Pilot´s Operating Handbook
EXTRA 200
904 EMERGENCY LOCATOR TRANSMITTER
904.1

GENERAL

To improve the passive security, the EXTRA 200 can be equipped with an optional Emer-
gency Locator Transmitter POINTER 3000 ELT. This POINTER 3000 ELT transmits auto-
matically after a crash or manual activity on the emergency frequencies of 121.5 MHz
(civilian) and 243.0 MHz (military).
904.2

LIMITATIONS

The operation limitations are not effected due to the installation of the POINTER 3000 ELT.
For the location and operation of the transmitter the following placards have to be attached
in the aircraft:
ELT located here
ELT - placard over the ELT- circuit breaker (see Fig.1) ,
Page Date: 20. April 2002
- placard outside on the left fuselage board in high of the ELT-unit,
ELT
1
REMOTE SWITCH
CIRCUIT BREAKER 1A
Figure 1
Section 904
Emergency Locator Transmitter
904 - 3
