DASP-52282 Card User's Manual
CON2: Digital Output Connector Pin Assignment
(20-pin Flat Connector)
Pin Description
1 Digital Output 0/TTL
3 Digital Output 2/TTL
5 Digital Output 4/TTL
7 Digital Output 6/TTL
9 Digital Output 8/TTL
11 Digital Output 10/TTL
13 Digital Output 12/TTL
15 Digital Output 14/TTL
17 PCB's GND
19 PCB's +5V Output
12
Pin Description
2 Digital Output 1/TTL
4 Digital Output 3/TTL
6 Digital Output 5/TTL
8 Digital Output 7/TTL
10 Digital Output 9/TTL
12 Digital Output 11/TTL
14 Digital Output 13/TTL
16 Digital Output 15/TTL
18 PCB's GND
20 PCB's +12V Output
