Section 912
FILSER TRT 600 Transponder
ROTATING KNOBS
Four rotating knobs are used to select the IDENT CODE.
The assignments X... , .X.. , ..X. , ...X indicate the position of the code number set by each knob.
PUSH BUTTONS
ON OFF
The unit can be turned on by pressing the ON OFF button for less then 1 second.
The unit can be turned off by pressing the ON OFF button for more then 2 seconds.
(also refer to the System Operation Paragraph 912.1.2).
MODE
The following modes can be selected in sequence by pressing the MODE button:
STBY Standby Mode used for aircraft on ground with reduced squitter rate, only Mode S with
altitude reporting all ZERO only
A-S Mode A active with Mode C frames only and Mode S with altitude reporting all ZERO
only
ACS Mode A ,C and S full active
ARROWS UP AND DOWN
To activate the inserted SQUAWK CODE from the lower standby line to the upper active position
the button with the UP AND DOWN ARROWS shall be pressed.
IDENT
The IDENT push button causes the special position identification pulse (SPI) to be transmitted
for a period of 18 seconds.
FID
In the Standby Mode, the Aircraft Identification (Flight Identification) and Aircraft Address can be
checked by pressing the push button FID. The Flight Identification is displayed on the right side
of the lower line. By pressing the button FID for more than 3 seconds the input mode can be set
or the Flight Identification can be changed.
FLAGS
Squitter Flag
When the extended squitter is active the letter 'S' is displayed on the left top side of the display.
As the squitter is a periodic signal, the displayed 'S' is blinking.
Reply Flag
In case of the transponder replying to interrogations the letter 'R' is displayed on the left top side
of the display.
