Chapter 1 Introduction; Features - AXIOMTEK SHB250R User Manual

The SHB250R PICMG
® TM
for Intel Core i7/ i5/ i3 desktop processors with 14nm technology and transfer rate 2400/
2666 MHz. The board integrates an Intel
system performance through high-bandwidth interfaces, multiple I/O functions for interactive
applications and various embedded computing solutions. There are two 260-pin DDR4
SO-DIMM sockets for sing channel DDR4 2400/2666MHz with maximum memory capacity up
to 64GB. The board also features dual Gigabit Ethernet, SATA 6Gbps with SATA RAID
0/1(Q370/C246) by PCH, USB 2.0, and USB 3.1 Gen1 high speed compliant ports and built-in
®
Intel HD Audio Digital Header to achieve the best stability and reliability for industrial
applications.
1.1

Features

 LGA1151 socket 9
35W)
®
 Intel Q370/H310/C246 PCH
 2 DDR4 SO-DIMM supports up to 64 GB memory capacity

2 USB 3.0 ports (Rear I/O)
 SATA 6Gbs with RAID 0,1
 Dual Display(DVI-I/DP++)
 ATX DC-in 12V
 Supports iAMT9.0
Introduction
SHB250R Intel LGA1151 Processor PICMG1.3 Half-size CPU Board
®
v1.3 Half-size Single Board Computer supports an LGA1151 socket
®
Q370/H310/C246 chipset that delivers outstanding
th th
/8 Generation Intel
Introduction
® TM
Core processors up to 95W (9
Chapter 1
th
TDP up to
1
