dji PHANTOM 2 VISION+ User Manual page 44

DJI VISION App Usage
A circle on the map, as shown in Figure 104, indicates a restricted, No Waypoint area. Waypoints cannot be
placed in this area. For more information, refer to "6.2 Flight Restriction of Restricted Areas (P30)".
To achieve the optimal video transmission quality, the aircraft is set to operate within a 500m-radius area from
Home point.
Tap on a waypoint to open a waypoint properties window. Slide the white dot right to adjust waypoint altitude. The
default altitude is set to 98 feet (30 m) and can be adjusted from 0 to 650 feet (200 m). Tap "OK" to save waypoint
settings. To delete current waypoint, tap
Figure 105
Step 3 Preview a Mission:
Tap "Done" to preview the mission when all waypoints are set. A prompt similar to the one below will appear.
This prompt lists all waypoints and their altitudes. The aircraft will ly to each waypoint listed. If there is a difference in
altitude between waypoints, the aircraft will adjust its altitude as it lies between points. When ready, tap "GO" to begin
mission.
Aircraft reacts differently to the "GO" command:
If aircraft is on the ground, the aircraft takes off automatically and ascend 16 feet (5m) then fly to the first
waypoint.
If aircraft is in the air, the aircraft lies to the irst waypoint.
Step 4 Executing Flight Mission
The aircraft lies to each waypoint in numerical order. As it lies, swipe back into the DJI Vision app camera GUI to
control camera tilt and capture photos or video. Tap
to resume mission. If you wish to regain control of the aircraft, toggle the S1 switch on remote controller
hovering. Tap
(Position-1) to either
from
Step 5 Landing
When all waypoints have been visited, the aircraft will return to its Home point and hover. Regain control of the aircraft
and land it manually. You may also tap
return to Home point and auto land. When the aircraft is landing automatically, users can control the aircraft's position
and altitude. Users can start the motors to take off immediately after the motors have stopped following auto landing.
44
©
2015 DJI. All Rights Reserved.
. Modify longitude and latitude value using the input box.
waypoint1
Longitude Latitude
113.94984 22.54074
Height
(Position-2) or (Position-3) to discontinue the current mission.
button to initiate "Go Home" procedure. Aircraft will abort current mission,
to pause the mission during the light, and aircraft will then start
Figure 107
Figure 106
