dji PHANTOM 2 VISION+ User Manual page 41

[ 5 ] Parameter Unit
Select imperial or metric units of measurement.
[ 6 ] Ground Station
Slide to the right to enable ground station feature.
[ 7 ] Compass Calibration
Tap to calibrate the compass. Do not calibrate the
compass during light.
[ 8 ] Low Battery Auto Go Home
Enable or disable auto go home feature when battery
is low.
[9] Dynamic Home Point
When activated, the Home point will be reset to your
current position at speciic time intervals. The aircraft
will return to the latest Home point as required.
[10] Current RTH Altitude
Default RTH altitude set to 20m. Raising the RTH
altitude above 120m is not recommended.
[11] Battery History Info
Show the battery history warning records.
[12] GPS Signal Notice
If enabled, the DJI VISION App will display a pop-
up tip when attempting to takeoff without a suficient
GPS signal.
[ 13 ] FPV Mode
Switched on, the gimbal will work in FPV mode.
Switched off, the gimbal will work in Stabilize mode.
[ 21 ] Find My PHANTOM 2 VISION
[ 22 ] Account
Tap to see user account information.
[ 23 ] Rate
Tap to rate the DJI VISION App. Internet access required.
Android App does not include rating.
[ 24 ] About
Tap to see the current version of the DJI VISION App and contact information.
[ 14 ] Rotation Lock
[ 15 ] Low Battery Warning
[ 16 ] Tutorial
[ 17 ] Clear News Cache
[ 18 ] Binding
[ 19 ] Rename Range Extender SSID
[20] Upgrade Range Extender
My location
Phantom 2 Vision's
location
DJI VISION App Usage
The user interface of the DJI VISION App will rotate
if rotation lock is enabled (for iOS device only).
If enabled, an alarm will sound when the battery
level is too low.
We recommended adjusting the mobile
device volume to the highest level.
Hints and Tips
Tap to lush news cache.
In the event that camera and Range Extender binding
is lost or an item has been repaired or replaced,
binding must be performed using the DJI VISION App.
Refer to Binding the Phantom 2 Vision+ and Range
Extender (Page 21) for details.
Tap to rename the SSID of the Range Extender.
Refer to Rename Range Extender SSID (Page 21)
for details.
When upgraded, it is possible to use a mobile
device's data network to access internet functions
while connected to the Phantom.
This feature is not available on Android.
Figure 97
©
2015 DJI. All Rights Reserved.
Figure 98
