3.
Make the settings for the take-up unit.
–
CHECK
TAKE-UP SETTING
Take-up with outward curl
Ensure there is
no slack.
Take-up with inward curl
Ensure there is
no slack.
When you begin take-up, take care to ensure that the end of the media does not become rolled or creased.
—
Press .
˜
W 1346mm
Make the setting for the AUTO switch on the take-up unit.
Making a setting is complete, when this screen appears.
Chapter 4 Operation of the Media Take-up System
4-2 Using the Take-up System
