OPERATING PLACARDS

V = 154 KIAS (Acro)
A
V = 138 KIAS (Normal)
A
THE MARKINGS AND PLACARDS INSTALLED IN
THIS AIRPLANE CONTAIN OPERATING LIMITATIONS
WHICH MUST BE COMPLIED WITH WHEN OPERATING
THIS AIRPLANE IN THE ACROBATIC CATEGORY.
OTHER LIMITATIONS WHICH MUST BE COMPLIED
WITH WHEN OPERATING THIS AIRPLANE IN THIS
CATEGORY OR IN THE NORMAL CATEGORY ARE
CONTAINED IN THE AIRPLANE FLIGHT MANUAL.
APPLICABLE RPM LIMITATION MUST BE OBSERVED.
THIS AIRPLANE IS CERTIFICATED
FOR VFR, DAY OPERATION.
OPERATION IN KNOWN ICING
CONDITIONS IS PROHIBITED.
F U E L
AVGAS 100/100 LL
FUEL SELECTOR VALVE
ACRO &
CENTER
TANK
usable 32 L
(8.5 US GAL)
NOSE DOWN <= NEUTRAL=> NOSE UP
MUST BE EMPTY FOR ACROBATICS
WHEN THE INDICATOR READS "ZERO" IN LEVEL FLIGHT THE
REMAINING USABLE FUEL IS 8 LITERS (2 US GAL.)
Page Date: 20. April 2002 Page Date: 14. July 2008
V = 285 km/h (Acro)
A
or
V = 256 km/h (Normal)
A
(near each
filler cap)
WING TANKS
usable 85 L(22.4 US GAL)
OFF
TRIM
WING TANK
ACRO & CENTER TANK
(near airspeed indicator)
(in the rear cockpit)
(on the rear instrument panel)
O I L (on the separate
hatch / upper cowling)
(in both cockpits near selector valve
handle)
(near the handle at the right side
in the rear cockpit)
(on the rear instrument panel under the
fuel capacity indicators )
