display the screen shown in the figure. Press [ ]. Use [ ] and [ ] to set the value. Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 278 Changing the Blade Force If the material was not cut correctly (for example, if the result of the cutting test was that two shapes peeled off together), change the blade force. Procedure Check that the PEN FORCE slider is at the center position (at "0" on the scale).
  • Page 279 Press ［ ］ to display the following screen. Press [ ] and [ ] to change the blade force. Press [ENTER] to select the setting. Press [MENU] to return to the original screen. Fine-tuning the Blade Force After you set the blade force using the FORCE menu, you can further fine-tune the blade force using the PEN FORCE slider.
  • Page 280 Adjustable range: ±Approximately 30 gf * This value is intended only as a rough guide. The accuracy of this value is not guaranteed. Improving the Finish...
  • Page 281 Using Various Material Widths (Loading Position of Material) Loading Position of Material Set the pinch rollers so they are inside the grit patterns. Number Description Use the right pinch roller within this range. When the left edge of the material is placed on one of the grit rollers from 2 to 9, load the material so that its right edge is within the range of this wide grit roller.
  • Page 282 Pinch Roller/Grit Pattern 1: Grit pattern 2: Pinch roller Improving the Finish...
  • Page 283 Using Thinner or Harder Material than Normal You can use the fan to hold down the material and prevent misalignment. Change these settings to match the thickness and hardness of the material used. Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure.
  • Page 284 Press [ ]. Use [ ] and [ ] to select the air volume. 1: Weak ... 5: Strong, AUTO: Automatic Use a weaker air volume when using thin material. Press [ENTER]. Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 285 Preventing Misaligned Cutting Set this setting to [ON] to feed out the material automatically during cutting. While this setting is enabled, when cutting data is sent from the computer, cutting is performed every 1 meter after the material has automatically been fed forward (depending on the data, the material may be fed out more than 1 m, for example if the next movement point is more than 1 m back).
  • Page 286 Press [ ]. Use [ ] and [ ] to select [ON] or [OFF]. Setting the Material Feed Speed When the figure shown above is displayed, press [ ] twice to display the figure shown below. Press [ ] and [ ] to set the speed.
  • Page 287 Press [MENU] to return to the top screen. Other Things That You Can Do...

  • Page 288: Adjusting The Cutting Position

    Adjusting the Cutting Position If the printing position and the cutting position are offset as shown in the following figure, you can correct the issue by adjusting either the printing position or the cutting position. This example shows the procedure for adjusting the cutting position.
  • Page 289 To move the cutting line 0.5 mm to the left → Enter the W value *1: Intended cutting line *2: Actual cutting line To move the cutting line 0.5 mm down → Enter the L value To move the cutting line 0.7 mm up and 0.5 mm to the right → Enter both W and L values...
  • Page 290 1. Set the CROP-L value. Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ]. Press [ ] several times to display the screen shown in the figure.
  • Page 291 Press [ ] twice. The screen shown in the following figure is displayed. First enter the CROP-L value. Use [ ] and [ ] to enter the value. Refer to the section above titled "CROP-L/W Values" to enter the values. Press [ENTER].
  • Page 292 Press [ ]. Use [ ] and [ ] to enter the value. Press [ENTER]. When you have finished, press [MENU] to return to the screen in the figure. Send the cutting data. Perform cutting again and check the cutting position. Other Things That You Can Do...
  • Page 293 Changing the Cutting Speed If the material was not cut correctly (for example, if the result of the cutting test was that two shapes peeled off together), reduce the cutting speed. When the cutting speed is fast and the material moves up and down during cutting, an excessive load will be applied to the material.
  • Page 294 Press [ENTER] to select the setting. Press [MENU] to return to the original screen. Improving the Finish...

  • Page 295: Adjusting The Cutting-In Amount

    Adjusting the Cutting-in Amount When you want to perform accurate adjustment of the cutting-in amount, such as when cutting material with thin carrier paper, you can obtain good results by adjusting the amount of blade extension. Turn the cap portion of the blade holder to adjust the amount of blade extension. An adjustment of 0.5 millimeters can be made by rotating the cap one full turn.
  • Page 296 4: 1/2 of the carrier paper Improving the Finish...
  • Page 297 Cutting the Same Object Repetitively Replot The data received from the computer can be saved to the machine's memory. This data can then be recut. To recut, use the [REPLOT] menu in the display menu. All the data received from the time the machine is put in the setup condition to the time the setup condition is canceled is saved.
  • Page 298 Step 1: Prepare the Data for Recutting Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Clear all data remaining in the machine's memory, and then send new data so that only the required data is stored in the machine's memory.
  • Page 299 Use [ ] and [ ] to select [CLEAR]. Press [ENTER]. The data is cleared. Send data from the computer. To next procedure...
  • Page 300 Step 2: Perform Recutting Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Procedure Make sure the material is loaded in the machine. Press [MENU] several times to display the screen shown in the figure.
  • Page 301 Press [ENTER]. You are returned to the screen in the figure, and cutting is performed. To previous procedure...
  • Page 302 Using the Material with Minimal Waste Setting the Origin You can use [ORIGIN] to freely set the position of the origin. You can use the material with minimal waste by setting the origin to an uncut position on the material. Procedure Load the material in the machine, and make it ready for cutting (setup condition).
  • Page 303 Hold down [ORIGIN] for one second or longer. [ORIGIN SET] flashes on the display. When the setting is complete, the following screen appears. Send the cutting data from the computer. Cutting is performed using the specified origin. Improving the Finish...
  • Page 304 Using Narrow Material/ Preventing Marking Made by the Middle Pinch Rollers When using narrow material and when using material that is easily marked by the pinch rollers, use just the pinch rollers on the ends to feed the material. In this mode, the middle pinch rollers are not used (they are disabled).
  • Page 305 Press [ ]. Press [ ] or [ ] to display the screen shown in the figure. This setting will be enabled the next time the pinch rollers are lowered. Press [ENTER]. Press [MENU] to return to the top screen. Reducing the Force of the Middle Pinch Rollers When using a wide sheet for which it is useful to use the middle pinch rollers in order to prevent the material from coming loose during cutting but is also easily marked by rollers, reduce the force with which the pinch...
  • Page 306 Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ]. Press [ ] to display the screen shown in the figure. Press [ ]. Press [ ] or [ ] to set this to [SLIGHT].
  • Page 307 Press [MENU] to return to the top screen. Other Things That You Can Do...
  • Page 308 Other Things That You Can Do Changing or Checking the Machine's Operation Changing the Language Used for the Display Setting the Displayed Unit Initializing All Settings to Their Default Values Checking the Machine Status <Self Test> Changing the Contrast of the Display Screen Frequently Using Perforated Cutting Minimizing Wasted Material Setting the Direction of the Coordinate Axis for Cutting <ROTATE>...
  • Page 309 Using Thinner or Harder Material than Normal Preventing Misaligned Cutting Adjusting the Cutting Position Adjusting the Printing Position Adjusting the Cutting Quality and Saving and Reusing the Adjusted Conditions Saving the Cutting Conditions Loading Cutting Conditions Creating Copies of the Same Object Cutting the Same Object Repetitively Moving the Carriage at High Speed Moving the Cutting Carriage at High Speed...
  • Page 310 Improving the Finish Optimizing the Cutting Quality for the Material Performing a Cutting Test Changing the Blade Force Changing the Cutting Speed Adjusting the Cutting-in Amount Cutting Conditions General Guide Regarding Cutting Conditions Using a Variety of Materials Using Various Types of Materials Loading Flat Material Using Various Material Widths (Loading Position of Material) Minimizing Wasted Material...

  • Page 311: Maintenance/Replacement

    Maintenance/Replacement Cleaning Cleaning Replacing the Blade and the Separating Knife Replacing the Blade and the Separating Knife Consumable Items Consumable Items...
  • Page 312 Cleaning Cleaning is important in order to ensure clean cutting. Clean the machine periodically. Cleaning the Blade Holder Cap Be sure to perform operations as specified by the instructions, and never touch any CAUTION area not specified in the instructions. Sudden movement of the machine may cause injury or burns.
  • Page 313 1: Grit rollers Periodically wipe away any grime. 2: Display: Wipe the display clean with a dry cloth. 3: Pinch rollers Remove any buildup of media and other material using a brush. Never use a metal brush. Cleaning the Blade Holder Cap If there is a buildup of pieces of material or dust inside the cap, loosen the cap, remove it, and then remove any foreign matter.
  • Page 314 Replacing the Blade and the Separating Knife If the blade becomes dull, replace it with a replacement blade. Consumable Items Be sure to perform operations as specified by the instructions, and never touch any CAUTION area not specified in the instructions. Sudden movement of the machine may cause injury or burns.
  • Page 315 Never touch the tip of the blade. CAUTION Doing so may result in injury. Remove the old blade.
  • Page 316 1: Press this pin. 2: Old blade Install a new blade. 1: New blade 2: Cutting tool with the new blade installed. Install the cutting tool.
  • Page 317 Installing the Cutting Tool Replacing the Separating Knife Procedure Remove the separating knife. (1) Loosen the screw until it slips out. (2) Grasp the screw portion, and then slowly pull it out in the direction of the arrow. When doing this, do not pull it back toward you. Install a new knife.
  • Page 318 The knife is secured in place by the magnet. 1: Magnet 2: Positioning groove Slowly insert the knife into the groove. Tighten the screw. Take care to ensure that the knife does not slip out of position at this time.

  • Page 319: Consumable Items

    Consumable Items Purchasing Consumable Items To purchase consumable items, visit the Roland DG Corp. website (http://www.rolanddg.com/) or contact your authorized Roland DG Corp. dealer. Blade Blade In the cases below, the blade has reached the end of its service life. Replace it with a new item.
  • Page 320 If cutting is performed when the blade protector is scratched, it will not be possible to cut cleanly. If the surface of the blade protector is deformed due to scratching or similar damage, the blade protector must be replaced. Contact your authorized Roland DG Corp. dealer.

  • Page 321: Troubleshooting

    Troubleshooting The Machine Doesn't Run The Machine Doesn't Run The Material Is Jammed Jammed Material Cannot Be Removed Flat Material Cannot Be Set Up Using "PIECE" (Length Is Not Displayed) Flat Material Cannot Be Set Up Using "PIECE" (Length Is Not Displayed) Creating or Importing Data Changing the Darkness of an Aligned Image Illustrator Data Cannot Be Imported...

  • Page 322: Frequently Asked Questions

    The Machine Cuts the Same Area Twice Installing and Uninstalling Software The Driver Cannot Be Installed (Windows 10) The Driver Cannot Be Installed (Windows 8.1) The Driver Cannot Be Installed (Windows 7) Uninstalling the Driver (Windows 10) Uninstalling the Driver (Windows 8.1) Uninstalling the Driver (Windows 7) Connecting Two or More Instances of This Machine to a Single Computer (Connecting Multiple Units with a USB Cable)

  • Page 323: The Machine Doesn't Run

    If the Machine Does Not Run Even after You Have Checked the Above Points Perform a self test. If the self test cannot be executed, the machine may have malfunctioned. Contact your authorized Roland DG Corp. dealer. Checking the Machine Status (Self Test)
  • Page 325 The Material Slips Away from the Pinch Rollers during Cutting Is the material loaded in parallel with the gradations of the ruler? If the front edge of the material is cut at an angle, trim off an excess portion so that the front edge is parallel with the gradations of the ruler, and then load the material.
  • Page 327 Crop Marks Cannot Be Read When the machine cannot read crop marks, it displays an error message and pauses operation. If this happens, press any key on the operation panel. Remove the material, check the following items, and then reload the material. "CROPMARK ERR"...
  • Page 328 Are the size and shape of crop marks correct? Make the crop marks perfect circles 10 mm (0.39 in.) in diameter. The machine can only detect crop marks in the prescribed shape. Crop Marks Are the crop marks at the correct positions? Refer to "Setting the Margins and the Distance between Crop Marks"...
  • Page 329 "LENGTH NG," "WIDTH NG," or "ANGLE TOO BIG" Is Displayed Is the material loaded at an angle? Are the printing results crooked? Crop marks cannot be detected in the following cases: The left and right crop marks are slanted by 5 degrees or more with respect to the moving direction of the carriage.
  • Page 330 Illustrator Data Cannot Be Imported Is the data saved in Illustrator 8.0 or EPS 8.0 format? Illustrator 8.0 and EPS 8.0 are the Illustrator file formats that can be imported into CutStudio. If using a higher version, save files as a lower version before importing. File Formats That Can Be Imported into CutStudio...
  • Page 331 Procedure Copy the Symbol folder from the path below. Store the folder in a desired location or move it. C:¥ProgramData¥Roland DG Corporation¥CutStudio¥Symbol If the Folder Is Not Displayed In "Sample Data Cannot Be Found," configure the settings for displaying hidden folders.
  • Page 332 Sample Data Cannot Be Found Location of Sample Data Folder Open the Sample.bmp file found in the CutStudio installation folder (usually located in the CutStudio folder under Program Files on the C drive). Is the computer not set to show hidden folders? Sample data may not be displayed in some cases depending on the computer settings.
  • Page 333 Click the View tab. Select the Hidden items check box.
  • Page 334 Windows 7 Procedure From the Start menu, click Computer. In the Organize menu, click Folder and search options. The screen shown in the following figure is displayed.
  • Page 335 Click the View tab, and then select the Show hidden files, folders, and drives option.
  • Page 336 Click OK.
  • Page 337 Changing the Darkness of an Aligned Image It is possible to change the darkness of an image imported into CutStudio. Procedure From the File menu, click Preferences. On the General tab, enter a value in the Image Darkness box. Setting range: 1 to 100%...
  • Page 338 Click OK.
  • Page 339 The Results of Cutting Are Displaced When Using the Printing and Cutting Function Is a thick material being used? When using thick material, set [Cutting Quality] to [HEAVY]. Setting Cutting Quality <QUALITY> When using roll material, was the amount of material to be cut pulled out before performing cutting? If cutting is performed without pulling out the material, the material may slip or a motor error may stop the operation...

  • Page 340: Adjusting The Printing Position

    Adjusting the Printing Position If the printing position and the cutting position are offset as shown in the following figure, you can correct the issue by adjusting either the printing position or the cutting position. This example shows the procedure for adjusting the printing position.
  • Page 341 Select the Fine adjustment check box, and then click Adjust.
  • Page 342 The Crop Mark Adjustment dialog box appears.
  • Page 343 Align the position with respect to a line or point that is close to the origin. Adjust the Base X and Base Y values to eliminate the offset, and then click OK. Do not change the W and L values at this point. Align the position with respect to this side.
  • Page 344 (3): Printing position The Cutting Position Is Offset to the Left or Right of the Printing Position Change the Base X value. If the cutting position is offset to the right of the printing position, increase the value; if it is offset to the left of the printing position, decrease the value. In the case shown in the above figure, increase Base X.
  • Page 345 (1): Origin (2): Cutting line (3): Printing position The actual distance is longer than the W and L settings. Set W and L in the Crop Mark Adjustment dialog box as described below to correct the error. However, the values are merely guidelines. The optimal values must be found by changing the values and actually cutting the material several times.
  • Page 346 (1): Origin (2): Cutting line (3): Printing position The Cutting Lines Are Offset Inward from the Printing Position This may be because the distance between the printed crop marks is shorter than the setting. In this case, set the W and L values smaller than the settings to make the adjustment. (1): Origin (2): Cutting line (3): Printing position...
  • Page 347 Back (to "Adjusting the Cutting Position")
  • Page 348 The Machine Cuts the Same Area Twice Is Overlap Cutting set to 0 in CutStudio? If Overlap Cutting is set to any number other than 0 on the Cut screen, the number is added to the number of cuts. Is the machine's [OVERLAP] setting a number from 1 to 10? Set the machine's [OVERLAP] setting to [OFF].
  • Page 349 Uncut Areas Remain or Cut Edges Are Not Clean Are the blade and blade holder securely installed? Make sure the screws are tightened securely so that they do not come loose during cutting. Installing the Cutting Tool Is the tip of the blade broken? If it is, replace the blade with a new one.
  • Page 350 Setting Cutting Quality <QUALITY> Is the blade force appropriate? Carry out cutting tests and adjust the blade force until cutting can be performed adequately. Performing a Cutting Test Is the amount of blade offset appropriate? If the setting for the amount of blade offset is not correct for the blade, corners may be rounded or have horns.
  • Page 351 If the blade protector is damaged, the material may not be cut correctly even if the machine's settings and the installation of the blade and blade holder are all correct. If this happens, contact your authorized Roland DG Corp. dealer. Consumable Items (Blade Protector)
  • Page 352 Uncut Portions Remain Is a thick material being used? When using thick material, set [Cutting Quality] to [HEAVY]. Setting Cutting Quality <QUALITY> When using roll material, was the amount of material to be cut pulled out before performing cutting? If cutting is performed without pulling out the material, the material may slip or a motor error may stop the operation...
  • Page 353 The Machine Cuts the Carrier Paper Are the blade tip adjustment and blade force appropriate for the material being cut? Perform a cutting test and adjust the blade tip and blade force appropriately. Performing a Cutting Test General Guide Regarding Cutting Conditions Adjusting the Cutting-in Amount...
  • Page 354 Using Various Types of Materials Using Roll Material Never load media that weighs over 40 kg (88.19 lb.). CAUTION The machine may fail to withstand the weight, causing the machine to tip over or the material to fall. Loading Roll Material Using Flat Material If flat material is used, it must be at least 60 mm longer than the vertical size of the cutting data.
  • Page 355 Using Material with Perforations for Sprocket Feed Sprocket-fed material has perforations along each edge. If the pinch rollers are positioned over the perforations, the material cannot be fed correctly. Load the material as shown in the figure. Improving the Finish...
  • Page 356 Loading Flat Material This example uses flat, A4-size material to explain how to load the material. If using roll material or other material, refer to "Loading Roll Material" and load the material. Procedure If the pinch rollers have lowered, press [PINCH]. Check that the pinch rollers have risen.
  • Page 357 2: Right edge of the material Slide the material to place its left edge over the grit roller. At this point, check that the right edge of the material remains over the grit roller on the right edge. 1: Grit roller 2: Left edge of the material Straighten the material.
  • Page 358 Place the left and right pinch rollers over the grit rollers on both edges of the material. Position the pinch rollers on the edges so that each one is 25 mm or more inside of the respective left or right edge of the material. *: 25 mm or more The middle pinch rollers are not used with A4-size material.
  • Page 359 If the condition of the material is as described below, stretch or flatten it before use. The material is curled upward. The leading edge of the material is bent or creased. Improving the Finish...
  • Page 360 Flat Material Cannot Be Set Up Using "PIECE" (Length Is Not Displayed) Is the material 1.6 m or longer? If flat material 1.6 m or longer is set up using "PIECE," the machine recognizes it as a roll. Using Various Types of Materials...
  • Page 361 The Driver Cannot Be Installed (Windows 10) If you have canceled installation or if the installation wizard does not appear when the USB cable is connected, follow the procedure shown below. Procedure Connect the machine to the computer with the USB cable and turn on the machine.
  • Page 362 From the View menu, click Show hidden devices. Search the list for Printers or Other devices, and then double-click it. The name of your machine or Unknown device appears below the selected item. Click the name to select it. From the Action menu, click Uninstall. On the Confirm Device Uninstall window, click OK.
  • Page 363 http://startup.rolanddg.com/...
  • Page 364 The Driver Cannot Be Installed (Windows 8.1) If you have canceled installation or if the installation wizard does not appear when the USB cable is connected, follow the procedure shown below. Procedure Connect the machine to the computer with the USB cable and turn on the machine.
  • Page 365 Click Device Manager. If a User Account Control window appears, click Allow. Device Manager appears. From the View menu, click Show hidden devices. Search the list for Printers or Other devices, and then double-click it. The name of your machine or Unknown device appears below the selected item. Click the name to select it.
  • Page 366 Follow the procedure in "Installing the Driver for Windows" and reinstall the driver from the beginning. http://startup.rolanddg.com/...
  • Page 367 The Driver Cannot Be Installed (Windows 7) If you have canceled installation or if the installation wizard does not appear when the USB cable is connected, follow the procedure shown below. Procedure Connect the machine to the computer with the USB cable and turn on the machine.
  • Page 368 Search the list for Printers or Other devices, and then double-click it. The name of your machine or Unknown device appears below the selected item. Click the name to select it. From the Action menu, click Uninstall. On the Confirm Device Uninstall window, select the Delete the driver software for this device check box, and then click OK.
  • Page 370 Uninstalling the Driver (Windows 10) To uninstall the driver, follow the procedure below. Procedure Switch off the machine, and then disconnect the connector cable between the computer and the machine. Log on to Windows as the computer's administrator. Right-click the Start menu, click Control Panel, and then click Uninstall a program.
  • Page 371 If a window prompting you to restart the computer appears, click Yes. The uninstall procedure is complete when the computer finishes restarting. * Download the driver for the machine you want to delete from the Roland DG Corp. website (http://www.rolanddg.com/), and then select a folder to extract the files into.
  • Page 372 Installation Procedure...
  • Page 373 Uninstalling the Driver (Windows 8.1) To uninstall the driver, follow the procedure below. Procedure Switch off the machine, and then disconnect the connector cable between the computer and the machine. Start Windows. Click Desktop. Move the mouse pointer to the lower-right corner of the screen to display the Charms bar, and then click Settings.
  • Page 374 then click Uninstall. A deletion confirmation message appears. Click Yes. From the Start menu, click Desktop. Open File Explorer, and then open the drive and folder containing the driver.* Double-click SETUP64.EXE (64-bit version) or SETUP.EXE (32-bit version). If a User Account Control window appears, click Allow. The setup program for the driver starts.
  • Page 375 If you can see the icon of the machine to delete, right-click it, and then click Remove device. * Download the driver for the machine you want to delete from the Roland DG Corp. website (http://www.rolanddg.com/), and then select a folder to extract the files into.
  • Page 376 Uninstalling the Driver (Windows 7) To uninstall the driver, follow the procedure below. Procedure Switch off the machine, and then disconnect the connector cable between the computer and the machine. Log on to Windows as the computer's administrator. From the Start menu, click Control Panel, and then click Uninstall a program.
  • Page 377 If a window prompting you to restart the computer appears, click Yes. The uninstall procedure is complete when the computer finishes restarting. * Download the driver for the machine you want to delete from the Roland DG Corp. website (http://www.rolanddg.com/), and then select a folder to extract the files into.
  • Page 379 Connecting Two or More Instances of This Machine to a Single Computer (Connecting Multiple Units with a USB Cable) When connecting multiple instances of this machine to a single computer with a USB cable, you must change the USB number of each machine so that the computer can distinguish between output destinations. The machine's default setting is "A."...
  • Page 380 (1) Change the Name of the Second Cutting Machine Follow the procedure below to connect a second machine. The same procedure can be used to connect a third unit and any subsequent units. Procedure * Do not connect the USB cable at this stage. Turn off the power of the machine.
  • Page 381 (2) Connect and Change the Computer's Printer Settings Procedure Connect the machine to the computer using the USB cable. The driver is installed. Open Devices and Printers. Roland GR-640 (Copy 1) (or 1 Copy) is created. (Hereinafter, this is referred to as "Copy 1.")
  • Page 382 From the Start screen, click Apps, and then click Control Panel. Click Hardware and Sound, and then click Devices and Printers. Windows 7 From the Start menu, select Devices and Printers. Right-click Roland GR-640 (Copy 1), and then select Printer properties.
  • Page 383 Change Roland GR-640 (Copy 1) to Roland GR-640 (B).
  • Page 384 Click OK. (3) Check That the Second Cutting Machine Has Been Installed Procedure Start CutStudio. From the File menu, click Cutting Setup.
  • Page 385 Click the Printer Name. Check that GS-640 (B) is displayed. If the screen looks similar to the one displayed in the figure below, the second machine is connected correctly.
  • Page 386 If the driver was not installed correctly, it may be displayed as "Unspecified" in some cases. Try the installation method described at the link below. The Driver is Displayed as "Unspecified" URLs contained in this manual are subject to change without notice. If a link appears to be broken, contact your authorized Roland DG Corp. dealer.
  • Page 387 Troubleshooting Creating or Importing Data Changing the Darkness of an Aligned Image Illustrator Data Cannot Be Imported Sample Data Cannot Be Found Crop Marks Cannot Be Read Crop Marks Cannot Be Read Cutting Results Are Not Clean The Results of Cutting Are Displaced When Using the Printing and Cutting Function The Machine Cuts the Same Area Twice Frequently Asked Questions Moving a Saved Symbol to a New Computer...

  • Page 388: Error Message List

    Error Message List Index Solution Cause Press any key to cancel setup and clear the error message. Move the pinch rollers to the correct positions and reload the material. * Note: If the message appears even if the pinch rollers are moved to the correct positions, the machine may be exposed to Pinch rollers are at positions where the direct sunlight or intense indoor lighting.
  • Page 389 interpret was sent. Press any key to clear the error message. The number of parameters differs from the Review the data sent from the computer, permissible number. and then send the correct data. The value of the specified parameter was outside the permissible range.
  • Page 390 The material came loose during cutting. Loading Position of Material Switch off the power and contact your authorized Roland DG Corp. dealer. Install the cutting tool again. The cutting tool was installed in the position for cutting perforated lines.
  • Page 391 Menu Flow Chart...

  • Page 397: Specifications

    0 to 1,750 mm 0 to 1,496 mm 0 to 1,172 mm Usable tools Roland CAMM-1 series blade (including blades for flatbed use) During cutting: 1,050 mm/sec. (all directions) Maximum cutting speed With blade raised: 1,485 mm/sec. (45° direction) Cutting speed 10 to 1,050 mm/sec.
  • Page 398 (for details, see the setup guide), setup guide *1: According to material and cutting conditions as specified by Roland DG Corporation *2: Excluding expansion/contraction of the material *3: [Range for assured repetition accuracy]...
  • Page 399 Creating Cutting Data * You must install Plug-in for Illustrator before proceeding. Installing Plug-in for Illustrator Procedure Start Illustrator. In Illustrator, click Extensions > Roland CutStudio from the Window menu. The "Roland CutStudio" palette appears.
  • Page 400 Open a new document, and then set the artboard. Set the document size to be the same as the cutting width displayed on the machine. Set a length that is longer than the product that you want to create. Enter "SALE." After you enter the text, change the size of the characters, and then drag the text to the bottom of the document.
  • Page 401 Position characters and shapes in the lower-left corner of the document. It is better to position characters and shapes starting from the bottom of the document. This makes it possible to prevent feeding more of the material than needed. Illustrator screen Actual cutting position...
  • Page 402 Select the Auto Update check box in the palette. With "SALE" selected, click An outline is created.
  • Page 403 Use Illustrator's rectangle tool to draw a frame around "SALE." Save the data. Performing Cutting...
  • Page 405 Performing Cutting Once the data has been prepared you are ready to start cutting. Changing and Checking the Cut Settings Procedure On the palette, select Output All Lines, and then click Update. Check that all the contour lines that you wish to cut are shown on the palette's preview screen.
  • Page 406 On the palette, click The screen shown in the following figure is displayed. Select the model name of the machine on hand, and then click Cut. Cutting starts. If the model name is not displayed, see "The Machine Doesn't Run." When cutting is finished, click Exit to close the window.
  • Page 407 Configuring Cut Settings from a Computer Procedure Click on the palette, and then click Preferences. Select the Use cut settings check box, and then click OK. Click on the palette, and then click Cut Settings. Cutting Setup will not be displayed if you do not perform steps 1 and 2.
  • Page 408 When You Do Not Select the Use Machine Settings Check Box Cutting is performed with the settings shown in the following figure (the Cut Setup screen).
  • Page 409 When You Select the Use Machine Settings Check Box Cutting is performed with the machine settings. Click OK. To Cancel Cutting Procedure Press [PAUSE]...
  • Page 410 Hold down [ENTER] for one second or longer. The data is canceled. Removing the Material...
  • Page 411 Sending Data from Illustrator You can output cutting line data drawn with Adobe Illustrator to the cutting machine. To output data it is necessary to install a plug-in. Required Items Plug-in for Illustrator Installing Plug-in for Illustrator Install Plug-in for Illustrator on the computer on which Illustrator is installed. Sending Data from Illustrator Outputting Data Created in Illustrator Viewing Help...
  • Page 412 * The screenshots show an example of Illustrator CC 2015, but the operation procedure is the same for other versions. You must install Plug-in for Illustrator before proceeding. Installing Plug-in for Illustrator Procedure Start Illustrator. In Illustrator, click Extensions > Roland CutStudio from the Window menu. The "Roland CutStudio" palette appears.
  • Page 413 Create a new file and create a new design or open an existing file. In this example, you will create the design shown in the figure below. Change the characters to outline data.
  • Page 414 When you select characters and click on the palette, the characters change to outline data. Select Output All Lines.
  • Page 415 On the Roland CutStudio palette, select the Auto Update check box. Check that the cutting line that you wish to output is shown on the preview screen. Click The following dialog box appears.
  • Page 416 Select the model name of the machine on hand, and then click Cut. The cutting data is output.
  • Page 417 Viewing Help (Illustrator) Procedure On the Roland CutStudio palette, click , and then click Help.
  • Page 418 Printing and Cutting Printing and Cutting Overview Your favorite picture can be printed and cut. This makes it easy to create your own original stickers. Flow Diagram Create the data in Illustrator. Print the data with the printer. (Use the printer that you have on hand.)
  • Page 419 Cut the printed material. Your original sticker is complete! Materials That Can Be Used for Printing and Cutting Materials That Can Be Used for Printing and Cutting Printing and Cutting with Illustrator Preparations for Printing and Cutting (When Using Illustrator) Printing and Cutting Procedure (Illustrator)
  • Page 420 Setting the Margins and the Distance between Crop Marks Set the margins and the distance between crop marks. Take into account the margin necessary for cutting the material and set the crop mark position. When Using Illustrator * When using material with a large amount of feed (long material), we recommend that you set the left and right margins to approximately 25 mm.
  • Page 421 B4 portrait W: 217 mm, L: 269 mm X: 10 mm, Y: 45 mm B4 landscape W: 324 mm, L: 162 mm * If you are using material that is larger than the sizes listed above, set the values by referring to the figure below.
  • Page 422 Switching between 3 and 4 Crop Marks In most cases you should use 4 crop marks. Switching to 3 Crop Marks Procedure Click , and then click Crop marks.
  • Page 423 From the Point list, select 3. Click OK. Setting the Margins and the Distance between Crop Marks...
  • Page 424 Preparations for Printing and Cutting (When Using Illustrator) Printing and Cutting Sample Data We recommend that you get comfortable with the printing and cutting procedure by using the sample data first. In this procedure, you will create the sticker shown below. Printing and Cutting Procedure (Illustrator) Items Required Other than the Machine Printer...
  • Page 425 Printer Requirements You must use a laser or inkjet printer with a resolution of 720 dpi or greater. If the printed filled sections are blurred, crop marks will not be read correctly. Plug-In for Illustrator Be sure to install this program. Installing Plug-In for Illustrator Material This example uses A4-size material.
  • Page 426 Printing and Cutting Procedure (Illustrator) Procedure Step 1: Set the Printing and Cutting Areas Step 2: Position the Sample Data Step 3: Draw the Cutting Lines Step 4: Perform Printing Step 5: Load the Printed Material Step 6: Set the Alignment Method (Sensor Mode) Step 7: Perform Cutting (Sensor Mode)
  • Page 427 Loading Roll Material Start Illustrator. Open a new document, and then set the artboard. Set the document size to be the same as the cutting width displayed on the machine. From the Window menu, click Extensions, and then click Roland CutStudio.
  • Page 428 The Roland CutStudio palette appears. On the palette, click Crop marks are inserted in the artboard.
  • Page 429 Click , and then click Crop marks. Select the model name from the Type list, and then select 4 from the Point list.
  • Page 430 Point: Set the number of crop marks. Set the margins, and then click OK. Setting the Margins and the Distance between Crop Marks Step 2: Position the Sample Data...
  • Page 431 Step 2: Position the Sample Data Procedure Position the image data in the area within the crop marks. Position the data within this area. Step 3: Draw the Cutting Lines...
  • Page 432 Step 3: Draw the Cutting Lines Procedure Draw the cutting lines. Create a new layer for the cutting lines and draw the cutting lines there. Newly created layer Cutting line Save the data. Step 4: Perform Printing...
  • Page 434 Step 4: Perform Printing Procedure Load the material in the printer. For details on how to load the material, see the instruction manual for your printer. * When expanded/reduced printing is enabled, disable it. Print at 100% scale. Hide the layer containing the cutting lines.
  • Page 435 From the File menu, click Print. The image is printed as shown in the figure below. Step 5: Load the Printed Material...
  • Page 436 Step 5: Load the Printed Material Procedure Check the origin for cutting of the printed material. Turn on the cutting machine. Wait for the initial operation to finish. Set the origin for cutting to the lower-left corner of the material, and then load the material in the machine.
  • Page 437 Position the left and right pinch rollers as shown in the figure. For A4-size material, do not use the middle pinch rollers. Using Narrow Material/Preventing Marking Made by the Middle Pinch Rollers (1) Position the pinch rollers outside the tool marks.
  • Page 438 Align the right edge of the material with the front and back gradations of the platen. Select the type of material. Using Various Types of Materials...
  • Page 439 Press [ENTER]. The pinch rolls lower and the carriage and material move. When the movement is finished, the cuttable width and length are displayed. Use [ ] and [ ] to move the material and position the crop marks above the blade protector. (1) Blade protector (2) Crop marks Press [ ] and [ ] to position the tip of the blade over the center of the...
  • Page 440 Do not set the origin. Crop marks cannot be read in the situations indicated below. If any of the following situations occur, remove the material, and then reload it. The left and right crop marks are slanted by 5 degrees or more with respect to the moving direction of the cutting carriage.
  • Page 441 *: Blade protector The material sometimes curls when it is printed on the printer. Do not use material that is curled as shown in the figure. The crop marks may not be read. If this happens, straighten out the material before loading it on the cutting machine. Step 6: Set the Alignment Method...
  • Page 442 Step 6: Set the Alignment Method (Sensor Mode) Position the crop marks automatically using the machine's integrated sensor. Procedure Press [MENU] several times to display the screen shown in the figure. Press [ ] several times to display the screen shown in the figure. Press [ ] once, and then press [ ] several times to select [SENSOR MODE] Press [ENTER] to select the setting.
  • Page 443 Step 7: Perform Cutting (Sensor Mode)
  • Page 444 Show the layer containing the cutting lines and select it. Check that all the cutting lines that you wish to cut are shown on the palette's preview screen. On the Roland CutStudio palette, select Output Current Layer, and then click Update.
  • Page 445 Click The screen shown in the following figure is displayed. If you want to check the cutting settings, refer to "Configuring Cutting Settings from a Computer."...
  • Page 446 Select the model name of the machine on hand, and then click Cut. If the model name is not displayed, see "The Machine Doesn't Run" in "Troubleshooting." The cutting data is sent to the machine. When the machine receives the data, it automatically reads the crop marks using a sensor, and then starts cutting.
  • Page 447 Removing the Material...
  • Page 448 Cutting Perforated Lines Overview of Cutting Perforated Lines The machine can also cut material without carrier paper, such as coated paper. This function makes it easy to create point-of-purchase advertisements, cards, and other materials. Step 1: Perform Preparations for Cutting Step 2: Create Perforated Line Data Step 3: Set Perforated Cutting Conditions Step 4: Cut Perforated Lines...
  • Page 449 Step 1: Perform Preparations for Cutting Procedure Perform preparations for cutting. Click the link below and perform the procedures from "Loading Roll Material" to "Setting the Origin." Exercise caution regarding the position in which the cutting tool is installed. Loading Roll Material When cutting perforated lines, install the cutting tool in the position shown in the figure.
  • Page 450 Step 2: Create Perforated Line Data * The screenshots show an example of Illustrator CC 2015, but the operation procedure is the same for other versions. * You must install Plug-in for Illustrator before proceeding. Installing Plug-in for Illustrator Procedure Start Illustrator.
  • Page 451 From the Window menu, click Extensions, and then click Roland CutStudio. The Roland CutStudio palette appears.
  • Page 452 Select the object that you want to apply perforated lines to. Click...
  • Page 453 Select Output Perforated Cut Lines.
  • Page 454 On the Roland CutStudio palette, click Update. Check that the cutting line that you wish to output is shown on the preview screen. Step 3: Set Perforated Cutting Conditions...
  • Page 455 Step 3: Set Perforated Cutting Conditions * The screenshots show an example of Illustrator CC 2015, but the operation procedure is the same for other versions. Procedure On the palette, click is not displayed, refer to "Configuring Cutting Settings from a Computer" and configure the settings.
  • Page 456 You can now enter the values. Enter the Perforated Cutting Conditions. Set the length of each perforation to make in the material (the perforation length) and the length of the part that is not perforated because the blade force is reduced (the half-cut length). Adjust the half-cut force to suit the type of material or paper used.
  • Page 457 *1: Perforation length *2: Half-cut length Perforation Length > Half-Cut Length Perforation Length = Half-Cut Length Perforation Length < Half-Cut Length Click OK.
  • Page 458 Step 4: Cut Perforated Lines...
  • Page 459 Step 4: Cut Perforated Lines Never touch the cutting carriage while output is in progress. CAUTION The cutting carriage moves at high speed. Coming into contact with the moving carriage may cause injury. Procedure On the palette, click The screen shown in the following figure is displayed. Checking the Installed Position of the Cutting Tool Each Time before Cutting Frequently Using Perforated Cutting Select the model name of the machine on hand, and then click Cut.
  • Page 460 Cutting starts. Adjusting Perforated Cutting Conditions Select optimum cutting conditions on the basis of the cutting results. Optimizing the Cutting Quality for the Material...
  • Page 461 Other Things That You Can Do Changing or Checking the Machine's Operation Changing the Language Used for the Display Setting the Displayed Unit Initializing All Settings to Their Default Values Checking the Machine Status <Self Test> Changing the Contrast of the Display Screen Frequently Using Perforated Cutting Minimizing Wasted Material Setting the Direction of the Coordinate Axis for Cutting <ROTATE>...
  • Page 462 Using Thinner or Harder Material than Normal Preventing Misaligned Cutting Adjusting the Cutting Position Adjusting the Cutting Quality and Saving and Reusing the Adjusted Conditions Saving the Cutting Conditions Loading Cutting Conditions Creating Copies of the Same Object Cutting the Same Object Repetitively Moving the Carriage at High Speed Moving the Cutting Carriage at High Speed...
  • Page 463 The Results of Cutting Are Displaced When Using the Printing and Cutting Function Is a thick material being used? When using thick material, set [Cutting Quality] to [HEAVY]. Setting Cutting Quality <QUALITY> When using roll material, was the amount of material to be cut pulled out before performing cutting? If cutting is performed without pulling out the material, the material may slip or a motor error may stop the operation...
  • Page 464 The Machine Cuts the Same Area Twice Is Overlap Cutting set to 0 in the cutting settings? If Overlap Cutting is set to any number other than 0 on the Cut Setting screen in Plug-in for Illustrator, the number is added to the number of cuts. Is the machine's [OVERLAP] setting a number from 1 to 9? Set the machine's [OVERLAP] setting to [OFF].
  • Page 465 Troubleshooting Crop Marks Cannot Be Read Crop Marks Cannot Be Read Cutting Results Are Not Clean The Results of Cutting Are Displaced When Using the Printing and Cutting Function The Machine Cuts the Same Area Twice Frequently Asked Questions Supported Versions of Illustrator...
