Setup Parameters

Serial Communication

The serial communication parameters control the communication
between the printer and the connected computer or other devices on
the standard serial port "uart1:" and the optional serial ports "uart2:",
"uart3:", "uart4:", and "uart5:". The optional ports require one or two
optional interface boards. The printer's fi rmware detects if an interface
board is installed in the printer and presents additional sets of commu-
nication setup menus depending on type of communication (refer to the
overviews in Chapter 7, "Setup Mode").
Note: The serial communication parameters have no effect on
parallel or EasyLAN communications, or on the IN and OUT
ports on the optional Serial/Industrial Interface Board.
For the serial communication channel "uart1:", the following parameters
can be set. Make sure they match the setup of the connected device or
vice versa. If the setup of the printer and the setup of the host do not
match, the response from the printer to host will be garbled.

Baud Rate

The baud rate is the transmission speed in bits per second. There are 10
options:
• 300
• 600
• 1200
• 2400
• 4800
• 9600
• 19200
• 38400
• 57600
• 115200
EasyCoder PX4i User's Guide (Fingerprint version)
(default)
Chapter 6 — Setting Up the Printer
53
