Chapter 2 — Installation
Rear View
The rear plate contains the On/Off switch, the AC power cord socket,
and various interface connectors and slots.
8
EasyCoder PX4i User's Guide (Fingerprint version)
Provision for EasyLAN
Wireless antenna
(option)
Provision for EasyLAN
Ethernet connection
(option)
Intake slot for external
media supply
Memory card slot
Provision for two optional
interface boards
On/Off Switch
Bar code wand socket
("wand:")
AC Power cord socket
RS-232 serial interface
("uart1:")
USB Interface ("usb1:")
Machine label
Intake slot for external
media supply
