MAINTENANCE MANUAL EXTRA 300/SC
Dates of issue for original and revised pages:
1st Edition .............................................. 16. June 2008
1. Revision ............................................. 29. May 2009
2. Revision ........................................... 1. August 2014
3. Revision ............................................ 4. March 2016
4. Revision ...................................... 12. February 2019
PAGE DATE: 12. February 2019
Log of Revisions
Date and sign of approval:
EASA MAJOR CHANGE APPROVAL
N° EASA.A.C.08679 ................................ 17. July 2008
Approved under the authority of DOA
N° EASA.21J.073 ................................... 29. May 2009
The technical content of this document is approved
under the authority of DOA
ref. EASA.21J.073. ......................... 19. December 2014
The technical content of this document is approved
under the authority of DOA
ref. EASA.21J.073. .............................. 23. March 2016
The technical content of this document is approved
under the authority of DOA
ref. EASA.21J.073. ................................ 19. April 2019
PAGE A
