Extra 200 Information Manual page 82

Section 6
Weight and Balance and Equipment List
QTY ITEM
1 EGT/CHT Indicator
1 EGT Probe
1 CHT Probe
1 Manifold press.
Indicator
1 Fuel Pressure Ind.
1 Man Press / Fuel Press
1 Man Press / Fuel Flow
1 Fuel Cont. Probe Wing
(Wing Tank)
1 Fuel Cont. Ind. Wing
(Wing Tank)
1 Fuel Cont. Probe
Acro & Center Tank
1 Fuel Cont. Ind.
Acro & Center Tank
1 Ammeter
1 Volt/Ammeter
1 Volt/Ammeter
1 Shunt
1 Alternator 60Amp
1 Voltage Regulator
1 Low Vol. Monitor
1 Alternator 65 Amps
1 Alternator 55 Amps
1 Alternator 55 Amps
1 Battery
1 Battery
1 Battery
1 Battery
1 Batt. Charger Plug
1 External Power Recept. Diverse
1 Ext. Power Solenoid
1 Ext. Power Solenoid
(cont. operation)
1 Main Bus Solenoid
1 Starter Solenoid
1 Ignition switch
1 Main Bus Fuseholder
1 Main Bus Strip Fuse
(40 Amps)
1 PCB Auto Fuse
1 Low Voltage Light
1 Switches
3 Circuit Breakers
5 Switch/Circuit Breakers
6 - 12
MANUFACT PART NUMBER
Westach 2 DA 1
Westach 712-2 DWK
Westach 712-7 DK
UMA 7-100-20
UMA 3-313-10
United Instr. UI6331 H.52
United Instr. UI6331 H.212
VDO 226 801 015 001 G
VDO 301 271 036 001 K
or 301 030 001 G
VDO 224 082 006 097 R
VDO 301 272 052 001 K
or 301 030 002 G
VDO 190 004 039 002
or 190 037 002 G
Electronics Intern. VA-1A
Electronics Intern. VA-1A-50
Electronics Intern. S-50
Electrosystems ALX 8421 LS
Lamar B-00371-25
Lamar B-00378-4
Bosch 0 120 489 935
Bosch 0 120 489 917
Bosch 0 120 489 469
Sonnenschein DRYFIT A212/24G
Hagen HDSM-12250
Exide/Sonnenschein Dryfit A512/25G5
B&C BC100-MJ
EXTRA 146 19 20
AN 2552-3A
Switches Kidde 22735
White-Rodgers 70-111-225-5
White-Rodgers 70-111-226-5
Switches Kidde 22735
TCM 10-357200-1
MTA PN 03.00360
MTA PN 02.00300
EXTRA 83290.1
OAK MS 25041-2
Cutler Hammer div.
Potter&Brumfield div.
Potter&Brumfield div.
Pilot´s Operating Handbook
WEIGHT ARM
Mark if
(KG) (m)
installed
0.07 1.52
0.06 -0.46
0.05 -0.50
0.13 1.52
0.05 1.52
0.54 1.50
0.54 1.50
0.12 0.51
0.08 1.50
0.20 0.36
0.14 1.50
0.08 1.50
0.26 1.51
0.22 1.50
0.09 1.40
5.90 -0.69
0.15 0.02
0.03 0.02
4.60 -0.72
4.20 -0.72
4.20 -0.72
8.60 -0.11
9.70 -0.11
9.65 -0.11
11.29 -0.11
0.02 0.26
1.46 1.77
0.40 -0.03
0.40 -0.03
0.40 -0.03
0.40 -0.03
0.15 1.50
0.03 -0.01
-0.01
0.01 -0.03
0.02 1.53
0.04 1.52
0.14 1.51
0.25 1.51
Page Date: 20. April 2002
Page Date: 28. February 2006
EXTRA 200
Required (R)
Optional (O)
Alternate (A)
O
O
O
R
R
A
A
R
R
R
R
R
A
A
A
R
R
R
A
A
A
R
A
A
A
O
O
O
O
R
R
R
O
O
O
R
R
R
R
