Pilot´s Operating Handbook
EXTRA 200
5.12

CRUISE PERFORMANCE

Range and Endurance values for a T/O weight of 840 kg (1852 lbs) including fuel for warm-
up and takeoff from SL, max. cont. Power climb to cruising altitude, and a reserve of 19
liters (5 US Gal.) for 45 minutes with 45% power. 5 liters (1.3 US Gal.) unusable fuel is taken
into account. (At ISA - Conditions.)
PA Eng. Manif. Power Setting
Press.
[ft] [RPM] [IN HG]
2000
2400 25,0
2300 23,5
2000 23,5
4000
2400 24,5
2200 23,8
2000 23,1
6000
2500 23,1
2200 23,0
2000 22,8
8000
2350 21,5
2050 21,5
10000
2500 19,9
2200 20,0
12000
2300 18,3
1 For temperatures above/ below Standard (ISA), increase/decrease Range 1,7% and
Endurance 1,1% for each 10°C above/below Standard Day Temperature for particular
altitude.
2 Leaning with exhaust gas temperature (EGT) gage
For the adjustment "Best Power", first lean the mixture to achieve the top exhaust
temperature (peak EGT) and then enrich again until the exhaust temperature is 100°F
lower than peak EGT.
For the adjustment "Best Economy", simply lean the mixture to achieve the top
exhaust temperature (peak EGT).
Leaning without exhaust gas temperature (EGT) gage and flowmeter
Slowly move mixture control from "Full rich" position towards lean position. Continue
leaning until slight loss of power is noted (Loss of power may or may not be accompanied
by rough engine run). Then enrich until engine runs smoothly and power is regained.
Page Date: 20. April 2002 Page Date: 14. July 2008
Fuel
Consumption
[%] [Hp] [l/h] (gal/h)
75 150 46 (12,2)
65 130 34 (9,0)
55 110 29 (7,7)
75 150 46 (12,2)
65 130 34 (9,0)
55 110 29 (7,7)
75 150 46 (12,2)
65 130 34 (9,0)
55 110 29 (7,7)
65 130 34 (9,0)
55 110 29 (7,7)
65 130 35 (9,2)
55 110 30 (7,9)
55 110 31 (8,2)
Always return the mixture to full rich before increasing power settings.
TAS IAS
[Kts] (km/h) [Kts] (km/h)
141 (261) 135 (250)
134 (248) 128 (237)
126 (233) 122 (226)
145 (269) 135 (250)
138 (256) 128 (237)
130 (241) 123 (228)
150 (278) 135 (250)
142 (263) 128 (237)
134 (248) 123 (228)
146 (270) 128 (237)
138 (256) 122 (226)
150 (278) 128 (237)
142 (263) 121 (224)
146 (270) 122 (226)
NOTE
CAUTION
Section 5
Performance
Endur. Range Mixture
1 1 2
[h] [NM] Best ...
2,05 288 Power
2.75 368 Economy
3.21 405 Economy
2,05 294 Power
2.73 374 Economy
3.18 412 Economy
2.05 303 Economy
2,71 382 Economy
3.15 421 Economy
2.70 389 Economy
3,12 428 Economy
2.60 380 Economy
2.98 416 Economy
2.85 408 Economy
5 - 15
