Matrice 200 V2
The DJI MATRICE 200 V2 (M200 V2) is a powerful industrial drone platform with world-class agility and speed, redundant
TM TM
barometers and IMUs for maximum reliability, and smart flight features that make capturing complex shots easy. The aircraft's visual
sensors* enable enhanced hovering precision even when flying indoors or in environments where GNSS is unavailable. The built-in
AirSense makes you aware of nearby aircraft in the surrounding airspace to ensure safety. Its airframe design gives it an IP43 Ingress
Protection, in accordance with the global IEC 60529 standard. The mechanical design, along with quick-release landing gears and
mounted folding arms, makes it easy to transport, store, and prepare for flight. The safety beacons on both the top and the bottom
of the aircraft allow the aircraft to be identified at night or in low light conditions. An advanced power management system along with
dual batteries ensures power supply and enhances flight safety. Without a payload, the M200 V2 has a flight time of up to 38 minutes
with standard batteries (TB55).*
The M200 V2 is compatible with many of DJI's DGC2.0 connector gimbals.* This manual uses the DJI ZENMUSE
example to demonstrate the M200 V2's remarkable functions.
7
6
5
2
4
3
22
Folded
* The Vision and Infrared Sensing Systems are affected by surrounding conditions. Read the Disclaimer and Safety Guidelines to learn more.
Maximum run-time is tested in a lab environment. Performance may vary depending on local conditions.
Gimbals can be purchased separately from the official DJI website.
DO NOT disassemble the aircraft shell, otherwise it will not be covered under warranty.
2
www.
13
11
12
8
1
9
10
1. FPV Camera
2. Forward Vision System
3. DJI Gimbal Connector V2.0
(DGC2.0)
4. Gimbal Detachment Button
5. Frame Arms
6. Motors
7. Propellers
8. ESC LEDs
9. Transmission Antennas
10. Landing Gear
11. Upward Infrared Sensor
.com
XT 2 as an
TM
15
14 16
17
18
19
20
21
12
12. Beacons
13. Aircraft Status Indicators
14. USB Mode Switch
15. USB Port
16. Linking Button and Indicator
17. Battery Removal Button
18. Intelligent Flight Batteries
19. Battery Level Indicators
20. Power Button
21. Downward Vision System
22. microSD Card Slot
