Chapter 2 — Installation
Print Mechanism
The print mechanism features a high-performance thermal printhead
with quick-mount fi ttings to facilitate replacement.
Pressure
arm
Thermal printhead
Tear bar
Upper label stop sensor
guide (removable)
Lower label stop sensor guide
(removable)
Label stop sensor
position adjustment
screw
10
EasyCoder PX4i User's Guide (Fingerprint version)
Pressure arm
locking knob
Printhead
pressure
adjustment
knob
Edge
guide
Printhead lift
lever
