Section 919
BECKER ATC 4401 Transponder
3 A further test of the unit is triggered, if the VFR1 button (F) and VFR2 button (G) are pressed
simultaneously. At this test all segments must flash into display (E) as long as the buttons are
pushed. Additional the transmitter and evaluation are tested on correct function in the SBY, ON
and ALT modes.
4 In case of a failure appears the report e.g. 'E10' in the top line of the display. Switch OFF the
transponder at such 'E' fault indications.

919.1.8 CONFIGURATION MODE

The configuration Mode is used to set the unit on the ground and must not be called up in flight.
Refer to BECKER's Pilot's Guide for further information.
919.2 LIMITATIONS
Not applicable.
919.3

EMERGENCY PROCEDURES

919.3.1 IMPORTANT CODES

7600 Loss of communications.
7500 Hijacking.
7700 Emergency (All secondary surveillance radar sites are ready to receive this code at all
times).
See the Airman's Information Manual (AIM) for a detailed explanation of identification codes.
919.4

NORMAL PROCEDURES

Not applicable
919.5

PERFORMANCE

Not applicable
919 - 8
Pilot´s Operating Handbook
EXTRA 200
Page Date: 28. February 2006
