Pilot´s Operating Handbook
EXTRA 200
907 LONG RANGE WING TANK CAPACITY
907.1

GENERAL

The leading edge wing tank on the EXTRA 200 equipped with the long range tank capacity
features two tank compartments on either wing side. The compartments are separated by a
slosh rib.
907.2 LIMITATIONS
FUEL
Minimum grade aviation gasoline: 100/100LL;
for alternate fuelgrades see latest revision of Lyc. S.I. No. 1070
Total fuel capacity
- Wingtanks:
- Acro & Center Tank:
Usable fuel capacity in the system: 185 L (48.0 US Gallons).
For acrobatic flight wing tanks must be empty.
Usable fuel capacity for acrobatic: 32 L (8.5 US Gallons).
WEIGHT LIMITS
Max. allowed empty weight - Normal category: 621 kg (1368lbs)
PLACARD
The existing "FUEL SELECTOR VALVE"- placard has to be replaced by the following
placard:
FUEL SELECTOR VALVE
ACRO &
CENTER
TANK
usable 32 L
(8.5 US GAL)
907.3

EMERGENCY PROCEDURES

Not affected.
907.4

NORMAL PROCEDURES

Not affected.
Page Date: 20. April 2002
190 L
154 L (2 x 77 L)
36 L
WING TANKS
usable 154 L(40,7 US GAL)
OFF
Long Range Wing Tank Capacity
(50.2 US Gallons).
(40.7 US Gallons)
( 9.5 US Gallons)
(in both cockpits
near selector valve handle)
Section 907
907 - 3
