Firmware upgradable items
Current irmware version
An internet connection is required to upgrade the Phantom 2 Vision+ irmware.
DO NOT power off until the upgrade is inished.
If the irmware upgrade fails, the Flight Controller will enter a waiting for irmware upgrade status automatically.
If this happens, repeat the above procedures.
Firmware upgradable items: (1)Flight Controller (2)GPS (3)5.8G Receiver (4) Main Board (P330CB) (5)Battery (6)
Gimbal IMU

2.3 Using the Phantom RC Assistant

Use the Phantom 2 Vision+ Assistant to install PHANTOM RC Assistant on your Windows PC or Mac, and then follow the
below steps to conigure the Remote Controller.
(1) Turn off the Remote Controller and ind its Micro-USB slot.
(2) Power on PC and Remote Controller then connect Remote Controller to the PC with a Micro-USB cable. DO NOT
disconnect until coniguration is inished.
(3) Run the PHANTOM RC Assistant and wait for the Remote Controller to connect to Assistant. Watch the indicators
on the bottom left of the screen. When connected successfully, the Computer Connection status is
Data Exchange Indicator blinks
(4) Finish coniguration in the [Main] page.
(5) Finish upgrade in the [Info] page if necessary.
Main page
Data Exchange Indicator
Computer Connection status
Figure 113
Figure 114
.
Figure 115
PC / MAC Assistant
Upgrade link
* This image is for reference
only. Please refer to the
actual user interface.
Language swap
Firmware upgrade,
Account, Software version
*This image is for reference only.
Please refer to the actual user
interface.
©
