Digital I/O
Channel 16
Type TTL level
VIL = 0.8V max.
Voltage low
IIL =-0.4mA max.
VIH = 2.0V min.
Voltage high
IIH = 20 A max.

1.3 Accessories

To make the DASP-52282 functionality complete, we carry a
versatility of accessories for different user requirements in the
following items:
Wiring Cable
CB-89037-2:
37-pin female D-sub type cable with 2m length
CB-89037-5:
37-pin female D-sub type cable with 5m length
The shielded D-sub cable with 2m and 5m are designed for
the DASP-52282 analog I/O connector, respectively.
CB-89320-2:
20-pin female flat type cable with 2m length
CB-89320-5:
20-pin female flat type cable with 5m length
The flat cable with 2m and 5m are designed for the
DASP-52282 digital I/O connector, respectively.
Terminal Block
TB-88037:
D-sub 37P female terminal block with DIN-rail
mounting
The terminal block is directly connected to analog I/O
connector of the DASP-52282.
Introduction
DASP-52282 Card User's Manual
Digital Input
16
TTL level
VOL = 0.5V max
@IOL =8mA max.
VOH = 2.7V min
@IOH =-400A max.
Digital Output
5
