CON4: A/D, D/A and Timer/Counter Connector
Pin Assignment (D-Sub 37-pin Connector for
Differential Signal)
Pin Description
1 Analog Input 0/+
2 Analog Input 1/+
3 Analog Input 2/+
4 Analog Input 3/+
5 Analog Input 4/+
6 Analog Input 5/+
7 Analog Input 6/+
8 Analog Input 7/+
9 Analog Ground
10 Analog Ground
11 No Connect
12 No Connect
13 +12V
14 Analog Ground
15 Digital Ground
16 Timer/Counter 0 Output
17 External Pulse Input
18 OSC clock Out (8MHz)
19 +5V
Hardware Installation
DASP-52282 Card User's Manual
Pin Description
20 Analog Input 0/-
21 Analog Input 1/-
22 Analog Input 2/-
23 Analog Input 3/-
24 Analog Input 4/-
25 Analog Input 5/-
26 Analog Input 6/-
27 Analog Input 7/-
28 Analog Ground
29 Analog Ground
30 DAC 1 Output
31 No Connect
32 DAC 2 Output
33 No Connect
34 No Connect
35 No Connect
36 No Connect
37 External Clock Input
