2 Camera Page

[6]
[1]
[2]
[3]
[4]
[ 1 ] Return [ 2 ] Camera Pitch Control [ 3 ] Flight Attitude and Radar Function [ 4 ] Flight Parameters [ 5 ] Wi-Fi Signal Strength [ 6 ]
Flight Battery Level [ 7 ] Aircraft GPS Status [ 8 ] Micro-SD Card Status [ 9 ] Range Extender Battery Level [ 10 ] Remaining
Shots [ 11 ] Shutter Button [ 12 ] Video Recording Button [ 13 ] Camera Settings [ 14 ] Hide or Show Flight Parameters
[ 15 ] Rear LED Flight Indicator Status

[ 1 ] Return

-Return to the preview page

[ 2 ] Camera Pitch Control

-Pitch Control switch is white
return to normal.

Normal Mode

Tap up arrow to pitch camera upwards and down arrow
camera pitch.
Gimbal pitch control (Normal Mode)

Accelerometer Sensor Mode

The gimbal pitch movement is controlled by moving your mobile device. Pitch forward to pitch camera down and
backward to pitch camera up.
Gimbal pitch control (Accelerometer Sensor Mode)
Figure 65
In Accelerometer Sensor Mode, the pitch angle indicator will show a grey area. When the green pitch indicator
is inside the grey area, the camera will move according to pitch gestures. When the indicator reaches the
boundary of the grey area, pitch gestures will control the camera's pitch speed at a constant rate.
[15]
Figure 62
tap once to highlight it
Ready to Fly
Figure 63
Ready to Fly
Figure 66
Ready to Fly
and enter Accelerometer Sensor Mode. Tap again to
to pitch downwards. Green slider indicates current
Gimbal pitch movement
Figure 64
Gimbal pitch movement
©
DJI VISION App Usage
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
