DASP-52282 Card User's Manual
CON1: Digital Input Connector Pin Assignment
(20-pin Flat Connector)
Pin Description
1 Digital Input 0/TTL
3 Digital Input 2/TTL
5 Digital Input 4/TTL
7 Digital Input 6/TTL
9 Digital Input 8/TTL
11 Digital Input 10/TTL
13 Digital Input 12/TTL
15 Digital Input 14/TTL
17 PCB's GND
19 PCB's +5V Output
10
Pin Description
2 Digital Input 1/TTL
4 Digital Input 3/TTL
6 Digital Input 5/TTL
8 Digital Input 7/TTL
10 Digital Input 9/TTL
12 Digital Input 11/TTL
14 Digital Input 13/TTL
16 Digital Input 15/TTL
18 PCB's GND
20 PCB's +12V Output
Hardware Installation
