d.
Raise the front part of the main board by slightly
pressing the bottom side down.
Remove the main board from the back cover by
e.
lifting the board upward
(as illustrated in the figure below)
WARNING!
To prevent damaging the main board and its delicate
components, DO NOT forcefully pull the main board forward or
backward without lifting the board first.
4
©Copyright 2020 Axiomtek Co., Ltd.
Version A2 August 2020
Printed in Taiwan
9412K300010E
DSP300-318 Quick Installation Guide
Packing List
System Unit x 1
DVD/CD x 1 (for Driver & Manual)
Quick Installation Guide x 1
36W power adapter x 1
US power cord x 1 or
Foot Pad x 4
EU power cord x 1
Do not try to apply power to the system if any damaged components.
Dimensions
©Copyright 2020 Axiomtek Co., Ltd.
Version A2 August 2020
Printed in Taiwan
9412K300010E
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DSP300-318 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AXIOMTEK DSP300-318

  • Page 1 DSP300-318 Quick Installation Guide Packing List System Unit x 1 DVD/CD x 1 (for Driver & Manual) Quick Installation Guide x 1 36W power adapter x 1 US power cord x 1 or Foot Pad x 4 EU power cord x 1 Do not try to apply power to the system if any damaged components.
  • Page 2 I/O Outlets Installation of SO-DIMM Memory The following figures show I/O outlets on the DSP300-318. To save your installation effort, we recommend purchasing all memory modules from Axiomtek, and we will have them fully Front View installed in the system unit prior to delivery.
