Pilot´s Operating Handbook
EXTRA 200
911 SINGLE SEAT CANOPY
911.1 GENERAL
To change the appearance of the EA-200 the standard canopy can be replaced by a single
seat canopy.
911.2 LIMITATIONS
With the single seat canopy installed the aircraft is limited to the categories NORMAL and
ACRO I.
In the NORMAL category the aircraft can be flown only with the pilot in the rear seat.
911.3 EMERGENCY PROCEDURES
Not affected.
911.4 NORMAL PROCEDURES
Befor starting engine, check front seat area and ensure seat belts and shoulder harness of
front seat are completely removed or fastened and secured, so that nothing can obstruct the
free movement of controls.
911.5 PERFORMANCE
Not affected.
911.6 WEIGHT AND BALANCE AND EQUIPMENT LIST
Refer to the equipment list in section 6.
911.7 DESCRIPTION OF THE SYSTEM
The single seat canopy has been designed to easily replace the standard canopy. This can
be achieved by using the same canopy frame, hinges and latches included. The front seat is
covered by the flat portion of the frame in front of the canopy. Operation of the locking
mechanism is feasible only from the rear seat.
911.8 HANDLING, SERVICE AND MAINTENANCE
Not affected.
Page Date: 20. April 2002
Section 911
Single Seat Canopy
911 - 3
