Recommended Feed Adjustments

The following settings allow printing from the top of the label. Minor
deviations from the recommended values may be required due to various
combinations of media types, roll size, type of media supply device, and
individual differences between printers.
Adjustment
type
Tear-Off (Straight-through)
Start adjust:
Stop adjust:
Peel-Off (Self-strip)
Start adjust:
Stop adjust:
Cut between labels w. gaps
Start adjust:
Stop adjust:
Cut fi x and variable length strip
Start adjust:
Stop adjust:
EasyCoder PX4i User's Guide (Fingerprint version)
8 dots/mm
203.2 dpi
-108 dots
0 dots
-80 dots
-40 dots
-287 dots
+176 dots
-294 dots
+298 dots
Chapter 6 — Setting Up the Printer
11.81 dots/mm
300 dpi
-160 dots
0 dots
-118 dots
-60 dots
-424 dots
+260 dots
-434 dots
+440 dots
Distance Distance
in mm in inches
13.5 0.54
0 0
10.0 0.39
5.0 0.20
35,9 1.41
22.0 0.87
36.8 1.45
37.3 1.47
57
