Section 4

Normal Procedures

4.1

PREFLIGHT INSPECTION

4.1.1

EXTERIOR INSPECTION ILLUSTRATION

4.1.2

GENERAL

Visually check airplane for general condition during walk around inspection. Perform exterior
check as outlined in the picture above in counterclockwise direction.
4.2

CHECKLIST PROCEDURES

1) Cockpit
1. Pilot's Operating Handbook
2. Airplane weight and balance
3. Ignition switch
4. Master switch
5. Fuel quantity indicators
6. Master switch
7. Fuel selector *
Although safe operation did not require the use of the tanks in a specific sequence, it is
recommended to set fuel selector to "ACRO & CENTER" Tank position!
8. Pitot-Static-Drain
9. "Acro & Center" Tank
Pay attention for fuel accumulations between alu-tank and GRP-cover. (This is indicated by
a blue color)
4 - 4
If water exists, drain by removing the plug. Reinstall plug.
3
4
1
5
(AVAILABLE)
CHECKED
OFF
ON
CHECK
OFF
"ACRO & CENTER"
NOTE *
CHECK FOR WATER
ACCUMULATIONS
NOTE
CHECK
FOR LEAKAGE
NOTE
Pilot´s Operating Handbook
EXTRA 200
2
Page Date: 20. April 2002
