Section 904
Emergency Locator Transmitter
904.4

NORMAL PROCEDURES

There is no change of basic normal procedures with the installation of the POINTER 3000 ELT.
In addition to the existing normal procedures the "AUTO" position of the unit master
switch or the remote switch has to be checked during the preflight check.
904.5

PERFORMANCE

Not affected.
904.6

WEIGHT AND BALANCE

Not affected.
904.7

DESCRIPTION OF THE SYSTEM

The used Emergency Locator Transmitter is a POINTER 3000 ELT from the POINTER
INC., Tempe, Arizona. After an activation the necessity signal is transmitted on the 121,5
MHz and the 243.0 MHz for a period of 48 hours at -20° respectively 2 hours at +50°.
The Inertia-switch releases the necessity signal after a G-force of 5
longitudinal axis and a duration of 11
When properly installed, parallel to the line of flight, the ELT will not activate due to turbu-
lence, normal operation, or aerobatics.
POINTER PORTABLE ELT MAYOR SYSTEM COMPONENTS
The POINTER PORTABLE ELT System consists of the following components:
Telescopic
Antenna
Remote switch
(optional)
904 - 6
±
5/0 milliseconds.
Whip-
Antenna
POINTER
Portable
ELT
Pilot´s Operating Handbook
±
2/0 g in aircraft-
Remote Connector
ELT mounting
bracket
Page Date: 20. April 2002
EXTRA 200
Rear
bracket
clip
