Pilot´s Operating Handbook
EXTRA 200
2) Empennage
1. All round inspection, canopy, surfaces,
stabilizer, elevator, trim rudder and tailwheel
2. Horizontal stabilizer attachment bolts
3) Right Wing
1. Aileron, freedom of movement and security
2. Trailing edge
3. Fuel tank vent opening (right landing gear)
4. Fuel quantity
5. Fuel tank filler cap
6. Right landing gear, wheel and brake
7. Stall warning vane
4) Nose
1. Engine oil dipstick
2. Propeller and spinner
3. Air inlet
4. Fuel quantity ("Acro & Center" tank)
5. Fuel tank filler cap
6. "Acro & Center" tank drain
7. "Wing tank" drain
8. Fuel filter drain
5) Left wing
1. Left landing gear, wheel and brakes
2. Fuel quantity
3. Fuel tank filler cap
4. Pitot cover
5. Trailing edge
6. Aileron, freedom of movement and security
Page Date: 20. April 2002
Normal Procedures
CHECK
CHECK FOR FREEPLAY BY
MOVING THE TIP OF THE
HORIZ. STABILIZER UP- AND
DOWNWARDS
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
CHECK
DRAIN FOR AT LEAST 4
SECONDS TO CLEAR SUMP OF
POSSIBLE WATER;
CHECK CLOSED
DRAIN FOR AT LEAST 4
SECONDS TO CLEAR SUMP OF
POSSIBLE WATER;
CHECK CLOSED
DRAIN FOR AT LEAST 4
SECONDS TO CLEAR
FILTER OF POSSIBLE WATER;
CHECK CLOSED
CHECK
CHECK
CHECK
REMOVE
CHECK
CHECK
Section 4
4 - 5
