PC / MAC Assistant
DMG installer supports Mac OS X 10.9 or above.
Phantom 2 Vision+ Assistant on Mac OS X and Windows are the same. Assistant pages shown in this manual
are from the Windows version.

2 Using Assistant

The Phantom 2 Vision+ Assistant is used to conigure the light control system and upgrade irmware. The Phantom RC
Assistant is used to conigure the Remote Controller and upgrade its irmware.

2.1 Using the Phantom 2 Vision+ Assistant

(1) Power on the PC and the Phantom 2 Vision+. Connect the Phantom 2 Vision+ to the PC with a Micro-USB cable. DO
NOT disconnect until coniguration is inished.
(2) Run Phantom 2 Vision+ Assistant and wait for the Phantom 2 Vision+ to connect. Watch the indicators
bottom of the screen. When connected successfully, the Computer Connection status is
Indicator blinks .
(3) Choose [Basic] or [Advanced] coniguration pages.
(4) View and check the current coniguration in the [View] page.
View conigurations
RC, Gain
Gimbal, Battery, Flight Limits
Data Exchange Indicator
Computer Connection status
Do not enable Naza-M mode before finishing "Advanced Flight Maneuvers" in the "Phantom Pilot Training
Guide".
Enable Phantom mode by tapping the same button if Naza-M mode is enabled. Once changed to Phantom
working mode, all parameters will return to factory settings.

2.2 Firmware Upgrade of the Phantom 2 Vision+

(1) Click [Upgrade] icon to check the current irmware version and whether the installed irmware is the latest version. If
not, click links to upgrade.
(2) Wait until the Assistant shows "inished". Click OK and power cycle the Phantom 2 Vision+ after 5 seconds. Once
complete, irmware is up to date.
46
©
2015 DJI. All Rights Reserved.
Figure 111
Figure 112
on the
and Data Exchange
Function switch between Phantom
and Naza-M working modo
Language swap
Account, software version
Firmware upgrade
IMU calibration
* This image is for reference
only. Please refer to the
actual user interface.
