Chapter 4 — Media Load
Internal Batch Takeup, cont.
5
Remove the tear bar from the print unit
and replace it with the guide plate.
6b
In case of a media roll with a 76 mm
(3-inch) core, fi rst fi t an adapter on the
media supply hub.
36
6a
Fit a new roll of media on the media
supply hub and push the roll inwards as
far as it will go.
7
Route the media underneath the slack
absorber and forward towards the print
mechanism. The slack absorber can be
rotated for better access and snap-
locked in open positon.
EasyCoder PX4i User's Guide (Fingerprint version)
