1.2 Specifications

Analog to Digital Converter (A/D)
Channels: 16 Single-ended or 8 differentials
Resolution: 12-bit
FIFO size: 1K samples
Sampling Rate: 330KS/s max.
Conversion Time: 3µ s
ADC input range: ±10V
Input protect: 30 Vp-p
On chip sample and hold.
Programmable Gain
Low Gain (DASP-52282/ DASP-52282L only)
Gain 0.5
Unipolar
N/A
±10V
Bipolar
High Gain (DASP-52282H/ DASP-52282HL)
Gain 0.5
N/A
Unipolar
Bipolar ±10V
Small signal bandwidth for PGA:
Low Gain (DASP-52282/ DASP-52282L only)
Gain 0.5
5MHz
Bandwidth
High Gain (DASP-52282H/ DASP-52282HL only)
Gain 0.5
1MHz
Bandwidth
Drift: 0.1 LSB @ gain 0.5
Max. input voltage: ±20V
Input impedance: 10000 MΩ 6 pF
On chip sample and hold
Introduction
DASP-52282 Card User's Manual
1 2
0~５v
0~10V 0~2.5v
±5v ±2.5v ±1.25v
1 10
0~10V 0~1V 0~0.1V 0~0.01V
±0.5V ±0.05V ±0.005V
±5v
1 2
5 MHz 4 MHz 1.3 MHz 600 KHz
1 10
1 MHz 80 KHz 10 KHz
║
4 8
0~1.25v
±0.625v
100 1000
4 8
100 1000
1 KHz
3
