DASP-52282 Card User's Manual
Easily Developing Application Programs-Various Sample
Programs
The DASP-52282 series provides many user-friendly sample
programs to help users developing various application programs
in different units, such as VB, VC, BCB, and Delphi. And it also
supports the most popular Labview 6.0/7.0 drivers. The API of
the DASP-52282 has passed strict assembling tests that helps
users not necessarily writer such complicated and wordy
programs while using it.
Easy to Troubleshoot Hardware Resource- PCI Scan
Utility
The PCI scan utility can scan all the DASP products within the
system, and can show users all system resources, such as serial
numbers, IRQ, and I/O addresses. This lets users clearly see
through and immediately know whether all DASPs are working
normally, decreasing the time of searching confirmation.
DASP-52282:
12-bit, 330 KHz multifunction board
DASP-52282L:
12-bit, 330 KHz multifunction board w/o DAC
DASP-52282H:
12-bit, 330 KHz high-gain multifunction board
DASP-52282HL:
12-bit, 330 KHz high-gain multifunction board w/o
DAC

1.1 Features

2 channel 12-bit D/A voltage output
16 D/I and 16 D/O (TTL compatible)
Maximum sampling rate up to 330KHz
Supports free-running mechanism with 1K FIFO
A/D trigger mode: software trigger, pacer
trigger, external trigger
Supports software programmable gain
Supports Windows® 98/NT/2000/XP, Labview
6.0/7.0 driver
Supports VB, VC, BCB, Delphi sample program
2
Introduction
