INSPIRE 2 SERIES
Inspire 2/Inspire 2 ProRes/Inspire 2 L
User Manual
V2.2
2018.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inspire 2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji Inspire 2 Series

Summary of Contents for dji Inspire 2 Series

  • Page 1 INSPIRE 2 SERIES Inspire 2/Inspire 2 ProRes/Inspire 2 L User Manual V2.2 2018.09...

  • Page 2: Using This Manual

    * For increased safety, the flight is restricted to a height of 30 m and distance of 50 m when not connected or logged into the app during flight, including DJI GO 4 and all apps compatible with DJI aircraft.

  • Page 3: Table Of Contents

    Contents Using this manual Legends Before Flight Watch the video tutorials Download the DJI GO 4 app Download the DJI Assistant 2 Product Profile Introduction Feature Highlights Assemble the Aircraft Preparing Remote Controller Aircraft Diagram Remote Controller Diagram Aircraft Flight Controller...
  • Page 4 INSPIRE 2 SERIES User Manual DJI GO 4 App Camera Editor SkyPixel Flight Flight Environment Requirements GEO (Geospatial Environment Online) System Flight Restrictions GEO Unlocking Preflight Checklist Calibrating the Compass Auto Take-off and Auto Landing Starting/Stopping the Motors Stop the Motor Mid-flight...
  • Page 5 Product Profile This chapter describes the features of Inspire 2, instructs you to assemble the aircraft and explains the components on the aircraft and remote controllers. © 2018 DJI All Rights Reserved.

  • Page 6: Product Profile

    23-minutes with a Zenmuse X7 and 27-minutes with a Zenmuse X4S.** * Lossless video (CinemaDNG, ProRes) and DNG RAW photo burst shooting will be available when using DJI CINESSD. You can purchase the DJI CINESSD and DJI CINESSD STATION separately on the official DJI Online Store.
  • Page 7 3. Align the white dot on the gimbal to the red dot on Inspire 2 and insert the gimbal. 4. Rotate the Gimbal Lock to the locked position by aligning the red dots. Always ensure that the DJI Gimbal Connector 2.0 on the Inspire 2 is in the right position when mounting, otherwise the camera will not mount.

  • Page 8: Preparing Remote Controller

    INSPIRE 2 SERIES User Manual Attaching 1550T Quick Release Propellers Following the steps below to attach the 1550T quick release propellers. 1. Pair the propellers and motors with arrows of the same color (red or white). Press down the spring pad and rotate...

  • Page 9: Aircraft Diagram

    INSPIRE 2 SERIES User Manual Aircraft Diagram [1] FPV Camera [11] Rear LEDs [2] Forward Vision System [12] Intelligent Flight Batteries [3] DJI Gimbal Connector V2.0 (DGC2.0) [13] Power Button [4] Gimbal and Camera Detach Button [14] Battery Level Indicators...

  • Page 10: Remote Controller Diagram

    [12] Camera Settings Dial Turn the dial to adjust camera settings. (Only functions when the remote controller is connected to a mobile device running the DJI GO 4 app.) [13] Record Button Press to start recording video. Press again to stop recording.
  • Page 11 Reserved extended port. [19] HDMI A Port HDMI A Port is for video output. [20] USB Port Connection to mobile device for DJI GO 4 app. [21] C1 Button Customizable through the DJI GO 4 app. [22] C2 Button Customizable through the DJI GO 4 app.
  • Page 12 Aircraft This chapter describes the features of the Flight Controller, Vision System and the Intelligent Flight Battery.

  • Page 13: Aircraft

    The aircraft’s descent speed is significantly increased in S-mode (Sport). A minimum braking distance of 164 feet (50 meters) is required in windless conditions. Use the Flight Controller mode switch to change the flight mode of the aircraft. © 2018 DJI All Rights Reserved.

  • Page 14: Flight Status Indicator

    (or nose) of the aircraft (Front and rear LEDs can be turned off in the DJI GO 4 app). The Aircraft Status Indicator communicates the system status of the flight controller. Refer to the table below for more information about the Aircraft Status Indicator.

  • Page 15: Return-To-Home (Rth)

    RTH while the Forward Vision System is enabled. Smart RTH Use the RTH button on the remote controller or tap the RTH button in the DJI GO 4 app and follow the on-screen instructions when GPS is available to initiate Smart RTH. The aircraft will then automatically return to the last recorded Home Point.
  • Page 16 The user cannot cancel the auto landing but can use the remote controller to alter the aircraft’s orientation during the landing process. The Battery Level Indicator is displayed in the DJI GO 4 app, and is described below: Sufficient battery...
  • Page 17 Failsafe. The aircraft cannot avoid obstacles during Failsafe RTH if the Forward Vision System is disabled. It is important to set a suitable RTH Altitude before each flight. Launch DJI GO 4, enter camera and tap to set Failsafe Altitude.
  • Page 18 INSPIRE 2 SERIES User Manual If the aircraft is flying under 65 feet (20 meters) and Failsafe (including Smart RTH, Lower Battery RTH) is triggered, the aircraft will first 20 m 20 m RTH Altitude automatically ascend to 65 feet (20 meters) from the current altitude. You can only cancel the ascending by exiting the Failsafe.

  • Page 19: Intelligent Flight Modes

    Users retain control of aircraft flight orientation. 3. If Landing Protection is inactive, the DJI GO 4 app will display a landing prompt when the Inspire 2 descends below 0.7 meters. Tap to confirm or pull down the control stick for 2 seconds to land when the environment is appropriate for landing.
  • Page 20 Be extra cautions when flying in dark (< 300 lux ) or bright (>10,000 lux) environments. Enable control stick control of the gimbal inside the DJI GO 4 app to control gimbal orientation using the remote controller. When control sticks are in use, the gimbal will automatically change into Free Mode.
  • Page 21 The aircraft automatically adjusts its speed when it senses an obstacle in front, or if it flies too close to the ground. The DJI GO 4 app will show a prompt if the aircraft flies over an obstacle or to the left or right of the obstacle.
  • Page 22 ActiveTrack: 1. Take off and hover at least 6 feet (2 meters) above the ground. 2 meters Auto Hold 2. Launch the DJI GO 4 app and tap , then tap , read and understand the prompts. 4.07V...
  • Page 23 The aircraft tracks the subject at constant angle distance. Use the roll stick on the remote and distance from the side. Use the roll stick on controller or the slider in DJI GO 4 app to circle the remote control to circle the subject. the subject.
  • Page 24 VS 2.0M/S VPS 2.0M You can drag on a subject in the DJI GO 4 app or move the gimbal control sticks to change the subject's position in the shot. Aircraft auto spin is enabled by default in Free Mode. It spins the aircraft in the opposite angle to gimbal rotation to avoid rotation limits during shooting.

  • Page 25: Vision System And Infrared Sensing System

    INSPIRE 2 SERIES User Manual Vision System and Infrared Sensing System The main components of the Vision System are located on the front and bottom of the Inspire 2, including [1] [2] two stereo vision sensors and [3] two ultrasonic sensors. The Vision Sys tem uses ultrasound and image data to help the aircraft maintain its current position, enabling precision hov- ering indoors or in environments where a GPS signal is not available.
  • Page 26 DJI Assistant 2 to complete calibration. 6. Place the aircraft straight, and ensure the dotted side of the visual calibration plate faces the downward vision system. Follow the instructions in the DJI Assistant 2 to complete calibration. ©...
  • Page 27 INSPIRE 2 SERIES User Manual Calibrating via Screen Follow the steps below to calibrate the camera. Point the aircraft toward the screen Align the boxes Pan and tilt the aircraft DO NOT power off or unplug the USB cable after calibration. Wait for data calculation.
  • Page 28 INSPIRE 2 SERIES User Manual Assisted Braking from Obstacle Sensing Powered by the Obstacle Sensing, the aircraft will now be able to actively brake when obstacles are detected around the aircraft. Note that Obstacle Sensing function works best when lighting is adequate and the obstacle is clearly marked or textured.

  • Page 29: Flight Recorder

    Note that all data is encoded and only stored on your DJI device. Data does not upload to a DJI server automatically, nor is it shared with DJI in any other way.
  • Page 30 2 requires the two batteries to have similar properties, e.g. internal resistance. Pairing batteries in the beginning is recommended. Pairing can be done using the DJI GO 4 app. The DJI GO 4 app will also prompt when batteries that are not paired are in use. The Intelligent Flight Battery Charging Hub will charge paired batteries simultaneously.
  • Page 31 Pairing can be carried out using the DJI GO 4 app. Refer to the "Status LED Description” section for more information about Status LED blinking patterns. The buzzer will begin beeping when charging is complete. Refer to the “Buzzer Beeping Description”...
  • Page 32 1 hour Updating the Firmware DJI will release firmware updates when available. Refer to the official DJI website and follow the instructions below to update the firmware. 1. Download the latest firmware update program from the official DJI website.
  • Page 33 INSPIRE 2 SERIES User Manual 2. Turn on the Charging Hub, then connect it to a computer using a Micro USB cable. 3. Run the firmware update program. Press the update button and wait for the process to finish. 4. The Charging Hub will automatically restart when the update has been successfully completed.
  • Page 34 4.35 V before each flight. 2. If the DJI GO 4 app displays the “Critical Low Battery Level Warning” when flying in low temperature environments, stop flying and land the aircraft immediately. You will still be able to control the aircraft’s movement when this warning is triggered.
  • Page 35 Remote Controllers This chapter describes the features of the remote controller that includes aircraft and remote controller operations and dual remote controller mode.

  • Page 36: Remote Controller

    The Status LED will show a solid green light when linking is completed. 4. Repeat step 2 to power off the remote controller after finish using it. © 2018 DJI All Rights Reserved.
  • Page 37 INSPIRE 2 SERIES User Manual Charging Remote Controller Charge the remote controller via supplied charger. Power Outlet Controlling Camera Shoot videos or images and adjust camera settings via the Shutter Button, Camera Settings Dial Video Recording Button and Gimbal Dial on the remote control.
  • Page 38 INSPIRE 2 SERIES User Manual Remote Aircraft Controller Remarks indicates nose direction) (Mode 2) Moving the left stick up and down changes the aircraft’s elevation. Push the stick up to ascend and down to descend. Push the throttle stick up to takeoff.
  • Page 39 The Flight Mode is locked in P-mode by default, regardless of switch position. To switch flight modes, go to Camera view in the DJI GO 4 app, tap and enable “Multiple Flight Modes”. After enabling multiple flight modes, toggle the switch to P and then to S to fly in Sport Mode.
  • Page 40 INSPIRE 2 SERIES User Manual 1. Raise: Raise the landing gear to its upper most position. 2. Lower: The landing gear will lower to its lowest position for landing. Do not raise the landing gear when the aircraft is on the ground. Ensure the landing gear is lowered before landing.

  • Page 41: Dual Remote Controllers Mode

    INSPIRE 2 SERIES User Manual Connecting Mobile Device Tilt the Mobile Device Holder to the desired position. Press the button on the side of the Mobile Device Holder to release the clamp, and then place your mobile device into the clamp. Adjust the clamp to secure your mobile device.
  • Page 42 Remote controller cannot link to the aircraft if the remote controller is set as “Slave”. Meanwhile, the “Slave” remote controller cannot control the orientation of the aircraft. Reset the remote controller to “Master” in DJI GO 4 app if you wish to link the remote controller to the aircraft.

  • Page 43: Remote Controller Status Led

    INSPIRE 2 SERIES User Manual 2. Search the “Master” remote controller in the surrounding area. Remote Controller Settings Master and Slave Set Remote Controller Status Master Slave Master ID: 28172d Slave ID: 14f93f Connection Status:OFF Search Master 3. Select the “Master” remote controller from the "Master" list and input the connection password to connect to the desired “Master”...

  • Page 44: Linking The Remote Controller

    Follow these steps to link a new remote controller: 1. Power on the remote controller and connect to the mobile device. Launch DJI GO 4 app. 2. Power on the Intelligent Flight Battery.

  • Page 45: Used With The Dji Focus

    Remote controller cannot link to the aircraft if the remote controller is set as “Slave”. Meanwhile, the “Slave” remote controller cannot control the orientation of the aircraft. Reset the remote controller to “Master” in DJI GO 4 app if you wish to link the remote controller to the aircraft.
  • Page 46 Gimbal and Camera This chapter provides the technical specifications of the camera and explains the working mode of the gimbal.

  • Page 47: Camera And Gimbal

    The gimbal tilts the camera across a -130° to +40° pitch angle and pans ± 320° in both directions. Live HD video from the camera is streamed to the DJI GO 4 app. Camera Micro SD Card Slot To store your photos and videos, plug in the Micro SD card into the slot shown below before powering on the Inspire 2.

  • Page 48: Gimbal

    Use the Shutter and Record button on the remote controller to shoot the images or the videos. For more information about how to use these buttons, refer to “Controlling Camera”. DJI GO 4 app Use the DJI GO 4 app to shoot the images or the videos. For more information, refer to “Zenmuse X5S User Manual”. Gimbal...
  • Page 49 Three Gimbal operation modes are available. Switch between the different operation modes on the Camera page of the DJI GO 4 App. Note that your mobile device must be connected to the remote controller for changes to take effect. Refer to the table below for details:...

  • Page 50: Using Cinessd

    4. Information about the CINESSD will be available in the DJI GO™ 4 app. Exporting Files 1. Power off the aircraft. Remove the batteries and then the CINESSD. 2. Insert the CINESSD into the DJI CINESSD Station, then connect the station to a computer via a USB cable. USB Port ©...
  • Page 51 To guarantee the high performance of the DJI CINESSD, the station only supports file exporting. To delete files, please insert the CINESSD into the aircraft and launch the DJI GO 4 app to format the CINESSD to free up storage space.
  • Page 52 DJI GO 4 App This chapter describes the four main GUI of the DJI GO 4 app.

  • Page 53: Dji Go 4 App

    DJI GO 4 App The DJI GO 4 app* is a new mobile app designed specifically for the Inspire 2. Use this app to control the gimbal, camera and other features of your flight system. The app also comes with Map, Store a User Center, for configuring your aircraft and sharing your content with friends.
  • Page 54 INSPIRE 2 SERIES User Manual 1. System Status : This icon indicates aircraft flight status and various warning messages. READY TO GO (GPS) 2. Battery Level Indicator : The battery level indicator provides a dynamic display of the battery level. The colored zones on the battery level indicator represent the power levels needed to carry out different functions.
  • Page 55 INSPIRE 2 SERIES User Manual 14. Photo/Video Button : Tap to switch between photo and video recording modes. 15. Gimbal Slider : Displays the pitch of the gimbal. 16. Shoot / Record Button : Tap to start shooting photos or recording video.

  • Page 56: Editor

    : Tap this icon to return to the main menu. Editor An intelligent video editor is built into the DJI GO 4 app. After recording several video clips and downloading them to your mobile device, go to Editor on the home screen. You can then select a template and a specified number of clips which are automatically combined to create a short film that can be shared immediately.
  • Page 57 Flight This chapter describes the flight safety and flight restrictions.

  • Page 58: Flight

    Once pre-flight preparation is complete, it is recommended that you use the flight simulator in the DJI GO 4 app to hone your flight skills and practice flying safely. Ensure that all flights are carried out in an open area.

  • Page 59: Flight Restrictions

    Restricted Zone, please go to https://www.dji.com/flysafe or contact flysafe@dji.com to unlock the zone. DJI GEO Zones aim to ensure the user’s flight safety, but it cannot be guaranteed to be in full compliance with local laws and regulations. Users should check local laws, regulations, and regulatory requirements before each flight and are responsible for the flight safety.
  • Page 60 INSPIRE 2 SERIES User Manual Maximum Flight Altitude Max Radius Home Point Height of aircraft when turned on Strong GPS Signal Restriction Description DJI GO 4 App Message Aircraft's altitude cannot exceed Maximum Flight Altitude reached. Adjust Max Altitude the specified value.
  • Page 61 Altitude Zone. If it is higher than the altitude limit, the aircraft decelerates and hovers in place. When the GPS signal changes from weak to strong, DJI GO 4 app starts a 20-second countdown. Once the countdown is over, the aircraft will descend and hover below the altitude limit.

  • Page 62: Geo Unlocking

    7. Ensure that the sensors for the Obstacle Sensing System are clean. Calibrating the Compass Only calibrate the compass when the DJI GO 4 app or the status indicator prompt you to do so. Observe the following rules when calibrating your compass: DO NOT calibrate your compass where there is a chance of strong magnetic interference, such as magnetite, parking structures, and steel reinforcements underground.
  • Page 63 INSPIRE 2 SERIES User Manual 3. Hold the aircraft vertically, with nose pointing downward, and rotate it 360 degrees around the center axis. Recalibrate the compass if the Aircraft Status Indicator glows blinking red. If the Aircraft Status Indicator blinks red and yellow after the calibration procedure, move your aircraft to a different location and try again.

  • Page 64: Auto Take-Off And Auto Landing

    If Landing Protection is not operational, the DJI GO 4 app will display a landing prompt when the Inspire 2 descends below 0.7 meters. Pull down on the throttle or use the auto landing slider to land.

  • Page 65: Stop The Motor Mid-Flight

    Pull the left stick to the bottom inside corners and press the RTH button at the same time. Only stop the motors mid-flight in emergency situations when doing so can reduce the risk of damage or injury. Please check that CSC is activated inside DJI GO 4 app, then the user can stop the aircraft mid-air. Flight Test Takeoff/Landing Procedures 1.
  • Page 66 Video Suggestions and Tips 1. Go through the full pre-flight checklist before each flight. 2. Select the desired gimbal operation mode in the DJI GO 4 app. 3. Only shoot video when flying in P-mode. 4. Always fly in good weather and avoid flying in rain or heavy wind.
  • Page 67 Appendix...

  • Page 68: Appendix

    Approx. 461 g( Including original lens, balancing ring, lens hood) Weight Camera DJI MFT 15mm/1.7 ASPH (With Balancing Ring and Lens Hood) Panasonic Lumix 15mm/1.7 (With Balancing Ring and Lens Hood) Panasonic Lumix 14-42mm/3.5-5.6 HD (With Balancing Ring)Olympus M.Zuiko 12mm/2.0 (With Balancing Ring) Supported Lens Olympus M.Zuiko 17mm/1.8 (With Balancing Ring)
  • Page 69 INSPIRE 2 SERIES User Manual 72° (with DJI MFT 15mm/1.7 ASPH ) 4:3, 5280×3956 Photo Resolutions 16:9, 5280×2970 H.264 C4K: 4096×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps 3840×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps 3840×1572 23.976/24/25/29.97p @100Mbps 2.7K: 2720×1530 23.976/24/25/29.97p @80Mbps 47.95/50/59.94p @100Mbps FHD: 1920×1080 23.976/24/25/29.97p @60Mbps 47.95/50/59.94p @80Mbps 119.88p @100Mbps H.265...
  • Page 70 INSPIRE 2 SERIES User Manual Anti-Flicker Auto, 50Hz, 60Hz PAL/NTSC Supported Environmental Operating Temperature 14° to 104°F (-10 to 40℃) Storage Temperature -4° to 140° F (-20 to 60 ℃) Gimbal Angular Vibration Range ±0.01° Controllable Range Pitch: -130° to +40°; Roll: ±20°; Pan: ±320°...

  • Page 71: Aircraft Status Indicator Description

    INSPIRE 2 SERIES User Manual Voltage 22.8 V Battery Type 6S LiPo Energy 97.58 Wh Net Weight 515 g Operating Temperature -4° to 104° F (-20° to 40° C) Less than 3 months: -4° to 113° F (-20° to 45° C) Storage Temperature More than 3 months: 72°...

  • Page 72: Upgrading The Firmware

    1. Power on the Intelligent Flight Battery, and toggle the USB Mode Switch up. 2. Connect the aircraft and your mobile device via an appropriate USB cable. 3. Follow the on-screen instructions in the DJI GO 4 app to upgrade. Ensure to connect to the Inter- net when downloading the firmware.

  • Page 73: After-Sales Information

    Method 1: Using the DJI GO 4 App Power on the remote controller and connect it with the DJI GO 4 app. A prompt will appear if a new firmware upgrade is available. To start upgrading, connect a mobile device to the Internet and follow the on-screen instructions.
  • Page 74 This content is subject to change. Download the latest version from www.dji.com/inspire-2 If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. © 2018 DJI All Rights Reserved.
