Pilot´s Operating Handbook
EXTRA 200
E) DESCENT AND LANDING
While descending the engine temperatures shall be observed (Danger of overcooling). Final
approach should account for the air-tow hanging below the aircraft flight path.
908.5

PERFORMANCE

The existing POH-Data remain valid with the exception of:
TAKE-OFF DISTANCE (in Meter)
Conditions:
Power: over 2600 Rpm and full throttle, mixture rich,
short grass, dry and paved level runway, no wind,
Max. takeoff weight of the towing aircraft: 700Kg (1543lbs)
Liftoff speed (T/O): 65 KIAS = 120 Km/h indicated
Obstacle clearance speed over 15m (50ft) : 70 KIAS = 130 Km/h indicated
For every 5 kts (9 km/h) headwind, the takeoff (T/O) distance can be decreased by 5%.
For every 2 kts (4 km/h) tailwind [up to 10 kts (19 km/h)], the (T/O) distance is increased by
10%.
All values are valid for single-pilot air-towing operation (700kg MTOW). In case of
an instruction flight with copilot, the higher takeoff weight has to be considered!
The maximum permissible air-towing speed of the glider needs to be observed!
Takeoff weight glider: 350 Kg
Press.- -10°C OAT
altitude T/0 50 ft
___0 ft 201 311
2000 ft 234 362
4000 ft 273 423
6000 ft 320 496
8000 ft 376 583
Takeoff weight glider: 600 Kg
Press.- -10°C OAT
altitude T/0 50 ft
___0 ft 270 419
2000 ft 315 488
4000 ft 368 571
6000 ft 431 669
8000 ft 507 786
Takeoff weight glider: 765 Kg
Press.- -10°C OAT
altitude T/0 50 ft
___0 ft 346 536
2000 ft 403 625
4000 ft 471 730
6000 ft 552 856
8000 ft 648 1006
Page Date: 14. July 2008
Page Date: 20. April 2002
CAUTION
0°C 10°C
T/0 50 ft T/0 50 ft
223 346 248 385
260 404 289 448
304 472 338 524
357 553 396 615
419 651 466 723
0°C 10°C
T/0 50 ft T/0 50 ft
301 467 334 518
351 544 390 604
410 636 456 707
481 746 534 829
566 877 629 975
0°C 10°C
T/0 50 ft T/0 50 ft
385 597 428 663
449 696 499 773
525 814 583 904
615 954 684 1060
724 1122 804 1247
20°C 30°C
T/0 50 ft T/0 50 ft
274 425 302 469
320 496 353 547
374 580 413 640
439 681 484 751
571 801 570 885
20°C 30°C
T/0 50 ft T/0 50 ft
370 574 408 632
431 669 476 738
504 782 557 863
592 918 653 1013
697 1080 769 1193
20°C 30°C
T/0 50 ft T/0 50 ft
473 734 522 809
552 856 608 944
645 1001 712 1104
757 1174 836 1296
891 1382 984 1526
Section 908
Airtow Hook
40°C
T/0 50 ft
332 515
388 601
454 704
533 827
628 974
40°C
T/0 50 ft
448 695
523 811
612 949
719 1115
847 1314
40°C
T/0 50 ft
573 889
669 1038
783 1214
920 1426
1083 1680
908 - 5
