Chapter 7 — Setup Mode
The Setup Mode is organized as an endless loop, from which you can
select a number of sub-categories. At startup, the fi rmware determines if
options such as a label taken sensor or an interface board are installed in
the printer. Only installed options are shown in the Setup Mode.
The diagram below shows the options in the main loop. Detailed over-
views are shown on the pages that follow.
SETUP:
PRINT DEFS
SETUP:
MEDIA
SETUP:
FEEDADJ
72
Starting point
SETUP:
SER-COM, UART1
SETUP:
NETWORK
EasyCoder PX4i User's Guide (Fingerprint version)
SETUP:
SER-COM, UART2
SETUP:
NET-COM, NET1
Option
Option
SETUP:
SER-COM, UART3
Option
SETUP:
SER-COM, UART4
Option
SETUP:
SER-COM, UART5
Option
Option
