Gimbal speciications
Control accuracy
Controllable range
Maximum angular velocity
Non-FPV Mode: the gimbal will stabilize across 3-axial for smooth aerial creativity.
FPV Mode (First Person View Mode): Gimbal will lock to the movements of the Phantom for a FPV experience.

Anti-drop Kit

The Anti-drop Kit helps keep the gimbal and camera
connected to the aircraft. Two have been mounted on
delivery. If new ones are required, take the gimbal and
press part [ 1 ] through the center hole of the Vibration
Absorber the center hole of part [ 2 ] . Lock them together
as shown in [ 3 ] . Mounting the Anti-drop Kit diagonally is
recommended.
Once part [ 1 ] and part [ 2 ] are connected, the Anti-drop Kit cannot be disconnected and reused.

Micro-SD Slot

With light battery powered off, make sure the Micro-SD
card is inserted correctly into the Micro-SD Slot before
taking any photos or recording any video.
The Phantom 2 Vision+ comes with a 4GB Micro-SD card
and can support cards up to 32GB. The DJI VISION App
may not be able to read some Micro-SD cards. Using
the DJI VISION App to reformat new Micro-SD cards is
recommended.
Refer to Format Micro-SD Card (Page 37) for details.
Do not insert or remove Micro-SD card when light battery is powered on.

Gimbal Error Warnings

Before the aircraft takes off, if a gimbal motor error is detected or the gimbal clamp is not removed, there will be a
warning prompt on the camera page of the DJI VISION App. This will disappear after the problem is resolved.
±0.03°
Pitch : -90°~0°
Pitch : 90°/s
Ready to Fly
Figure 16
[ 1 ]
[ 2 ]
Figure 14
Figure 15
Ready to Fly
Figure 17
©
2015 DJI. All Rights Reserved.
Assembly and Use
[ 3 ]
13
