Instrument Markings - Extra 200 Information Manual

Section 2
Limitations
2.14.3

INSTRUMENT MARKINGS

AIRSPEED INDICATOR
green arc
yellow arc
red line
OIL PRESSURE INDICATOR
red line
yellow arc
green arc
yellow arc
red line
OIL TEMPERATURE INDICATOR
yellow arc
green arc
yellow arc
red line
CYLINDERHEAD TEMPERATURE INDICATOR
yellow arc
green arc
yellow arc
red line
RPM INDICATOR
green arc
yellow arc
red line
G - METER
green arc
yellow arc
red line
FUEL PRESSURE INDICATOR
red line
green arc
red line
FUEL CAPACITY INDICATOR "WING TANK"
red line
FUEL CAPACITY INDICATOR "ACRO & CENTER TANK"
yellow line
*
red line
When the Fuel Capacity Indicator "ACRO & CENTER TANK" reads
"ZERO" in level flight the remaining usable fuel is 8 Liters (2 US GAL.)
2 - 14
60 KIAS (111 km/h) - 154 KIAS (285 km/h)
154 KIAS (285 km/h) - 217 KIAS (402 km/h)
217 KIAS (402 km/h)
25 Psi (172 kPa)
25 Psi (172 kPa)
55 Psi (379 kPa)
90 Psi (621 kPa)
100 Psi (689 kPa)
<140°F
140°F - 210°F
210°F - 245°F
245°F
<150°F
150°F - 400°F
400°F - 500°F
500°F
700 - 2500 RPM
2500 - 2700 RPM
2700 RPM
- 5 g - + 8 g
+ 8 g - + 10 g
+ 10 g
0 PSI
0 PSI - 12 PSI
12 PSI
0
0
0
NOTE
*
For the US. registred aircrafts only
Pilot´s Operating Handbook
- 55 Psi (379 kPa)
- 90 Psi (621 kPa)
- 100Psi (689 kPa)
Page Date: 20. April 2002 Page Date: 14. July 2008
EXTRA 200
