Section 903
Electronic Accelerometer
Additionally the long-term memory stores the times and dates when new "Absolute Extreme
Values" occur. They are shown if you push S2 next. In this case during the next twelve
seconds the LC-Display shows under the title "MAX-DATE" the time and date of the positve
"Absolute Extreme Value" and under the title "MIN-DATE" the time and date of the negative
"Absolute Extreme Value". Afterwards the instrument returns into the "Normal Operating
Mode".
If you push S1 instead of S2, the LC-Display will show the current time and date.
If there is no button pushed for about five seconds, the instrument will return into the
"Normal Operating Mode" .
6) OUTPUT OF TIME AND DATE
push button: four times S1
The LC-Display will exhibit time and date after you have pushed S1 for four times. For
example:
is the ninth December 1993 at 2 o'clock and 52 minutes in the afternoon. If you want to set
the clock, you have to push S1 for another time, otherwise the instrument returns into the
"Normal Operating Mode".
7) SETTING OF THE CLOCK
push button: five times S1
You can only set the clock, if you know the right four digit code.
If you push S1 for five times, the LC-Display shows a request to enter the code. You can
change the code-digit by pushing S2. To confirm your input of a digit you have to push S1.
If the entered code-digits are wrong, or you wait longer than six seconds, the instrument will
return into the "Normal Operating Mode".
Provided it was the right code, the LC-Display shows the current time and Date with a
cursor under the first digit. By pushing S2 you can change the digit.
The change can be confirmed by pushing S1. In this case the cursor moves to the next
digit. The instrument changes into the "Normal Operating Mode", if you have stepped
through all digits with the cursor, or you waited more than six seconds without pushing a
button. In this case the time and date on the display are transferred into the clock. If you try
to enter an impossible number ( like 18 as months or 35 as days), the instrument turns
903 - 8
02: 52 PM
12 / 09 93
CODE
0_ _ _
Pilot´s Operating Handbook
EXTRA 200
Page Date: 20. April 2002
