Assembly and Use
Enable the "Tutorial" switch in the Settings page to get
hints and tips the irst time you use the DJI VISION App.

8 Connecting the Camera

Before light, always connect your smartphone to the Phantom's Wi-Fi network. This is required for the camera control
and FPV.

8.1 Connecting Procedures

Follow these instructions to connect a mobile device to the Phantom 2 Vision+ camera.
(1) Power on the Remote Controller and the Range Extender.
(2) Power on the Phantom 2 Vision+.
(3) Enable the Wi-Fi on your mobile device; wait for about 30 seconds, and then select "Phantom_XXXXXX" from theWi-
Fi network list (Figure45).
(4) Run the DJI VISION App on your mobile device. When the Wi-Fi Computer Connection status on the App main menu
goes green, the connection is good (Figure46).
(5) Tap the "CAMERA" icon and the DJI VISION App will begin a live camera preview (Figure47). This means everything
is functioning normally.
Enable Wi-Fi
Select
Phantom_XXXXXX
Wi-Fi Computer Connection Status Description
Icon
Solid green
Solid blue
Off
The SSID is unique for each Phantom 2 Vision+ It will appear as Phantom_XXXXXX in your Wi-Fi list.
Android users can tap the SSID button on the main page to mobile device Wi-Fi settings directly.
24
©
2015 DJI. All Rights Reserved.
Figure 45

Description

Wi-Fi is connected to the Phantom 2 Vision+.
Wi-Fi is connected to another Wi-Fi network, not to the Phantom 2 Vision+.
No Wi-Fi connection.
Figure 44
Figure 46
Ready to Fly
Figure 47
Wi-Fi Computer
Connection status
