Flight

6 Flight Limits

All unmanned aerial vehicle (UAV) operators should abide by all regulations from such organizations as the ICAO
(International Civil Aviation Organization) and their own national airspace regulations. For safety reasons, the light limits
function is enabled by default to help users use this product safely and legally. The light limits function includes height,
distance limits and No Fly Zones.
In Ready to Fly mode, height, distance limits and No Fly Zones work together to manage light. In Ready to Fly (non-GPS)
status, only height limits work and lights cannot go higher than 120m.
Default parameters in Assistant are compliant within the deinitions of class G ruled by ICAO. (Refer to Airspace
Deinition to get more details). As each country has its own rules, make sure to conigure these parameters to
comply with these rules before lying.
6.1 Max Height & Radius Limits
Max Height & Radius limits lying height and distance. Coniguration can be done in the Phantom 2 Vision+ Assistant
(Figure 57). Once complete, your Phantom will ly in a restricted cylinder (Figure 58).
Figure 57
Green lashing
Ready to Fly
Limits
Flight height must be under
Max Height
the set height.
Flight distance must be within
Max Radius
the max radius.
Ready to Fly(non-GPS)
Flight Limits
Max Height
Flight height restricted to 120m and under.
Max Radius No limits
If you ly out of the limit, you can still control the Phantom, but cannot ly it further.
If the Phantom flies out of the max radius in Ready to Fly (non-GPS) mode, it will fly back within range
automatically.

6.2 Flight Restriction of Restricted Areas

Restricted areas include airports worldwide. All restricted areas are listed on the DJI oficial website at http://www.dji.
com/ly-safe/category-mc. Restricted areas are divided into category A and category B. Category A areas cover major
international airport such as LAX and Heathrow, while category B areas includes smaller airports.
30
©
2015 DJI. All Rights Reserved.
DJI VISION App
Warning: Height limit
reached.
Warning: Distance limit
reached.
Yellow lashing
DJI VISION App
Warning: Height limit reached.
Max Height
Figure 58
Rear LED light indicator
None.
Rapid red lashing
the max radius limit.
Rear LED light indicator
None.
Max Radius
Home Point
Height of aircraft
when powered on
when close to
